TT-1托卡马克装置垂直场电源大功率脉冲电感的研制

范文迪; 管锐; 张健; 黄懿赟

doi:10.11884/HPLPB202335.220393

TT-1托卡马克装置垂直场电源大功率脉冲电感的研制

doi: 10.11884/HPLPB202335.220393

范文迪^{1, 2,},
管锐^{2, 3},
张健^{2, 3},
黄懿赟^{2, 3, ,}

1.
安徽大学物质科学与信息技术研究院，合肥 230039
2.
中国科学院合肥物质科学研究院，等离子体物理研究所，合肥 230031
3.
中国科学技术大学科学岛分院，合肥 230026

基金项目: 中泰TT-1托卡马克装置重建项目（P640895）

详细信息

作者简介:
范文迪，wendi.fan@ipp.ac.cn

通讯作者:
黄懿赟，yyhuang@ipp.ac.cn

中图分类号: TL631.24
计量
- 文章访问数: 353
- HTML全文浏览量: 123
- PDF下载量: 54
- 被引次数: 0
出版历程
- 收稿日期: 2021-11-02
- 修回日期: 2023-03-28
- 录用日期: 2023-03-28
- 网络出版日期: 2023-04-03
- 刊出日期: 2023-05-06

Development of high-power pulse inductor for vertical field power supply of TT-1 device

Fan Wendi^{1, 2
,},
Guan Rui^{2, 3},
Zhang Jian^{2, 3},
Huang Yiyun^{2, 3
, ,}

1.
Institute of Physical Science and Information Technology, Anhui University, Hefei 230039, China
2.
Institute of Plasma Physics, Hefei Institutes of Physical Science, Chinese Academy of Sciences, Hefei 230031, China
3.
Science Island Branch, University of Science and Technology of China, Hefei 230026, China

摘要

摘要: 为满足等离子体放电需求，垂直场电源需串联脉冲电感来改变输出电流参数。针对TT-1装置垂直场电源对输出电流的要求，对脉冲电感进行了设计与研制。根据电感的运行工况及参数，通过感应系数法和累积温升法进行详细的数学分析和结构设计。基于理论设计，建立Ansys仿真模型对电感进行了磁场及温升的研究。最后完成电感的研制，根据电桥测量和实验波形，实际电感参数与理论分析高度吻合，并对电感进行大电流条件下的疲劳实验和温升实验，验证理论设计的可靠性。
- TT-1装置 /
- 脉冲电感 /
- 垂直场电源 /
- Ansys仿真
Abstract: To meet the demand of plasma discharge, pulse inductor should be connected to the vertical field power supply to change the output current parameters. To satisfy the need of the output current of the vertical field power supply of the TT-1 device, pulse inductor was designed and developed. According to the operating conditions and parameters of the inductor, the detailed mathematical analysis and structural design were carried out by the induction coefficient method and cumulative temperature rise method. Based on the theoretical design, an Ansys simulation model was established to study the magnetic field and temperature rise of the inductor. Finally, the inductor was developed. According to the bridge measurement and experimental waveform, the actual inductance parameters agree well with the theoretical analysis. The experiment of fatigue and temperature was carried out on the inductor under the condition of high current to verify the reliability of the theoretical design.
- TT-1 device /
- pulse inductor /
- vertical field power supply /
- Ansys simulation

HTML全文

图 1 垂直场电源电路拓扑图

Figure 1. Vertical field circuit topology

下载: 全尺寸图片幻灯片

图 2 脉冲电感电流仿真波形

Figure 2. Simulation waveform of pulse inductor current

下载: 全尺寸图片幻灯片

图 3 电感三种绕制方式

Figure 3. Three winding methods of inductor

下载: 全尺寸图片幻灯片

图 4 矩形导体线圈

Figure 4. Rectangular conductor coil

下载: 全尺寸图片幻灯片

图 5 电感的三维模型

Figure 5. Three dimensional model of inductor

下载: 全尺寸图片幻灯片

图 6 Maxwell仿真模型

Figure 6. Maxwell simulation model

下载: 全尺寸图片幻灯片

图 7 激励电路

Figure 7. Excitation circuit

下载: 全尺寸图片幻灯片

图 8 脉冲电感的磁场分布

Figure 8. Magnetic field distribution of pulse inductor

下载: 全尺寸图片幻灯片

图 9 脉冲电感的整体温升

Figure 9. Overall temperature rise of pulse inductor

下载: 全尺寸图片幻灯片

图 10 测试电路原理图

Figure 10. Schematic diagram of test circuit

下载: 全尺寸图片幻灯片

图 11 脉冲电源装置

Figure 11. Pulse power supply device

下载: 全尺寸图片幻灯片

图 12 通流实验电流波形图

Figure 12. Waveform diagram of pulse inductive current experiment

下载: 全尺寸图片幻灯片

图 13 温升实验最高温度位置

Figure 13. Maximum temperature position of pulse inductor temperature rise experiment

下载: 全尺寸图片幻灯片

表 1 TT-1装置垂直场电源参数

Table 1. Main working parameters of pulse inductor

coil inductance L_o/mH	coil resistance R_o/mΩ	pulse capacitors C_v/mF	charging voltage U_o/V	peak current I_p/kA	peak current time t_p/ms
8.4	67	3.6	9724	4.7	11

下载: 导出CSV

表 2 脉冲电感主要设计参数

Table 2. Main designing parameters of pulse inductor

work cycle/min	pulse discharge time/s	inductance/mH	withstand voltage/kV	maximum working voltage/V	maximum working current/A	DC resistance/mΩ	duty cycle
5	1	5.8	10	3961	4693	＜25	1/300

下载: 导出CSV

表 3 铝和铜材料性能对比

Table 3. Comparison of properties between aluminum and copper

	atomic weight	density/ (kg·m⁻³)	resistivity/ (nΩ·m)	resistance temperature coefficient/ (nΩ·m⁻¹·K⁻¹)	tensile strength/ MPa	positive modulus of elasticity/ GPa	linear expansion coefficient/ (10⁻⁶K⁻¹)	specific heat capacity/ (J·kg·⁻¹·K⁻¹)	thermal conductivity/ (W·m⁻¹·K⁻¹)
aluminum	36.98	2700	28.3	0.1	150～200	63	23	900	231
copper	63.54	8890	17.77	0.09525	350～470	120	17	392	436

下载: 导出CSV
