An all-metal beam scanning lens antenna for high-power microwave applications
-
摘要: 提出了一种基于Risley棱镜原理的新型圆极化全金属超透镜波束扫描天线，旨在解决高功率微波天线领域的大角度波束扫描和高功率容量难题。通过在六边形透镜单元中引入圆形缝隙及超材料结构，实现了该单元在中心频点处超过99%的圆极化正交转化效率（表征入射左旋/右旋圆极化波向右旋/左旋圆极化的转化效率）及0～360°连续相位调控。单元组阵后，两层透镜与径向线枝节缝隙馈源共同构成了波束扫描天线。其中第一层透镜将馈源辐射的圆极化空心波束转换为实心波束，并实现25.66°波束偏转，第二层透镜将该偏转波束进行二次偏转，独立转动两层透镜可以实现±60°锥角内的二维波束扫描。仿真设计了工作在14.25 GHz、轴向长度为5.6λ的波束扫描透镜天线，扫描过程中增益变化范围为34.7～37.9 dB，反射系数始终低于−25 dB，最大口径效率超过79%。单个透镜单元功率容量为0.63 MW，天线整体功率容量超过1 GW，具有应用在高功率微波领域的潜力。Abstract:
Background With the advancement of high-power microwave (HPM) technology, there is a growing demand for HPM antennas with beam scanning capabilities.Purpose This paper focuses on the beam-scanning technology in HPM field and proposes a novel circularly-polarized all-metal beam-scanning lens antenna based on the Risley-prism principle, aiming to address the challenges of wide-angle beam scanning and high power handling capacity (PHC).Methods By introducing circular slots and metamaterial structures into hexagonal units, a circular polarization orthogonal conversion efficiency(the conversion efficiency of incident left-hand/right-hand circularly polarized (LHCP/RHCP) waves to their orthogonal RHCP/LHCP waves) of over 99% at the central frequency and a continuous phase tuning range of 0° to 360° are achieved. After arraying, the two-layer lens, together with the radial line slot array (RLSA) antenna, constitutes the beam scanning antenna system. Specifically, the first lens converts the circularly polarized hollow beam radiated by the feed antenna into a solid beam while achieving a 25.66° beam deflection synchronously. The second lens further deflects the beam, and two-dimensional beam scanning within a conical angle of ±60° can be realized by independently rotating the two layers of lenses.Results A beam scanning lens antenna operating at 14.25 GHz with an axial length of 5.6λ is designed and simulated. During the scanning process, the gain varies within the range of 34.7–37.9 dB, the reflection coefficient remains consistently below −25 dB, and the maximum aperture efficiency exceeds 79%, with the PHC of the beam scanning antenna exceeds 1 GW.Conclusions The antenna proposed in this paper exhibits excellent beam scanning performance and high PHC, demonstrating great potential for applications in the HPM field. -
图 6 扫描角度与单元边长的限制关系
Figure 6. Limiting relationship between scanning angle and unit side length
图 11 馈源天线+一层透镜结构模型与远场性能
Figure 11. Structure model and far-field pattern of feed antenna
图 12 馈源天线+两层透镜三维方向图
Figure 12. 3D far-field radiation pattern of feed antenna with two lens
表 1 两种单元结构参数
Table 1. Structure parameters of two kinds of units
parameters f/GHz a/mm r/mm h/mm l1/mm w1/mm r1/mm l2/mm w2/mm r2/mm cham/mm unit#1 14.25 6.26 4.86 11.58 4.54 4.35 1.60 2.33 1.83 0.60 0.30 unit#2 14.25 6.64 5.22 11.21 4.87 4.84 2.00 2.28 2.02 0.30 0.30
下载: 导出CSV
表 2 波束扫描透镜天线性能
Table 2. Performance of beam scanning lens antenna
case θ/(°) gain/dB reflection coefficient/dB aperture efficiency/% axial ratio/dB sidelobe/dB 1 0 37.9 −31.3 79.5 2.216 −16.9 2 19.3 37.5 −36.9 72.6 0.309 −16.8 3 37.8 36.6 −38.9 58.9 0.583 −16.9 4 53.1 35.5 −35.6 45.8 4.456 −16.3 5 60 34.7 −27.8 38.1 8.411 −12.1
下载: 导出CSV
-
