T/R双模微波功率模块技术及其应用

李建兵; 邱立; 王斌; 郭静坤; 董雪雨

doi:10.11884/HPLPB202335.230184

T/R双模微波功率模块技术及其应用

doi: 10.11884/HPLPB202335.230184

1.
战略支援部队信息工程大学信息系统工程学院，郑州 450001
2.
中国电子科技集团公司第十二研究所，北京 100015
3.
中国电子科技集团公司第二十九研究所，成都 610036

基金项目: 军队十四五预先研究项目(0722-227FJ552YPF/02)

详细信息

作者简介:
李建兵，49286894@qq.com

中图分类号: TN83
计量
- 文章访问数: 21
- HTML全文浏览量: 7
- PDF下载量: 6
- 被引次数: 0
出版历程
- 收稿日期: 2023-06-18
- 修回日期: 2023-10-26
- 录用日期: 2023-10-23
- 网络出版日期: 2023-11-20

Technology and applications of T/R dual-mode microwave power module

1.
PLA Strategic Support Force Information Engineering University, Zhengzhou 450001, China
2.
Beijing Vacuum Electronics Research Institute, Beijing 100015, China
3.
The 29S1 Research Institute of China Electronics Technology Group, Chengdu610036, China

摘要

摘要: 微波功率模块（MPM）是真空电子器件和固态电子器件组合而成的一种新型微波功率器件，具有频率高、频带宽、功率大、体积重量小等特点，它使常规行波管的应用变得更加便利和广泛。现代战争向雷达、电子战综合一体化方向发展，这就要求功放既能工作在高峰值功率、低占空比的高模工作方式，也能工作在低峰值功率、准连续波的低模工作方式，针对这一需求，结合电子系统收发共孔径的要求，提出了T/R双模MPM技术。T/R双模MPM技术的核心是T/R双模行波管，基于三端口双向T/R行波管，通过在慢波系统的衰减器附近设置一个耦合口，实现行波管的信号反向接收功能；通过T/R双模行波管设计、双模放大均衡组件、双调制栅极电源等技术实现MPM的双模双向功能。T/R双模MPM应用前景广阔，特别是在基于无人机平台的作战应用中的具有明显优势。
- 微波功率模块 /
- T/R行波管 /
- 收发共孔径 /
- 功放 /
- 均衡器
Abstract: Microwave power module (MPM) is a new type of microwave power device which is a combination of vacuum electronic devices and solid-state electronic devices. It has the characteristics of high frequency, wide bandwidth, large power and small volume and weight, which makes the application of conventional traveling wave tubes more convenient and extensive. Modern warfare is developing towards the integration of radar and electronic warfare, which requires that the power amplifier can work in both high-mode with high peak power and low duty cycle and low-mode with low peak power and quasi-continuous wave. In order to meet this demand, combined with the requirements of common aperture of electronic system, T/R dual-mode MPM technology is proposed. The core of T/R dual-mode MPM technology is T/R dual-mode traveling wave tube. Based on three-port bidirectional T/R traveling wave tube, the signal reverse receiving function of traveling wave tube is realized by setting a coupling port near the attenuator of slow wave system. The dual-mode bidirectional function of MPM is realized through the design of T/R dual-mode traveling wave tube, dual-mode amplifier and equalizer, and dual-modulation grid power supply. T/R dual-mode MPM has broad application prospects, especially in combat applications based on Unmanned Aerial Vehicle platform.
- microwave power module /
- T/R traveling wave tube /
- common aperture oftransceiver /
- power amplifier /
- equalizer

HTML全文

图 1 基于双模MPM的雷达、电子战综合一体化

Figure 1. Integrated integration of radar and electronic warfare based on dual-mode MPM

下载: 全尺寸图片幻灯片

图 2 典型雷达系统

Figure 2. Typical radar system

下载: 全尺寸图片幻灯片

图 3 基于T/R双模MPM的雷达、电子战综合一体化

Figure 3. Integrated integration of radar and electronic warfare based on T/R dual-mode MPM

下载: 全尺寸图片幻灯片

图 4 发射状态下行波管微波信号流向

Figure 4. Direction of microwave signal of TWT in emission state

下载: 全尺寸图片幻灯片

图 5 截止状态下行波管微波信号流向

Figure 5. Direction of microwave signal of TWT in cut-off state

下载: 全尺寸图片幻灯片

图 6 反向通道结构模型

Figure 6. Reverse channel structure mode

下载: 全尺寸图片幻灯片

图 7 插入损耗计算结果

Figure 7. Results of insertion loss

下载: 全尺寸图片幻灯片

图 8 行波管正向工作时第三端口耦合功率计算结果

Figure 8. Coupling power of the third port during the forward operation of the TWT

下载: 全尺寸图片幻灯片

图 9 单控制栅双模电子枪结构示意图

Figure 9. Single control grid dual mode electron gun structure

下载: 全尺寸图片幻灯片

图 10 两种工作模式下电子枪内部电子轨迹

Figure 10. Electron trajectory in electron gun under two working modes

下载: 全尺寸图片幻灯片

图 11 T/R双模MPM实现思路

Figure 11. Realization of T/R dual-mode MPM

下载: 全尺寸图片幻灯片

图 12 高低模切换测试结果

Figure 12. High and low mode switching test results

下载: 全尺寸图片幻灯片
