一种陡脉冲高电压电阻分压器的补偿方法
A METHOD OF COMPENSATING FOR RESISTIVE VOLTAGE DIVIDERS
-
摘要: 在对实用分压器构型进行分析比较的基础上提出了一种补偿法。其特点是,采用高阻高压臂一级分压构型,利用低阻低压臂自身电感对分压器的对地分布电容进行抵偿。按这种方法设计的兆估级纳秒脉冲电阻分压器自身的方法响应上升时间约为1ns。Abstract: A new method of compensating for resistive voltage dividers is proposed in this paper. This method is characterized by high resistance in the high voltage arm of a one-stage divider, and the compensation for risetime is fulfilled by the inductance of the low arm itself. A divider has been designed with this method to measure megavolt, nanosecond signals. A risetime of about Ins has been achieved with this divider.
-
Key words:
- resistive voltage divider /
- stray capacitance /
- compensation
-
