高延时分辨低抖动同步时序信号产生技术

王深圳 王超 苏东 党钊 张雄军 陈文棋 陈骥

王深圳, 王超, 苏东, 等. 高延时分辨低抖动同步时序信号产生技术[J]. 强激光与粒子束, 2023, 35: 082002. doi: 10.11884/HPLPB202335.220294
引用本文: 王深圳, 王超, 苏东, 等. 高延时分辨低抖动同步时序信号产生技术[J]. 强激光与粒子束, 2023, 35: 082002. doi: 10.11884/HPLPB202335.220294
Wang Shenzhen, Wang Chao, Su Dong, et al. Generation technology of synchronous trigger signals with low time jitter and high delay resolution[J]. High Power Laser and Particle Beams, 2023, 35: 082002. doi: 10.11884/HPLPB202335.220294
Citation: Wang Shenzhen, Wang Chao, Su Dong, et al. Generation technology of synchronous trigger signals with low time jitter and high delay resolution[J]. High Power Laser and Particle Beams, 2023, 35: 082002. doi: 10.11884/HPLPB202335.220294

高延时分辨低抖动同步时序信号产生技术

doi: 10.11884/HPLPB202335.220294
基金项目: 国家自然科学基金项目(12004352)
详细信息
    作者简介:

    王深圳,szwang@cqu.edu.cn

    通讯作者:

    党 钊,qingzhaodangma@caep.cn

  • 中图分类号: TN492

Generation technology of synchronous trigger signals with low time jitter and high delay resolution

  • 摘要: 针对大型激光装置中广空间分布的甚多路高精度(一是长时间时间抖动小于5 ps,二是时间延迟微步进分辨率小于15 ps)同步触发信号的需求,设计了一种“数据流编解码光传输+高速串行收发器粗延时+宽带微带线微步进延时”的同步时序产生方案。通过数据流编解码光传输架构实现了广空间范围内时序的对齐;高速串行收发器粗延时和微带线微步进延时技术解决了同步触发信号低时间抖动和高延迟分辨的问题。通过对系统的时序逻辑和电路板的关键线路进行仿真,完成了整个系统的设计与研制,并开展了实验测试。测试结果表明:该系统可以实现广空间范围内的同步时序信号产生,同步触发信号的时间抖动精度优于3.76 ps(均方根值,8 h),39.6 ps(峰峰值,8 h),时间延迟分辨率优于15 ps;若应用于小空间范围,同步触发信号的时间精度可优于1.27 ps(均方根值,8 h),12.4 ps(峰峰值,8 h)。
  • 图  1  高延时分辨低抖动同步时序信号产生系统框图

    Figure  1.  Framework of the synchronizing system with high resolution and low jitter

    图  2  基准时钟与触发启动信号的编解码过程图

    Figure  2.  Encoding and decoding of the reference clock and delayed start signal

    图  3  高速串行收发器粗延时的原理图

    Figure  3.  Principle of coarse delay by using transceiver

    图  4  高速串行收发器工作模式配置图

    Figure  4.  Transceiver configured in Basic (PMA Direct)

    图  5  微带线微步进延迟线原理图

    Figure  5.  Principle of fine delay by using stripline delay line

    图  6  Transceiver收发器实现同步信号的粗延时的波形图

    Figure  6.  Wave of the transceiver implementing the coarse delay of the synchronization signal

    图  7  基准时钟与延时起点信息的编解码时序逻辑仿真图

    Figure  7.  Codec timing logic simulation of the reference clock and delayed start signal

    图  8  具备粗延时的同步信号波形数据的产生

    Figure  8.  Generation of the waveform data for synchronous signals with coarse delay

    图  9  电路板关键线路的仿真

    Figure  9.  Simulation of key circuits on the board

    图  10  实验测试系统框图

    Figure  10.  Framework of experimental test system

    图  11  同步信号时间抖动测试结果

    Figure  11.  Timing jitter result of synchronous signals

    表  1  延时设置误差测试结果

    Table  1.   Results of delay setting error

    No.delay on the
    CH1/ns
    delay on the
    CH2/ns
    delay between the two channels
    in the oscilloscope/ns
    theoretical
    value/ns
    error between the theoretical
    value and measured/ps
    1 1 1 −0.027 −0.027(intrinsic delay) 0
    2 1 10 −9.031 −9.027 4
    3 1 50 −49.036 −49.027 9
    4 1 100 −99.034 −99.027 7
    5 1 300 −299.035 −299.027 8
    6 1 800 −799.036 −799.027 9
    7 1 1000 −990.033 −999.027 6
    8 1 2000 −1999.039 −1999.027 12
    9 1 5000 −4999.053 −4999.027 26
    10 1 10000 −9999.063 −9999.027 36
    11 1 20000 −19999.083 −4999.027 56
    下载: 导出CSV

    表  2  延时分辨率测试结果

    Table  2.   Results of delay resolution

    No.delay on the
    CH1/ns
    delay on the
    CH2/ns
    delay between the two channels
    in the oscilloscope/ps
    theoretical
    value/ps
    error between the theoretical
    value and measured/ps
    1 1 1.00 −27 −27(intrinsic delay) 0
    2 1 1.01 −40 −37 3.0
    3 1 1.02 −47 −47 0
    4 1 1.03 −59 −57 2.0
    5 1 1.04 −66.7 −67 −0.3
    6 1 1.05 −81.6 −77 4.6
    7 1 1.08 −107.8 −107 0.8
    8 1 1.10 −127.5 −127 0.5
    9 1 1.15 −179.8 −177 2.8
    10 1 1.20 −225.7 −227 −1.3
    11 1 1.25 −279 −277 2.0
    12 1 1.30 −331.5 −327 4.5
    13 1 1.31 −341.7 −337 4.7
    下载: 导出CSV
  • [1] Li Hao, Liu Shubin, Feng Changqing, et al. TOF clock system for BES III[J]. IEEE Transactions on Nuclear Science, 2010, 57(2): 442-445. doi: 10.1109/TNS.2009.2034659
    [2] 褚少平. LHAASO WCDA读出电子学时钟同步与数据传输研究[D]. 合肥: 中国科学技术大学, 2017: 13-26

    Chu Shaoping. Research of clock synchronization and data transmission in LHAASO WCDA readout electronics[D]. Hefei: University of Science and Technology of China, 2017: 13-26
    [3] Crane J K, Tietbohl G, Arnold P, et al. Progress on converting a NIF quad to eight, petawatt beams for advanced radiography[J]. Journal of Physics: Conference Series, 2010, 244: 032003. doi: 10.1088/1742-6596/244/3/032003
    [4] 赵环, 王鹏, 滕浩, 等. TW级钛宝石飞秒激光放大装置中的同步控制[J]. 强激光与粒子束, 2010, 22(5):953-958 doi: 10.3788/HPLPB20102205.0953

    Zhao Huan, Wang Peng, Teng Hao, et al. Synchronization of time-frequency signals in TW Ti: sapphire laser system[J]. High Power Laser and Particle Beams, 2010, 22(5): 953-958 doi: 10.3788/HPLPB20102205.0953
    [5] 尹佳辉, 曾江涛, 孙凤举, 等. 低抖动快前沿高电压重复率触发器[J]. 强激光与粒子束, 2011, 23(10):2836-2840 doi: 10.3788/HPLPB20112310.2836

    Yin Jiahui, Zeng Jiangtao, Sun Fengju, et al. Repetitive trigger generator with low jitter and fast rise time[J]. High Power Laser and Particle Beams, 2011, 23(10): 2836-2840 doi: 10.3788/HPLPB20112310.2836
    [6] 党钊, 唐菱, 张晓璐, 等. 大型激光装置精密同步系统总体技术研究[J]. 强激光与粒子束, 2014, 26:081009 doi: 10.11884/HPLPB201426.081009

    Dang Zhao, Tang Ling, Zhang Xiaolu, et al. General technology research on high precision synchronizing system for large-scale laser facilities[J]. High Power Laser and Particle Beams, 2014, 26: 081009 doi: 10.11884/HPLPB201426.081009
    [7] Lerche R A, Coutts G W, Lagin L J, et al. The NIF integrated timing system-design and performance[DB/OL]. arXiv preprint arXiv: physics/0111046, 2001.
    [8] Luttmann M, Pastor J F, Drouet V, et al. Laser mégajoule synchronization system[C]//Proceedings of the 7916, High Power Lasers for Fusion Research. 2011: 79160Z.
    [9] 党钊, 王超, 唐菱, 等. 开放式精密时序发生系统: CN103076841A[P]. 2013-05-01

    Dang Zhao, Wang Chao, Tang Ling, et al. Open precision timing generation system: CN103076841A[P]. 2013-05-01
    [10] 王梦宇, 张延超, 李美伦, 等. 用于激光雷达的高精度脉冲延时及脉宽控制研究[J]. 机械与电子, 2016, 34(8):3-6 doi: 10.3969/j.issn.1001-2257.2016.08.001

    Wang Mengyu, Zhang Yanchao, Li Meilun, et al. Research on high precision pulsed delay and pulse width control based on laser lidar[J]. Machinery & Electronics, 2016, 34(8): 3-6 doi: 10.3969/j.issn.1001-2257.2016.08.001
    [11] 陈伯俊, 周俊敏, 马军勇. 基于FPGA的高精度多路同步脉冲产生系统研究[J]. 科学技术与工程, 2010, 10(19):4793-4796 doi: 10.3969/j.issn.1671-1815.2010.19.046

    Chen Bojun, Zhou Junmin, Ma Junyong. The research of synchronization pulse generation system with multi-channel and high-precision based on FPGA[J]. Science Technology and Engineering, 2010, 10(19): 4793-4796 doi: 10.3969/j.issn.1671-1815.2010.19.046
    [12] 刘鹏, 许可. 一种基于FPGA的高精度大动态数字延迟单元的设计[J]. 微计算机信息, 2010, 26(8):132-134

    Liu Peng, Xu Ke. A design of digital delay line based on FPGA[J]. Microcomputer Information, 2010, 26(8): 132-134
    [13] 潘昭浩, 张政权, 刘庆想, 等. 高精度多路脉冲延时技术[J]. 强激光与粒子束, 2021, 33:105001 doi: 10.11884/HPLPB202133.210082

    Pan Zhaohao, Zhang Zhengquan, Liu Qingxiang, et al. High-precision multi-channel pulse delay technology[J]. High Power Laser and Particle Beams, 2021, 33: 105001 doi: 10.11884/HPLPB202133.210082
    [14] 李军, 虎雷, 李永明, 等. 一种高精度可延时同步脉冲产生系统[J]. 数字技术与应用, 2018, 36(7):182-184 doi: 10.19695/j.cnki.cn12-1369.2018.07.93

    Li Jun, Hu Lei, Li Yongming, et al. Design of high accuracy and delayed synchronization pulse generation system[J]. Digital Technology & Application, 2018, 36(7): 182-184 doi: 10.19695/j.cnki.cn12-1369.2018.07.93
    [15] 姜漫. 10Gbps/40Gbps光纤通信技术研究与系统实现[D]. 长春: 中国科学院大学, 2012: 48-53

    Jiang Man. 10Gbps/40Gbps optical fiber communication technology research and system implementation[D]. Changchun: University of Chinese Academy of Sciences, 2012: 48-53
