Capacitor Charging Control Strategy For Multi-modes Hybrid Series Resonance
-
摘要: 串联谐振型电容器充电电源凭借高效、高功率密度及抗短路能力，在脉冲功率领域应用广泛。然而，其传统PFM恒流充电控制方式导致充电损耗较大，效率降低，该问题在充电初期阶段表现尤为突出。提出一种多模态混合式恒流充电控制策略，旨在提高电容器充电电源的效率和输入电源的利用率。该策略通过半桥模态（充电初期）、混合式模态（充电中期）及全桥模态（充电后期）的协同控制，实现充电电压无缝切换的同时减小充电损耗、提升效率。此外，通过功率器件的复用设计实现模态切换，既满足高压充电需求，又降低了系统成本。基于此，设计并搭建一台650 V/1 A的充电电源样机。实验表明，相比传统PFM恒流充电控制，该策略显著提高了充电电源的整体效率，最大充电效率为96.4%。该方案不仅为电容储能设备的充电系统提供了高效率、低成本的控制路径，其模态切换机制亦可迁移至其他谐振型变换器的设计中，具备广泛的工程推广价值。Abstract:
Background Series resonant capacitor charging power supply is widely used in the field of pulse power due to its high efficiency, high power density, and short-circuit resistance. However, its traditional PFM constant current charging control method leads to significant charging losses and reduced efficiency, which is particularly prominent in the early stages of charging.Purpose A multimodal hybrid constant-current charging control strategy is proposed to enhance both the charging efficiency and input power utilization.Methods This strategy achieves smooth transitions of charging voltage while reducing charging losses and improving efficiency through collaborative control of half-bridge mode (early charging stage), hybrid mode (mid charging stage), and full-bridge mode (late charging stage). In addition, the conversion of working modes is achieved by multiplexing power devices, which not only meets the requirements of high-voltage charging but also reduces system costs.Results Based on this approach, a 650 V/1 A charging power supply prototype has been designed and built. Experimental results demonstrate that, compared to conventional PFM control, the proposed strategy significantly improves overall charging efficiency, achieving a maximum efficiency of 96.4%.Conclusions This method not only provides an effective solution for capacitor energy storage charging systems with high efficiency and low cost, but its modal switching mechanism is also transferable to the design of other resonant converters, demonstrating broad engineering applicability.-
Key words:
- series resonance /
- capacitor charging /
- constant current control /
- hybrid control /
- Multi-modes control
-
图 3 恒流充电过程的电压频率曲线
Figure 3. Voltage-frequency curve of constant current charging process
图 5 混合式控制的等效电路
Figure 5. Equivalent circuit of LC resonant converter in hybrid control
表 1 已知参数与设计参数
Table 1. Known parameters and design parameters
Parameters Values Parameters Values input voltage Vin/V 60 Resonant Inductor Lr/μH 15 output voltage Vo/V 650 resonant capacitor Cr/μF 0.7 output current Io/A 1 Transformer turns ratio N 11 Resonant frequency fr/kHz 50
下载: 导出CSV
-
[1] 甘延青, 罗光耀, 李飞, 等. 大功率重复频率高电压脉冲充电电源研制[J]. 强激光与粒子束, 2025, 37: 035003Gan Yanqing, Luo Guangyao, Li Fei, et al. Development of high power repetition-rate high voltage pulse charging power supply[J]. High Power Laser and Particle Beams, 2025, 37(3): 035003 [2] 李波, 赵娟, 李洪涛, 等. 正负双极性直流高压充电电源设计[J]. 强激光与粒子束, 2022, 34: 095016 doi: 10.11884/HPLPB202234.210490Li Bo, Zhao Juan, Li Hongtao, et al. Design of bipolarity DC high voltage charging power supply[J]. High Power Laser and Particle Beams, 2022, 34: 095016 doi: 10.11884/HPLPB202234.210490 [3] 孙加祥, 吴红飞, 汤欣喜, 等. 基于整流侧辅助调控的交错并联LLC谐振变换器[J]. 电工技术学报, 2021, 36(10): 2072-2080Sun Jiaxiang, Wu Hongfei, Tang Xinxi, et al. Interleaved LLC resonant converter with auxiliary regulation of rectifier[J]. Transactions of China Electrotechnical Society, 2021, 36(10): 2072-2080 [4] 熊慧, 秦涛涛, 刘近贞. 基于LCCL谐振变换器拓扑的新型经颅磁刺激电容器充电电源设计[J]. 电工技术学报, 2022, 37(18): 4757-4765,4776Xiong Hui, Qin Taotao, Liu Jinzhen. Design of new transcranial magnetic stimulation capacitor charging power supply based on LCCL resonant converter topology[J]. Transactions of China Electrotechnical Society, 2022, 37(18): 4757-4765,4776 [5] Wang Yuchen, Yang Yahong, Wang Lei, et al. Optimal design of high-efficiency series resonant capacitor charging power supply[C]//Proceedings of the 2022 IEEE 6th Information Technology and Mechatronics Engineering Conference. 2022: 7-10. [6] 郭俊超, 韩耀锋, 李龙骧, 等. 脉冲激光器中储能电容的充电电源改进与仿真[J]. 激光杂志, 2020, 41(7): 176-180Guo Junchao, Han Yaofeng, Li Longxiang, et al. Improvement and simulation on charging power supply used in energy storage capacitors of pulsed laser[J]. Laser Journal, 2020, 41(7): 176-180 [7] 江进波, 徐林, 罗正, 等. 基于LC串联谐振的高压恒流充电电源设计[J]. 强激光与粒子束, 2024, 36: 055006Jiang Jinbo, Xu Lin, Luo Zheng, et al. Design of high voltage constant current charging power supply based on LC series resonance[J]. High Power Laser and Particle Beams, 2024, 36: 055006 [8] 陈泽宇, 刘庆想, 李伟. 恒功率输入的电容器充电电源算法优化设计[J]. 强激光与粒子束, 2025, 37: 035018Chen Zeyu, Liu Qingxiang, Li Wei. Optimal design of capacitor charging power supply algorithm with constant power input[J]. High Power Laser and Particle Beams, 2025, 37: 035018 [9] Gao J, Guan J S, Zhang Y, et al. Design of a high voltage charging power supply for HIAF-kicker system[J]. Physics of Particles and Nuclei, 2025, 56(3): 549-557. doi: 10.1134/S1063779624701946 [10] Zhang Yuqiang, Shangguan Jingbin, Gao Daqing, et al. Design of a modular high-accuracy, high-voltage charging power supply prototype[J]. Journal of Physics: Conference Series, 2022, 2401: 012051. doi: 10.1088/1742-6596/2401/1/012051 [11] Li Zi, Zhu Yingbing, Jiang Song, et al. Optimal design of the series resonant charging power supply[J]. IEEE Transactions on Plasma Science, 2025, 53(4): 704-712. doi: 10.1109/TPS.2025.3531361 [12] Jafari H, Habibi M. High-voltage charging power supply based on an LCC-type resonant converter operating at continuous conduction mode[J]. IEEE Transactions on Power Electronics, 2020, 35(5): 5461-5478. doi: 10.1109/TPEL.2019.2946876 [13] Xu Yun, Lu Chao, Yu Zhiyuan, et al. Multimode constant power control strategy for LCC resonant capacitor charging power supply based on state plane analysis[J]. IEEE Transactions on Power Electronics, 2021, 36(7): 8399-8412. doi: 10.1109/TPEL.2020.3042824 [14] Gong J W, Ahn S H, Ryoo H J, et al. Comparison of DCM and CCM operated resonant converters for high-voltage capacitor charger[C]//Proceedings of the 39th Annual Conference of the IEEE Industrial Electronics Society. 2013: 532-537. [15] 曾宇轩, 菲华·帕兰斯, 于克训, 等. 变母线电压的LLC高压电容充电电源设计[J]. 强激光与粒子束, 2024, 36: 025013 doi: 10.11884/HPLPB202436.230151Zeng Yuxuan, Palanas P J, Yu Kexun, et al. LLC high voltage capacitor charging power supply design with variable bus voltage[J]. High Power Laser and Particle Beams, 2024, 36: 025013 doi: 10.11884/HPLPB202436.230151 [16] Sun Xiaofeng, Li Xiaohua, Shen Yanfeng, et al. Dual-bridge LLC resonant converter with fixed-frequency PWM control for wide input applications[J]. IEEE Transactions on Power Electronics, 2017, 32(1): 69-80. doi: 10.1109/TPEL.2016.2530748 [17] Ma Jianguang, Wei Xueye, Hu Liang. Investigation on optimal parameter selection for LLC half-bridge resonant converter based on FHA[J]. Turkish Journal of Electrical Engineering and Computer Sciences, 2018, 26(2): 895-905. doi: 10.3906/elk-1706-194 [18] 缪哲语, 仝昊, 姚文熙, 等. 一种柔性多模态宽范围全桥LLC变换器控制方法[J]. 中国电机工程学报, 2022, 42(2): 747-760 doi: 10.13334/j.0258-8013.pcsee.210211Miao Zheyu, Tong Hao, Yao Wenxi, et al. A flexible variable-mode control method for wide-range full-bridge LLC converter[J]. Proceedings of the CSEE, 2022, 42(2): 747-760 doi: 10.13334/j.0258-8013.pcsee.210211 -
