高压保护开关缓冲电路参数优化设计

李志恒 马少翔 张鸿淇 朱帮友 张明 于克训 潘垣

李志恒, 马少翔, 张鸿淇, 等. 高压保护开关缓冲电路参数优化设计[J]. 强激光与粒子束. doi: 10.11884/HPLPB202335.230158
引用本文: 李志恒, 马少翔, 张鸿淇, 等. 高压保护开关缓冲电路参数优化设计[J]. 强激光与粒子束. doi: 10.11884/HPLPB202335.230158
Li Zhiheng, Ma Shaoxiang, Zhang Hongqi, et al. Parameter optimization design of snubber circuit for high voltage protection switch[J]. High Power Laser and Particle Beams. doi: 10.11884/HPLPB202335.230158
Citation: Li Zhiheng, Ma Shaoxiang, Zhang Hongqi, et al. Parameter optimization design of snubber circuit for high voltage protection switch[J]. High Power Laser and Particle Beams. doi: 10.11884/HPLPB202335.230158

高压保护开关缓冲电路参数优化设计

doi: 10.11884/HPLPB202335.230158
基金项目: 国家重点研发计划项目(2017YFE0300104); 国家自然科学基金项目(51821005)
详细信息
    作者简介:

    李志恒,zhihengli@hust.edu.cn

    通讯作者:

    马少翔,mashaoxiang@hust.edu.cn

  • 中图分类号: TM832

Parameter optimization design of snubber circuit for high voltage protection switch

  • 摘要: 目前的高压保护开关缓冲电路参数设计缺乏相关理论设计方法,同时缓冲电路方案由于设计过程中并未考虑分布电容影响,因此均为等参数设计方案,这种方法均压效果不够理想。为了解决目前参数设计中存在的问题,首先建立了含缓冲电路和杂散电感的MOSFET模型并对其关断过程进行了分析,从而得到了抑制电压尖峰的缓冲电路理论设计方法及表达式。针对于串联均压未考虑分布电容的问题,通过构造等电位点,建立了含有分布电容的等效电路并进行分析,根据电荷方程等式得到了缓冲电路非等参数设计方法及表达式,该参数设计方法可以补偿分布电容造成的电压分布不均,并更好地指导高压保护开关的均压方案设计。为了验证参数设计的合理性进行了仿真分析,结果表明,最终得到的整体设计方案可以满足尖峰抑制以及均压的设计要求。
  • 图  1  电压钳位型均压电路原理图

    Figure  1.  Schematic diagram of voltage clamp voltage-balancing circuit

    图  2  电压钳位型均压电路工作原理图

    Figure  2.  Working principle diagram of voltage clamp voltage-balancing circuit

    图  3  新型均压拓扑原理图

    Figure  3.  New voltage-sharing topology schematic diagram

    图  4  拓扑工作模式示意图

    Figure  4.  Schematic diagram of topology working mode

    图  5  分析电路示意图

    Figure  5.  Schematic diagram of analytical circuit

    图  6  SiC MOSFET关断波形图

    Figure  6.  SiC MOSFET turn-off waveforms

    图  7  MOSFET串联模型示意图

    Figure  7.  Schematic diagram of MOSFET series model

    图  8  考虑分布电容和缓冲电路的串联MOSFET等效电路

    Figure  8.  Equivalent circuit of series MOSFET considering distributed capacitor and snubber circuit

    图  9  等电位点电路图

    Figure  9.  Isoelectric point circuit diagram

    图  10  简化等效电路图

    Figure  10.  Simplified equivalent circuit diagram

    图  11  无缓冲电路的电压电流波形图

    Figure  11.  Voltage and current waveforms without snubber circuit

    图  12  m=1.1时的电压电流波形图

    Figure  12.  Voltage and current waveforms of m=1.1

    图  13  m=1.2时的电压电流波形图

    Figure  13.  Voltage and current waveforms of m=1.2

    图  14  无缓冲电路的两管电压波形图

    Figure  14.  Two-tube voltage waveforms without snubber circuit

    图  15  等参数缓冲电路的两管电压波形图

    Figure  15.  Two-tube voltage waveform of isoparametric snubber circuit

    图  16  非等参数缓冲电路的两管电压波形图

    Figure  16.  Two-tube voltage waveform of non-isoparametric snubber circuit

    表  1  拓扑工作模式

    Table  1.   Topology working mode

    Pattern T1 T2 Module voltage Single tube current Function
    1 on on 0 i1/2 Over-current balancing
    2 on off 0 i1 Conduction discharge
    3 off off V1 0 Current shutoff
    4 off on 0 i1 Conduction discharge
    下载: 导出CSV

    表  2  MOSFET工作模式

    Table  2.   Working mode of MOSFET

    Operation mode Cgs Cgd Cds Channel condition
    VgsVth and VdsVgs-Vth Ohmic Cgs Cgd2 Cds2 Constant resistance Rds(on)
    VgsVth Cut off Cgs Cgd1 Cds1 Open circui
    下载: 导出CSV
  • [1] 章雪亮. 聚变装置辅助加热系统逆变型直流高压电源技术研究[D]. 武汉: 华中科技大学, 2016

    Zhang Xueliang. Research on the technology of inverter type DC high voltage power supply for auxiliary heating system of fusion device[D]. Wuhan: Huazhong University of Science & Technology, 2016
    [2] Watanabe K, Kashiwagi M, Kawashima S, et al. Development of a dc 1 MV power supply technology for NB injectors[J]. Nuclear Fusion, 2006, 46(6): S332-S339. doi: 10.1088/0029-5515/46/6/S15
    [3] 余振雄. J-TEXT装置ECRH控制系统研究[D]. 武汉: 华中科技大学, 2017

    Yu Zhenxiong. Research of electron cyclotron resonance heating control system on J-TEXT[D]. Wuhan: Huazhong University of Science and Technology, 2017
    [4] Zhang Ming, Wang Dongyu, Ma Shaoxiang, et al. A novel series switch module in high-voltage applications[J]. Fusion Engineering and Design, 2019, 146: 2618-2623. doi: 10.1016/j.fusengdes.2019.04.057
    [5] Abbate C, Busatto G, Iannuzzo F. High-voltage, high-performance switch using series-connected IGBTs[J]. IEEE Transactions on Power Electronics, 2010, 25(9): 2450-2459. doi: 10.1109/TPEL.2010.2049272
    [6] Podlesak T F, Carter J L, McMurray J A. Demonstration of compact solid-state opening and closing switch utilizing GTOs in series[J]. IEEE Transactions on Electron Devices, 1991, 38(4): 706-711. doi: 10.1109/16.75193
    [7] Consoli A, Musumeci S, Oriti G, et al. Active voltage balancement of series connected IGBTs[C]//Proceedings of the Conference Record of the 1995 IEEE Industry Applications Conference Thirtieth IAS Annual Meeting. 1995: 2754-2758.
    [8] Renz G, Holzschuh F, Zeyfang E. PFNs switched with stacked SCRs at 20 kV, 500 J, and 100 Hz REP-rate[C]//Proceedings of the 11th IEEE International Pulsed Power Conference. 1997: 390-395.
    [9] Welleman A, Fleischmann W, Kaesler W. Solid state on-off pulse switches using IGCT technology[C]//Proceedings of the IEEE 34th International Conference on Plasma Science. 2007: 1025-1028.
    [10] Dongye Zhonghao, Qi Lei, Cui Xiang, et al. A new approach to model reverse recovery process of a thyristor for HVdc circuit breaker testing[J]. IEEE Transactions on Power Electronics, 2021, 36(2): 1591-1601. doi: 10.1109/TPEL.2020.3007660
    [11] Luo Yifei, Xiao Fei, Liu Binli, et al. A physics-based transient electrothermal model of high-voltage press-pack IGBTs under HVdc interruption[J]. IEEE Transactions on Power Electronics, 2020, 35(6): 5660-5669. doi: 10.1109/TPEL.2019.2948936
    [12] Xiao Huangqing, Xu Zheng, Xiao Liang, et al. Components sharing based integrated HVDC circuit breaker for meshed HVDC grids[J]. IEEE Transactions on Power Delivery, 2020, 35(4): 1856-1866. doi: 10.1109/TPWRD.2019.2955726
    [13] Wang Dongyu, Zhang Ming, Ma Shaoxiang, et al. A high-voltage solid-state switch based on submodule topology of SiC MOSFETs for J-TEXT tokamak[J]. IEEE Transactions on Plasma Science, 2020, 48(6): 1676-1680. doi: 10.1109/TPS.2019.2959623
    [14] Ma Shaoxiang, Shang Wentong, Wang Dongyu, et al. A reliable voltage clamping submodule based on SiC MOSFET for solid state switch[J]. Review of Scientific Instruments, 2021, 92: 024713. doi: 10.1063/5.0027135
    [15] Lu Ting, Zhao Zhengming, Ji Shiqi, et al. Active clamping circuit with status feedback for series-connected HV-IGBTs[J]. IEEE Transactions on Industry Applications, 2014, 50(5): 3579-3590. doi: 10.1109/TIA.2014.2308356
    [16] Ji Shiqi, Lu Ting, Zhao Zhengming, et al. Series-connected HV-IGBTs using active voltage balancing control with status feedback circuit[J]. IEEE Transactions on Power Electronics, 2015, 30(8): 4165-4174. doi: 10.1109/TPEL.2014.2360189
    [17] Zarghani M, Mohsenzade S, Kaboli S. A fast and series-stacked IGBT switch with balanced voltage sharing for pulsed power applications[J]. IEEE Transactions on Plasma Science, 2016, 44(10): 2013-2021. doi: 10.1109/TPS.2016.2574126
