Empirical formula of breakdown electric field and time delay for SF6 gas switch under nanosecond pulse and hundreds of kV/cm electric field
-
摘要: 百kV/cm高场强纳秒脉冲条件下，采用J. C. Martin经验公式估算SF6气体击穿场强时，估算值与实验结果差异显著。为了进一步指导高场强脉冲气体开关设计，为开关工作状态调节提供依据，借鉴经典击穿场强经验公式形式建立了百kV/cm场强下SF6气体开关纳秒脉冲击穿场强和时延与实验参数之间的关系，基于实验数据拟合形成了修正系数的击穿场强和时延经验公式。研究表明，百kV/cm场强和纳秒脉冲条件下脉冲电压斜率对开关击穿特性有重要影响，击穿场强与击穿时延相互关联。百ns至μs脉冲与几十ns脉冲气体放电机理的区别引起放电过程中击穿时延组成发生变化，导致了经典击穿场强经验公式估算值与实验结果的显著差异。修正系数的击穿经验公式可为电磁脉冲模拟器输出开关提供更为精确的工程设计依据。Abstract: There are significant differences between the calculation results and experimental results by using J. C. Martin empirical formula to estimate the breakdown electric field for hundreds of kV/cm electric field and nanosecond pulse. To improve the design of pulsed gas switch and adjustment of working conditions, the relationships between the breakdown electric field and time delay and the experimental parameters based on the classical empirical formula is established. The empirical formula of breakdown electric field and time delay for SF6 gas switch under nanosecond pulse and hundreds of kV/cm electric field is presented. It is indicated that the slope of pulse will affect the breakdown characteristics of nanosecond pulse in high electric field and the breakdown electric field is correlated with the breakdown time delay. The differences between the calculation results and experimental results are caused by the experimental conditions. The fitting expression of empirical formula can give more guidance for the design of output switch in the electromagnetic pulse simulator.
-
图 2 SF6气体开关击穿特性研究高压实验平台
Figure 2. High electric field nanosecond pulse experimental setup
图 3 三种场型结构电极电场分布图
Figure 3. Electric field distribution of three electrode configurations
-
[1] 严璋, 朱德恒. 高电压绝缘技术[M]. 3版. 北京: 中国电力出版社, 2015Yan Zhang, Zhu Deheng. High voltage insulation technology[M]. 3rd ed. Beijing: China Electric Power Press, 2015 [2] 施围, 邱毓昌, 张乔根. 高电压工程基础[M]. 北京: 机械工业出版社, 2011Shi Wei, Qiu Yuchang, Zhang Qiaogen. High voltage engineering foundation[M]. Beijing: China Machine Press, 2011 [3] 刘锡三. 高功率脉冲技术[M]. 北京: 国防工业出版社, 2005Liu Xisan. High power pulse technology[M]. Beijing: National Defense Industry Press, 2005 [4] Bluhm H. Pulsed power systems: principles and applications[M]. Berlin, Heidelberg: Springer, 2006. [5] Mesyats G A. Pulsed power[M]. New York: Kluwer Academic/Plenum Publishers, 2005. [6] 尹佳辉, 孙凤举, 邱爱慈, 等. MV级气体开关脉冲自击穿特性及支撑结构的优化[J]. 强激光与粒子束, 2008, 20(7):1220-1224. (Yin Jiahui, Sun Fengju, Qiu Aici, et al. Self-breakdown properties and optimization of insulator envelope for MV gas switch under pulsed voltage[J]. High Power Laser and Particle Beams, 2008, 20(7): 1220-1224Yin Jiahui, Sun Fengju, Qiu Aici, et al. Self-breakdown properties and optimization of insulator envelope for MV gas switch under pulsed voltage[J]. High Power Laser and Particle Beams, 2008, 20(7): 1220-1224 [7] Martin T H, Guenther A H, Kristiansen M. J. C. Martin on pulsed power[M]. New York: Plenum Press, 1996. [8] Gilman C, Lam S K, Naff J T, et al. Design and performance of the FEMP-2000: a fast rise time, 2 MV EMP pulser[C]//Proceedings of the 12th IEEE International Pulsed Power Conference. Monterey, USA: IEEE, 1999: 1437-1440. [9] Belt D, Mazuc A, Sebacher K, et al. Operational performance of the Horizontal Fast Rise EMP pulser at the Patuxent River EMP test facility[C]//Proceedings of 2011 IEEE Pulsed Power Conference. Chicago, USA: IEEE, 2011. [10] 邱爱慈. 脉冲功率技术应用[M]. 西安: 陕西科学技术出版社, 2016Qiu Aici. Pulsed power technology application[M]. Xi’an: Shannxi Science and Technology Press, 2016 [11] 张永民, 来定国, 程亮, 等. 纳秒脉冲电压下气体开关的击穿特性[J]. 强激光与粒子束, 2009, 21(8):1267-1270. (Zhang Yongmin, Lai Dingguo, Cheng Liang, et al. Breakdown characteristics of gas switch under nanosecond pulse voltage[J]. High Power Laser and Particle Beams, 2009, 21(8): 1267-1270Zhang Yongmin, Lai Dingguo, Cheng Liang, et al. Breakdown characteristics of gas switch under nanosecond pulse voltage[J]. High Power Laser and Particle Beams, 2009, 21(8): 1267-1270 [12] Guo Fan, Xie Yanzhao, Jia Wei, et al. Effect of electrode surface micro-protrusions on the breakdown time delay and jitter for nanosecond pulsed gas discharge under hundreds of kV/cm in sulfur hexafluoride[J]. Physics of Plasmas, 2020, 27: 083502. doi: 10.1063/5.0005499 [13] Martin T H. An empirical formula for gas switch breakdown delay[C]//Proceedings of the 7th Pulsed Power Conference. Monterey, USA: IEEE, 1989: 73-79. [14] Schaefer G, Kristiansen M, Guenther A. Gas discharge closing switches[M]. New York: Plenum Press, 1990. [15] 郭帆. 兆伏级SF6气体开关纳秒脉冲击穿时延和抖动的影响机制研究[D]. 西安: 西安交通大学, 2021Guo Fan. The influence mechanism of breakdown time delay and jitter for megavolt level SF6 gas switch under nanosecond pulse[D]. Xi’an: Xi’an Jiaotong University, 2021 [16] Guo Fan, Xie Yanzhao, Jia Wei, et al. The self-breakdown characteristics of the output switch for EMP simulator[C]//Proceedings of 2019 Asia Electromagnetic Conference. Xi'an, China, 2019. -
