Development of rep-rate PFN-Marx generator with nanosecond output jitter
-
摘要: PFN-Marx型脉冲驱动源具有结构紧凑、输出脉冲波形可调等优点，当用作高功率微波系统前级驱动源时在提升系统轻小型化水平、输出效率等方面具有巨大潜力。设计并研制了基于2节紧凑脉冲形成模块和低感火花隙气体开关的PFN-Marx型高压脉冲发生器，并实现了其50 Hz重复频率运行和低抖动输出。基于非均匀脉冲形成及波形调控技术实现了2节PFN的低振荡波形输出，并研制了兼具储能与脉冲形成功能的紧凑脉冲形成模块。对其工作参数和输出特性进行了分析计算，模块可输出近方波高压脉冲，脉冲宽度约150 ns。研制了紧凑型PFN-Marx发生器，通过对称放电、平面触发结构火花隙气体开关设计，实现了PFN-Marx发生器的重复频率运行和低抖动输出。所设计发生器输出功率可达3.4 GW，脉冲平顶持续时间约80 ns，能够以50 Hz重复频率工作，输出抖动标准差低至2.4 ns。Abstract:
Background The PFN (pulsed forming network)-Marx generator shows robust capabilities for enhancing the output efficiency and miniaturization level of pulsed power system, and offers the most significant potential for compact and lightweight design.Purpose This study aims to develop a compact PFN-Marx generator that is capable of generating high-power pulses with flat-top duration, while maintaining low output jitter.Methods A tailored pulsed forming module (PFM) was developed by employing a non-uniform PFN sections reduced to 2, aiming for enhanced compactness. The influence of key circuit parameters on its output waveform was investigated. A PFN-Marx generator was designed and assembled by employing the PFMs and low-jitter plane-triggering-electrode gas switches et al.Results The effects of key circuit parameters on the pulse shaping was quantitatively analyzed, and waveform tailoring of the PFM was achieved. The PFM could output a high-voltage pulse with a pulse width and flat-top duration (90%−90%) of about 150 ns and 80 ns, respectively. Once assembled into the Marx generator, it could deliver a 190 kV, 3.4 GW high pulsed power to a 10.6 Ω resistive load, while maintaining a flat-top duration of about 80 ns. When operating at a repetition rate of 50 Hz, it exhibits highly consistent output waveforms, with an output jitter as low as 2.4 ns.Conclusions A compact PFN-Marx generator was developed by employing a 2-sections tailored PFM that is capable of generating high-power pulses with flat-top duration. It is helpful for the development of compact Marx generator with the required waveform and low output jitter.-
Key words:
- Marx generator /
- rep-rate /
- pulse forming /
- gas switch /
- low output jitter.
-
图 3 两节Guillemin网络仿真电路和输出波形
Figure 3. Simulation circuit and waveform of the 2-section Guillemin network
图 4 两节Guillemin网络各支路电流波形(下)与回路输出波形(上)
Figure 4. Current waveform of each section (lower) and the algebraic sum of each section(upper)
图 5 脉冲形成模块实验波形及照片(插图)
Figure 5. Experimental waveform and picture inset of pulse forming module
图 6 气体开关电场分布图和电场强度曲线
Figure 6. Electric field distribution and field strength value on curve of the gas switch
表 1 各支路电流波峰/波谷占比随Lpri变化规律
Table 1. The percentage of peak/trough of each section in current waveform with the increase of Lpri
Lpri /nH percentage of T1/% percentage of P1/% percentage of T2/% section1 section2 section2 section2 0 107.74 38.68 30.57 28.68 40 117.38 30.47 24.25 31.33 120 106.14 20.39 12.61 24.25 200 97.61 16.18 7.67 20.78
