Experimental investigation on multi-channel discharge formation in self-breakdown switch for 10 MA pulsed power device
-
摘要: 针对10 MA脉冲功率装置中采用的水介质三电极板-球结构自击穿开关，研究了开关击穿时电极电压变化情况和放电多通道形成的判据。根据开关的具体结构，理论分析了特征时间常数和电极多通道间的距离等因素对开关多通道形成的影响，计算得出多通道形成判据左侧项为8.6 ns，大于两倍开关抖动时间6 ns，满足判据要求。实验验证了开关在3 MV击穿电压下，3对电极的放电电弧在约30 ns时间内同时从球电极产生并发展到板电极。Abstract:
Background Water-dielectric self-breakdown switches are critical components in pulsed power devices such as the 10 MA facility. The plate-sphere electrode structure is specifically designed to achieve simultaneous multi-channel discharge, which is essential for minimizing switch inductance and reducing timing jitter.Purpose This study investigates the factors affecting multi-channel formation in a water-dielectric, three-electrode plate-sphere self-breakdown switch operating at 3 MV, with the aim of validating the theoretical formation criterion.Methods Theoretical analysis was conducted based on the specific parameters of the switch structure, focusing on key temporal characteristics influencing discharge behavior. Experimental validation was performed at the nominal breakdown voltage of 3 MV, utilizing diagnostic techniques to observe the development of discharge arcs across all electrode pairs.Results The calculated characteristic value for multi-channel formation was determined to be 8.6 ns, exceeding twice the measured switch jitter time of 3 ns, thereby satisfying the theoretical criterion. Observations confirmed that discharge arcs initiated nearly synchronously at the three sphere electrodes and propagated toward the plate electrodes, with complete multi-channel formation achieved within approximately 30 ns.Conclusions The study validates the criterion for multi-channel discharge in the plate-sphere switch structure. The design effectively enables simultaneous formation of multiple discharge channels within tens of nanoseconds, meeting essential requirements for high-performance pulsed power devices and contributing to improved operational stability. -
[1] Weinbrecht E A, Bloomquist D D, McDaniel D H, et al. Status of the Z refurbishment project (ZR) at sandia national laboratories[C]//Proceedings of 2005 IEEE Pulsed Power Conference. 2005: 170-173. [2] Struve K W, Harjes H C, Corley J P. Circuit model predictions for the performance of ZR[C]//Proceedings of the 2007 IEEE 34th International Conference on Plasma Science. 2007: 639. [3] Corcoran P A, Whitney B A, Bailey V L, et al. Circuit modeling techniques applied to ZR[C]//Proceedings of 2009 IEEE Pulsed Power Conference. 2009: 150-155. [4] Savage M E, Austin K N, Coffey S K, et al. Considerations for improvements to the 25 TW Saturn high-current driver[C]//Proceedings of 2019 IEEE Pulsed Power & Plasma Science. 2019: 1-5. [5] Struve K, Ulmen B. Three-dimensional model of the SATURN accelerator water tri-plate transmission line connection to the vacuum insulator stack[C]//Proceedings of 2019 IEEE Pulsed Power & Plasma Science. 2019: 1-4. [6] 李洪涛, 王玉娟, 丰树平, 等. 4 MV激光触发多级多通道开关特性[J]. 强激光与粒子束, 2007, 19(11): 1923-1926Li Hongtao, Wang Yujuan, Feng Shuping, et al. Switching property of 4 MV laser-triggered multistage switch[J]. High Power Laser and Particle Beams, 2007, 19(11): 1923-1926 [7] 夏明鹤, 孟维涛, 丰树平, 等. 同轴-三平板型水介质脉冲输出开关实验研究[J]. 强激光与粒子束, 2007, 19(8): 1404-1408Xia Minghe, Meng Weitao, Feng Shuping, et al. Investigation of coaxial-triplate water dielectric output switch[J]. High Power Laser and Particle Beams, 2007, 19(8): 1404-1408 [8] 夏明鹤, 谢卫平, 李洪涛, 等. 低预脉冲水介质多通道自击穿开关实验研究[J]. 强激光与粒子束, 2006, 18(8): 1363-1366Xia Minghe, Xie Weiping, Li Hongtao, et al. Investigation of a low prepulse multi-channel self-breaking water switch[J]. High Power Laser and Particle Beams, 2006, 18(8): 1363-1366 [9] 夏明鹤, 谢卫平, 李洪涛, 等. 多通道自击穿水开关测试方法研究[J]. 强激光与粒子束, 2005, 17(11): 1744-1748Xia Minghe, Xie Weiping, Li Hongtao, et al. Test methods of multi-channel water self-breaking switch[J]. High Power Laser and Particle Beams, 2005, 17(11): 1744-1748 [10] 夏明鹤, 卫兵, 王玉娟, 等. 水介质自击穿开关放电参数测试[J]. 强激光与粒子束, 2006, 18(1): 151-154Xia Minghe, Wei Bing, Wang Yujuan, et al. Discharge parameters test of water self-breaking switch[J]. High Power Laser and Particle Beams, 2006, 18(1): 151-154 [11] 关永超, 王勐, 丰树平, 等. 高功率低阻抗三平板传输线的设计[J]. 强激光与粒子束, 2010, 22(3): 519-523 doi: 10.3788/HPLPB20102203.0519Guan Yongchao, Wang Meng, Feng Shuping, et al. Design for high power and low impedance triplate transmission line[J]. High Power Laser and Particle Beams, 2010, 22(3): 519-523 doi: 10.3788/HPLPB20102203.0519 [12] 夏明鹤, 王勐, 王玉娟, 等. 4 MV同轴-三平板型水介质自击穿开关设计[J]. 强激光与粒子束, 2006, 18(3): 496-500Xia Minghe, Wang Meng, Wang Yujuan, et al. Design of 4 MV coaxial-triplate water pulse forming line switch[J]. High Power Laser and Particle Beams, 2006, 18(3): 496-500 [13] Rosenthal S E, Pointon T D, Elizondo J M, et al. Investigating the electromagnetic structure of the coax-to-triplate transition for the pulse-compression section of the ZR accelerator[C]//Proceedings of the 14th IEEE International Pulsed Power Conference. 2003: 626-629. [14] Struve K W, Corley J P, Johnson D L, et al. Design options for a pulsed-power upgrade of the Z accelerator[C]//Proceedings of the 28th IEEE International Conference on Plasma Science and 13th IEEE International Pulsed Power Conference. 2001: 569-572. [15] 刘锡三. 高功率脉冲技术[M]. 北京: 国防工业出版社, 2005: 360-367Liu Xisan. High pulsed power technology[M]. Beijing: National Defense Industry Press, 2005: 360-367 [16] 曾正中. 实用脉冲功率技术引论[M]. 西安: 陕西科学技术出版社, 2003: 67-69Zeng Zhengzhong. Introduction to practical pulsed power technology[M]. Xi’an: Shaanxi Science and Technology Press, 2003: 67-69 -
