An integrated multi-parameter synchronous testing system for fiber lasers
-
摘要: 设计并实现了一种用于光纤激光器的多参量一体化同步测试系统，能够实现激光器功率、光谱、时域和光束质量的同步测量。通过外部接口、内部光路和控制软件的协同设计，该系统支持80 W至10 kW输出功率范围的光纤激光器测试。用户只需将待测激光器的光纤端帽（QBH）接入系统，通过上位机软件控制，即可实现光纤激光器的多参数同步测试而无需手动调节光路。测试完成后，系统会自动调用和处理原始测量数据并生成测试报告。该系统能够显著提升光纤激光器多参数测试效率并大幅降低数据处理复杂度，为科研和工业激光测试提供了高效、可靠的解决方案。Abstract:
Background Fiber lasers have been widely used in numerous fields such as industrial processing and scientific research detection, due to their significant advantages including high efficiency, low cost, and miniaturization. In the R&D (Research and Development) and mass production of fiber lasers, the synchronous testing of core performance indicators such as power, spectrum, time-domain characteristics, and beam quality is a key technical support. It enables comprehensive evaluation of the device’s overall performance, accurate localization of design defects, optimization of production process parameters, and guarantee of consistent product delivery. However, the traditional testing mode requires temporarily building a dedicated test system for each laser under test. It has problems such as long time consumption, cumbersome operation, and low testing efficiency, making it difficult to meet the needs of large-scale production and high-efficiency R&D.Purpose To address the above issues, this paper proposes an integrated synchronous testing system for multi-parameter fiber lasers. The system aims to realize the synchronous acquisition and testing of multiple indicators, including power, spectrum, time-domain characteristics, and beam quality. It further improves the scientificity of the comprehensive performance evaluation of lasers, provides reliable technical support for production practice and scientific research in related fields, and achieves the core goals of improving testing efficiency and simplifying testing processes.Methods The system achieves the integrated integration of multi-module hardware testing equipment, as well as standardized interfaces and external connections, based on optical principle design and precision mechanical structure design. From the perspective of safe operation, an emergency shutdown device for abnormal working conditions is equipped to ensure the safety of the system and the laser under test during the testing process. The control software adopts LabVIEW multi-threading technology to realize the synchronous acquisition and real-time transmission of various parameters.Results The system can adapt to the testing needs of fiber lasers with an output power range of 80 W to 10 kW. During testing, users only need to connect the fiber end cap of the laser under test to the system, and can start multi-parameter synchronous testing through the upper computer software without manual intervention in the optical adjustment link. After the test, the system can automatically complete the analysis and processing of raw data and generate a standardized test report. Verification experiments conducted with a 10 kW fiber laser as the test object show that the system has good operability, reliability, test repeatability, and technical feasibility.Conclusions The system significantly improves the efficiency of multi-parameter testing of fiber lasers and greatly reduces the complexity of data processing, providing an efficient and reliable solution for scientific research and industrial laser testing.-
Key words:
- fiber laser /
- laser parameters /
- integrated testing /
- control soft /
- test report
-
图 1 多参量一体化同步测试系统原理示意图
Figure 1. Schematic diagram of multi-parameter integrated synchronized testing system
图 2 多参量一体化同步测试系统整体硬件设计
Figure 2. Overall hardware design of multi-parameter integrated synchronized testing system
图 3 多参量一体化同步测试系统上位机操作界面
Figure 3. Upper-computer operation interface of multi-parameter integrated synchronized testing system
表 1 多参量一体化同步测试系统功能与测量范围
Table 1. Function and measurement range of the multi-parameter integrated synchronous testing system
parameter function measurement range power power meter control; power data acquisition, storage, and plotting; real-time display of maximum, minimum, average and standard deviation values of power 80 W～10 kW spectrum spectrometer control; spectrum data acquisition, storage, and plotting; real-time display of central wavelength, 3dB linewidth, average central wavelength, and standard deviation of central wavelength 600～ 1700 nmtime domain oscilloscope control; temporal data acquisition, storage, and plotting; real-time display of peak-to-peak, minimum, maximum, and average values in time domain DC～1 GHz beam quality beam quality analyzer control; beam quality analyzer data retrieval, storage, and plotting; real-time display of beam quality in X/Y directions, average beam quality, and standard deviation of beam quality M2: 1～50
下载: 导出CSV
-
[1] Zhou Jiaqi, Pan Weiwei, Qi Weiao, et al. Ultrafast Raman fiber laser: a review and prospect[J]. PhotoniX, 2022, 3: 18. doi: 10.1186/s43074-022-00064-2 [2] 周朴. 我国高功率光纤激光技术学科方向的历程、现状、挑战与建议[J]. 红外与激光工程, 2023, 52: 20230071 doi: 10.3788/IRLA20230071Zhou Pu. Review on the discipline of high power fiber laser in China[J]. Infrared and Laser Engineering, 2023, 52: 20230071 doi: 10.3788/IRLA20230071 [3] Richardson D J, Fini J M, Nelson L E. Space-division multiplexing in optical fibres[J]. Nature Photonics, 2013, 7(5): 354-362. doi: 10.1038/nphoton.2013.94 [4] 李森森, 闫秀生. 激光对抗系统中的中红外激光源及其关键技术[J]. 光电技术应用, 2018, 33(5): 19-23 doi: 10.3969/j.issn.1673-1255.2018.05.005Li Sensen, Yan Xiusheng. Research on mid-infrared laser source in laser countermeasure system and key technology[J]. Electro-Optic Technology Application, 2018, 33(5): 19-23 doi: 10.3969/j.issn.1673-1255.2018.05.005 [5] Fu W, Wright L G, Sidorenko P, et al. Several new directions for ultrafast fiber lasers [invited][J]. Optics Express, 2018, 26(8): 9432-9463. doi: 10.1364/OE.26.009432 [6] 朱虹, 李新, 秦鹏, 等. 一体化激光参数测试仪研制[J]. 激光与红外, 2008, 38(8): 809-812 doi: 10.3969/j.issn.1001-5078.2008.08.019Zhu Hong, Li Xin, Qin Peng, et al. The development of integrated laser tester[J]. Laser & Infrared, 2008, 38(8): 809-812 doi: 10.3969/j.issn.1001-5078.2008.08.019 [7] 吴伟霖, 余华恩, 陈冠楠, 等. 基于LabVIEW的激光功率远程检测系统[J]. 计算机系统应用, 2016, 25(4): 68-72Wu Weilin, Yu Huaen, Chen Guannan, et al. Remote detection system in laser power based on LabVIEW[J]. Computer System & Applications, 2016, 25(4): 68-72 [8] Bo Wen, Yi Jiangang. Power monitoring system of laser welding equipment[J]. Journal of Physics: Conference Series, 2021, 1944: 012042. doi: 10.1088/1742-6596/1944/1/012042 [9] 周国清, 谭逸之, 周祥, 等. 波长1064 nm和532 nm脉冲激光大动态范围能量的测试方法及实验[J]. 红外与激光工程, 2021, 50: 202004 doi: 10.3788/IRLA20200417Zhou Guoqing, Tan Yizhi, Zhou Xiang, et al. Testing method and experiment of large dynamic range energy of pulsed laser with wavelength of 1064 nm and 532 nm[J]. Infrared and Laser Engineering, 2021, 50: 202004 doi: 10.3788/IRLA20200417 [10] 黎高平, 陈超, 李栋, 等. 高能高功率激光参数测量技术研究[J]. 应用光学, 2020, 41(4): 645-650Li Gaoping, Chen Chao, Li Dong, et al. Study on parameters measurement technology of high energy and high power laser[J]. Journal of Applied Optics, 2020, 41(4): 645-650 [11] Yang H W, Shan Y H, Gao X M. Design and implementation of the multi-parameter laser test system[C]//Proceedings of the 2015 International Conference on Artificial Intelligence and Industrial Engineering. 2015: 132-135. [12] 中国人民解放军国防科技大学. 光纤激光器多参量同步测量软件V1.0[CP]. 2020-12-31National University of Defense Technology of the Chinese People's Liberation Army. Multi-parameter Synchronous Measurement Software for Fiber Laser V1.0[CP]. 2020-12-31 [13] 马彬, 侯志强, 焦宏飞, 等. 脉冲激光损伤阈值测量技术及光学元件损伤性能[J]. 光学 精密工程, 2022, 30(21): 2805-2826 doi: 10.37188/OPE.20223021.2805Ma Bin, Hou Zhiqiang, Jiao Hongfei, et al. Pulsed laser-induced damage threshold measurement and damage performance of optical components[J]. Optics and Precision Engineering, 2022, 30(21): 2805-2826 doi: 10.37188/OPE.20223021.2805 -
点击查看大图
图(7) / 表(1)
