基于敏感性分析的核数据调整模块开发与验证

邹晓阳; 梁亮; 徐嘉隆

doi:10.11884/HPLPB202638.250234

基于敏感性分析的核数据调整模块开发与验证

doi: 10.11884/HPLPB202638.250234

西安智核云谷科技有限公司，西安 710021

详细信息

作者简介:
邹晓阳，1968940059@qq.com

中图分类号: TL32
计量
- 文章访问数: 197
- HTML全文浏览量: 350
- PDF下载量: 2
- 被引次数: 0
出版历程
- 收稿日期: 2025-07-24
- 修回日期: 2025-12-18
- 录用日期: 2025-12-18
- 网络出版日期: 2026-01-04

Development and validation of a nuclear data adjustment module based on sensitivity analysis

Xi'an Nuclear Intelligence Valley Co., Ltd. Xi'an 710021, China

摘要

摘要: 随着中子学计算方法的发展和精确建模能力的提高，核反应堆物理计算程序中模型近似和离散方法带来的误差逐渐减小，而核数据因其测量难度高，成为影响计算精度的关键输入参数。因此，基于自主研发的敏感性和不确定性分析平台SUPES，开发了基于敏感性分析和广义线性最小二乘算法的核数据调整模块。首先，由敏感性分析获取响应关于输入参数的变化规律；其次，通过相似性分析筛选中子学层面上相似程度高的实验装置参与核数据调整；最后，采用广义线性最小二乘算法使得计算值与实测值之间的误差最小，获得核数据调整量。根据临界基准题HEU-MET-FAST-078中的22个算例，对ACE格式连续能量数据库进行调整，数值结果表明，有效增殖因子k_eff的均方根误差从3.10×10⁻³降低到1.53×10⁻³。通过数值结果对比分析，验证了所开发的核数据调整模块的正确性。
- 敏感性分析 /
- 相似性分析 /
- 核数据调整 /
- ACE数据库
Abstract: Background
With the development of neutron calculation methods and improved modeling capabilities, the errors introduced by model approximations and discretization methods in nuclear reactor physics calculations have gradually decreased. However, nuclear data, due to the challenges in measurement, have become the key input parameter affecting computational accuracy.
Purpose
In this study, a nuclear data adjustment module based on sensitivity analysis and the generalized linear least squares algorithm was developed within the self-developed sensitivity and uncertainty analysis platform, SUPES.
Methods
First, sensitivity analysis was used to determine the relationship between system responses and input parameter variations. Next, similarity analysis was applied to select experimental setups with high similarity at the neutron physics level. Finally, the generalized linear least squares algorithm was employed to minimize the error between computed and measured values, resulting in nuclear data adjustments.
Results
The adjustment of the ACE format continuous energy database was performed on 22 cases from the critical benchmark HEU-MET-FAST-078. The numerical results show that the root mean square error of the effective multiplication factor (k_eff) was reduced from 3.10×10⁻³ to 1.53×10⁻³.
Conclusions
The comparison and analysis verified the correctness of the developed nuclear data adjustment module.
- sensitivity analysis /
- similarity analysis /
- nuclear data adjustment /
- ACE database

HTML全文

图 1 SUPES程序功能介绍

Figure 1. Introduction to SUPES program functions

下载: 全尺寸图片幻灯片

图 2 核数据调整模块流程图

Figure 2. Flowchart of nuclear data adjustment module

下载: 全尺寸图片幻灯片

图 3 HEU-MET-FAST-078基准题结构示意图

Figure 3. Schematic diagram of HEU-MET-FAST-078 benchmark structure

下载: 全尺寸图片幻灯片

图 4 临界实验装置k_eff对核数据的相对灵敏度系数

Figure 4. Relative sensitivity coefficients of k_eff to nuclear data for critical experiment device

下载: 全尺寸图片幻灯片

图 5 HEU-MET-FAST-078基准题算例之间的相似性系数

Figure 5. Similarity coefficients among HEU-MET-FAST-078 benchmark cases

下载: 全尺寸图片幻灯片

图 6 主要反应道核数据的相对调整系数

Figure 6. Relative adjustment coefficients of nuclear data for major reaction channels

下载: 全尺寸图片幻灯片

图 7 核数据调整前后k_eff计算值与基准值的对比

Figure 7. Comparison of k_eff calculation values before and after nuclear data adjustment with benchmark values

下载: 全尺寸图片幻灯片

图 8 核数据调整前后²³⁵U主要反应道核数据相对标准差的变化

Figure 8. The change in relative standard deviation of ²³⁵U reaction channel before and after nuclear data adjustment

下载: 全尺寸图片幻灯片

图 9 核数据调整前后²³⁵U主要反应道对k_eff不确定度的贡献

Figure 9. The contribution of ²³⁵U reaction channels to k_eff uncertainty before and after adjustment

下载: 全尺寸图片幻灯片

表 1 HEU-MET-FAST-078基准题的材料和尺寸信息

Table 1. Material and dimension information of HEU-MET-FAST-078 benchmark cases

case	²³⁵U mass fraction/%	fuel density/ (g/cm³)	diameter D/cm	fuel height H_c/cm	reflector material	top thickness H_t/cm	bottom thickness H_b/cm	reflector density/ (g/cm³)
#1	93.3	17.9	38.1	5.7562	water	15.24	0.0	0.9982
#3	93.3	17.9	38.1	6.7331	polyethylene	2.54	0.0	0.925
#5	93.3	17.9	38.1	5.9663	polyethylene	5.08	0.0	0.925
#7	93.3	17.9	38.1	3.8392	polyethylene	5.08	5.08	0.925
#9	93.3	17.9	38.1	5.7404	polyethylene	7.62	0.0	0.925
#11	93.3	17.9	38.1	5.6984	polyethylene	10.16	0.0	0.925
#13	93.3	17.9	38.1	5.7089	polyethylene	15.24	0.0	0.925
#15	93.3	17.9	38.1	5.6984	polyethylene	20.32	0.0	0.925
#17	93.3	17.9	38.1	5.6984	polyethylene	25.40	0.0	0.925
#19	93.3	17.9	38.1	5.5881	Lucite	15.24	0.0	1.18
#21	93.3	17.9	38.1	5.7352	paraffin	15.24	0.0	0.87
#23	93.3	17.9	38.1	7.1165	paraffin	2.54	0.0	1.79
#25	93.3	17.9	38.1	6.5860	paraffin	5.08	0.0	1.79
#27	93.3	17.9	38.1	6.0346	paraffin	15.24	0.0	1.70
#29	93.3	17.9	38.1	3.9600	paraffin	15.24	15.24	1.70
#31	93.3	17.9	38.1	5.9820	paraffin	17.78	0.0	1.71
#33	93.3	17.9	38.1	3.8340	paraffin	17.78	17.78	1.70
#35	93.3	17.9	38.1	5.9453	paraffin	20.32	0.0	1.72
#37	93.3	17.9	38.1	5.9558	paraffin	30.48	0.0	1.70
#39	93.3	17.9	38.1	5.9505	paraffin	35.56	0.0	1.71
#41	93.3	17.9	38.1	8.1564	none	/	/	/
#43*	93.3	17.9	38.1	6.7751	polyethylene	15.24	0.0	0.925
Note：*case #43 has a 0.0381 cm thick cadmium sheet between the polyethylene reflector and the fuel cylinder.

下载: 导出CSV

表 3 核数据调整前后k_eff计算值与基准值的误差

Table 3. Error of k_eff calculation values before and after nuclear data adjustment from benchmark values

case	benchmark k_eff (±1σ)	ENDF/B-VII.1 ACE MCNP result (±1σ)	error before adjustment/10⁻⁵	after adjustment MCNP result (±1σ)	error after adjustment/10⁻⁵
#1	0.9995±0.0018	0.99460±0.00007	−490	0.99799±0.00007	−151
#3	0.9994±0.0022	0.99597±0.00007	−343	0.99781±0.00007	−159
#5	0.9991±0.0019	0.99619±0.00007	−291	0.99864±0.00007	−46
#7	1.0000±0.0019	0.99857±0.00008	−143	1.00147±0.00008	147
#9	0.9997±0.0022	0.99580±0.00007	−390	0.99815±0.00007	−155
#11	0.9995±0.0015	0.99582±0.00007	−368	0.99845±0.00007	−105
#13	1.0000±0.0017	0.99735±0.00007	−265	0.99996±0.00008	−4
#15	0.9991±0.0018	0.99670±0.00007	−240	0.99925±0.00007	15
#17	0.9995±0.0018	0.99668±0.00007	−282	0.99928±0.00007	−22
#19	0.9995±0.0016	0.99560±0.00008	−390	0.99842±0.00007	−108
#21	0.9995±0.0020	0.99624±0.00007	−326	0.99885±0.00008	−65
#23	0.9992±0.0022	0.99804±0.00006	−116	0.99947±0.00006	27
#25	0.9992±0.0025	0.99739±0.00007	−181	0.99896±0.00007	−24
#27	0.9992±0.0021	0.99597±0.00007	−323	0.99733±0.00006	−187
#29	1.0000±0.0025	1.00235±0.00007	235	1.00292±0.00007	292
#31	0.9994±0.0020	0.99513±0.00007	−427	0.99668±0.00007	−272
#33	0.9996±0.0026	0.99591±0.00007	−369	0.99677±0.00007	−283
#35	0.9991±0.0022	0.99452±0.00007	−458	0.99592±0.00007	−318
#37	0.9986±0.0021	0.99624±0.00007	−236	0.99777±0.00006	−83
#39	0.9989±0.0021	0.99676±0.00007	−214	0.99835±0.00007	−55
#41	0.9992±0.0025	0.99678±0.00006	−242	0.99860±0.00006	−60
#43	1.0000±0.0019	0.99895±0.00007	−105	1.00044±0.00008	44

下载: 导出CSV

表 2 敏感性分析包含的核素反应道

Table 2. Nuclide reaction channels included in the sensitivity analysis

reaction symbol	instruction	involved nuclides
σ_elas	elastic scattering reaction	¹H ¹²C ¹⁶O ²³⁴U ²³⁵U ²³⁸U
σ_inel	inelastic scattering reaction	²³⁴U ²³⁵U ²³⁸U
σ_f	fission reaction	²³⁴U ²³⁵U ²³⁸U
σ_γ	capture reaction	¹H ¹²C ¹⁶O ²³⁴U ²³⁵U ²³⁸U
ν_p	prompt fission neutron yield	²³⁴U ²³⁵U ²³⁸U
χ_p	prompt fission neutron spectrum	²³⁵U

下载: 导出CSV

表 4 核数据调整前后有效增殖因子k_eff不确定度的变化

Table 4. The change in k_eff uncertainty of eigenvalues before and after nuclear data adjustment

case	benchmark k_eff (±1σ)	ENDF/B-VII.1 ACE MCNP result (±1σ)	before adjustment k_eff uncertainty/10⁻⁵	after adjustment k_eff uncertainty/10⁻⁵
#1	0.9995±0.0018	0.99460±0.00007	1130	482
#3	0.9994±0.0022	0.99597±0.00007	1145	516
#5	0.9991±0.0019	0.99619±0.00007	1135	478
#7	1.0000±0.0019	0.99857±0.00008	1321	462
#9	0.9997±0.0022	0.99580±0.00007	1128	464
#11	0.9995±0.0015	0.99582±0.00007	1119	460
#13	1.0000±0.0017	0.99735±0.00007	1123	464
#15	0.9991±0.0018	0.99670±0.00007	1126	471
#17	0.9995±0.0018	0.99668±0.00007	1117	463
#19	0.9995±0.0016	0.99560±0.00008	1136	471
#21	0.9995±0.0020	0.99624±0.00007	1117	462
#23	0.9992±0.0022	0.99804±0.00006	1039	531
#25	0.9992±0.0025	0.99739±0.00007	1098	533
#27	0.9992±0.0021	0.99597±0.00007	1199	539
#29	1.0000±0.0025	1.00235±0.00007	1538	525
#31	0.9994±0.0020	0.99513±0.00007	1204	534
#33	0.9996±0.0026	0.99591±0.00007	1574	536
#35	0.9991±0.0022	0.99452±0.00007	1206	532
#37	0.9986±0.0021	0.99624±0.00007	1211	534
#39	0.9989±0.0021	0.99676±0.00007	1212	539
#41	0.9992±0.0025	0.99678±0.00006	994	567
#43	1.0000±0.0019	0.99895±0.00007	1141	504

下载: 导出CSV

参考文献(14)

[1]	曹良志, 邹晓阳, 刘宙宇, 等. 高保真数值核反应堆不确定度量化方法研究进展[J]. 核动力工程, 2021, 42(2): 1-15 doi: 10.13832/j.jnpe.2021.02.0001 Cao Liangzhi, Zou Xiaoyang, Liu Zhouyu, et al. Research progresses of uncertainty quantification methods for high fidelity numerical nuclear reactor[J]. Nuclear Power Engineering, 2021, 42(2): 1-15 doi: 10.13832/j.jnpe.2021.02.0001
[2]	阳文俊, 胡赟. 核数据调整方法研究现状与发展[J]. 科技创新与应用, 2023, 13(27): 24-28 doi: 10.19981/j.CN23-1581/G3.2023.27.006 Yang Wenjun, Hu Yun. Research status and development of nuclear data adjustment methods[J]. Technology Innovation and Application, 2023, 13(27): 24-28 doi: 10.19981/j.CN23-1581/G3.2023.27.006
[3]	Salvatores M, Palmiotti G, Ishikawa M, et al. Assessment of existing nuclear data adjustment methodologies[R]. NEA/NSC/WPEC/DOC(2010)429, 2011.
[4]	Ishikawa M, Sugino K, Sato W, et al. Development of a unified cross-section set ADJ2000 based on adjustment technique for fast reactor analysis[J]. Journal of Nuclear Science and Technology, 2002, 39(s2): 1073-1076. doi: 10.1080/00223131.2002.10875287
[5]	吴海成. 基于核数据调整基准例题的²³⁵U协方差数据测试[J]. 原子能科学技术, 2020, 54(11): 1985-1990 doi: 10.7538/yzk.2020.youxian.0279 Wu Haicheng. Test of ²³⁵U covariance data with nuclear data adjustment benchmark[J]. Atomic Energy Science and Technology, 2020, 54(11): 1985-1990 doi: 10.7538/yzk.2020.youxian.0279
[6]	Wu Qu, Peng Xingjie, Yu Yingrui, et al. Nuclear cross-section adjustment based on the 2-D/1-D transport code KYADJ[J]. Annals of Nuclear Energy, 2020, 137: 107068. doi: 10.1016/j.anucene.2019.107068
[7]	吴屈. 基于一步法确定论程序的核数据敏感性与不确定度分析[D]. 北京: 清华大学, 2019 Wu Qu. Sensitivity and uncertainty analysis for nuclear data based on one-step determistic code[D]. Beijing: Tsinghua University, 2019
[8]	朱帅涛. 快能谱反应堆多群核数据的调整与精度评估方法研究[D]. 北京: 华北电力大学(北京), 2020 Zhu Shuaitao. Research on multigroup nuclear data adjustment and accuracy assessment method for fast spectrum reactor[D]. Beijing: North China Electric Power University (Beijing), 2020
[9]	万承辉. 核反应堆物理计算敏感性和不确定性分析及其在程序确认中的应用[D]. 西安: 西安交通大学, 2018 Wan Chenghui. Researches on sensitivity and uncertainty analysis for reactor physics computation and its application in code validation[D]. Xi'an: Xi'an Jiaotong University, 2018
[10]	乔梁. 钠冷快堆中子输运并行算法及堆芯物理参数的不确定性分析与核数据调整研究[D]. 西安: 西安交通大学, 2021 Qiao Liang. Neutron transport parallel calculation method in sodium-cooled fast reactor applied with uncertainty analysis and nuclear data adjustment research[D]. Xi'an: Xi'an Jiaotong University, 2021
[11]	黄金龙. 基于连续能量核数据的反应堆物理敏感性与不确定性分析及数据同化方法研究[D]. 西安: 西安交通大学, 2024 Huang Jinlong. Researches on the sensitivity and uncertainty analysis and data assimilation methos of reactor physics based on continuous energy nuclear data[D]. Xi'an: Xi'an Jiaotong University, 2024
[12]	Reed R, Schira N. Heu metal cylinders, partially reflected by water, polyethylene, lucite, and paraffin[R]. OECD Nuclear Energy Agency, 2006.
[13]	Wieselquist W, Zhu T, Vasiliev A, et al. PSI methodologies for nuclear data uncertainty propagation with CASMO-5M and MCNPX: results for OECD/NEA UAM benchmark phase I[J]. Science and Technology of Nuclear Installations, 2013, 2013: 549793. doi: 10.1155/2013/549793
[14]	Pusa M. Adjoint-based sensitivity and uncertainty analysis of lattice physics calculations with CASMO-4[C]//Proceedings of the International Conference on the Physics of Reactors. 2014.
