储能电容方式驱动强流脉冲加速器重频运行
Primary power supply of repetitive pulsed intense current accelerator charged by capacitance of energy store
-
摘要: 对储能电容方式驱动强流脉冲加速器初级能源回路重频运行进行研究，阐明其工作原理，给出了储能电容电压的适用范围，得到了储能电容的初始电压、原边电容的反向电压、储能电容对原边电容开始充电和能量回收回路启动之间的延时这三者之间的解析关系式。对实际应用的储能电容方式驱动强流脉冲加速器初级能源回路进行了模拟研究，制定了256×256的数据表格，供控制程序查表之用，根据数据表格，实现了储能电容方式驱动强流脉冲加速器稳定的重频运行。Abstract: The primary power supply of repetitive pulsed intense current accelerator charged by capacitance of energy store is studied. The principle of primary power supply circuit and its time diagram of switches are presented. The circuit is analyzed and some expressions are got, especially, the usable voltage scope of capacitance of energy store, and the correlation between the parameters of circuit and time delay, which is between the turn-on of the charging circuit of capacitance of energy store and the circuit of recuperation. The time delay of 256×256 lookup table is made with the instruction of theory and the simulation of the actual parameters of circuits. The table is used by the control program to control the repetitive operating of the actual pulsed intense current accelerator. Finally,
-
