低阻抗嵌套型双环电子束二极管的粒子模拟研究

杨温渊 任晓东 孙会芳 薛碧曦 董烨 杨郁林

杨温渊, 任晓东, 孙会芳, 等. 低阻抗嵌套型双环电子束二极管的粒子模拟研究[J]. 强激光与粒子束. doi: 10.11884/HPLPB202638.250361
引用本文: 杨温渊, 任晓东, 孙会芳, 等. 低阻抗嵌套型双环电子束二极管的粒子模拟研究[J]. 强激光与粒子束. doi: 10.11884/HPLPB202638.250361
Yang Wenyuan, Ren Xiaodong, Sun Huifang, et al. Particle simulation studies of low impedance nested double-ring electron beam diodes[J]. High Power Laser and Particle Beams. doi: 10.11884/HPLPB202638.250361
Citation: Yang Wenyuan, Ren Xiaodong, Sun Huifang, et al. Particle simulation studies of low impedance nested double-ring electron beam diodes[J]. High Power Laser and Particle Beams. doi: 10.11884/HPLPB202638.250361

低阻抗嵌套型双环电子束二极管的粒子模拟研究

doi: 10.11884/HPLPB202638.250361
基金项目: 国家自然科学青年基金项目(12305218)
详细信息
    作者简介:

    杨温渊,yang_wenyuan@iapcm.ac.cn

    通讯作者:

    薛碧曦,xue_bx@163.com

  • 中图分类号: TL503;TL501

Particle simulation studies of low impedance nested double-ring electron beam diodes

  • 摘要: 低阻抗嵌套型双环电子束二极管是一种自磁绝缘二极管。本文采用全电磁粒子模拟程序对低阻抗嵌套型双环二极管中电子束的产生和传输特性进行了较为细致的数值模拟,重点考查了电压脉冲上升过程中电子束传输特性的演化情况,并对二极管的物理特性和运行规律进行了物理分析和总结。通过数值模拟,给出了二极管中电场和角向自磁场空间分布、电子在实空间和相空间的分布、阳极靶面电子数能谱、电子落点和入射角分布等典型物理图像;给出了结构参数固定的情况下二极管电压波形和纵向间距的变化对二极管阻抗、电流以及电子束运行轨迹等的影响规律,加深了对二极管工作过程和物理特性的理解,同时可为后续利用蒙特卡罗(MC)程序计算电子轫致辐射产生的X射线剂量和辐射场的空间分布等提供电子源输入参数。当二极管电压峰值为1.5 MV时,模拟得到了到靶电流强度约为2.47 MA,阻抗约为0.6 Ω的电子束,二极管中自磁场的最大强度达到了1.7 T。
  • 图  1  低阻抗嵌套型双环电子束二极管的基本结构,rz截面

    Figure  1.  Schematic drawings of the nested double-ring electron beam diode, rz cross section

    图  2  注入电压的归一化时间波形图

    Figure  2.  Normalized time waveform of the input voltage

    图  3  打在阳极2侧壁的电子电流随时间变化图,图上方1、2、3和4标注了4个不同的时间段

    Figure  3.  Time plot of the beam current on the side wall of anode 2.And 4 different time periods 1, 2, 3 and 4 are marked at top

    图  4  对应图3中1、2、3和4时间段中某一时刻的电子实空间相位图

    Figure  4.  The real space plots of electrons at given times during the time periods 1, 2, 3, and 4 marked in Fig.3

    图  5  靶面电流强度随时间的变化曲线

    Figure  5.  Time plots of the beam current on the anode target surface

    图  6  二极管阻抗随时间的变化曲线

    Figure  6.  Time plots of the diode impedance

    图  7  电压达到稳定时二极管中电场的等高图,t=80.166 ns

    Figure  7.  Contour plots of electric field in the diode at t=80.166 ns

    图  8  二极管中不同位置角向自绝缘磁场随时间的变化曲线

    Figure  8.  Time plots of the angular self-insulating magnetic field at different positions in the double-ring diode

    图  9  电压达到稳定时二极管中角向自绝缘磁场等高图,t=80.166 ns

    Figure  9.  The contour plot of the angular self-insulating magnetic field in the double-ring diode when the voltage reaches stable, t=80.166 ns

    图  10  不同时刻外环阴极发射的电子束轨迹图

    Figure  10.  Trajectories of electron beams emitted from the outer ring cathode at different times

    图  11  不同时刻靶面电子数随能量和位置变化的等高图

    Figure  11.  Contour plot of electron number on target as a function of the energy and position at different times

    图  12  电压达到稳定后某一时段阳极靶面电子数能谱、电子落点和入射角分布图,Δt≈0.5 ns,t0 = 80.166 ns

    Figure  12.  The electron number energy spectrum, electron impact point and incident angle distribution on the target surface at a certain period of time when the voltage reaches stable, Δt≈0.5 ns,t0 = 80.166 ns

    图  13  稳定时二极管阻抗和电流随二极管峰值电压的变化曲线,纵向间距为6 mm

    Figure  13.  Time plots of the diode impedance and current as a function of the diode peak voltage at stable state with the axial gap length of 6 mm

    图  14  不同二极管峰值电压下,打在阳极2侧壁的电子电流随时间变化图,曲线1、2和3分别代表峰值电压为1.0 MV,1.5 MV和2.0 MV,纵向间距为6 mm

    Figure  14.  Time plots of the electron current on the side wall of anode 2 under different peak diode voltages with the axial gap length of 6mm, curves 1, 2 and 3 stands for 1.0 MV, 1.5 MV and 2.0 MV respectively

    图  15  稳定时二极管阻抗和电流随二极管纵向间距的变化曲线,峰值电压为1.5 MV

    Figure  15.  Variation of the diode impedance and current as a function of the axial gap length at stable state,the peak voltage is 1.5 MV

    图  16  不同二极管纵向间距时,打在阳极2侧壁的电子电流随时间变化图,曲线1和2分别代表纵向间距为6 mm和5 mm,峰值电压为1.5 MV

    Figure  16.  Time plots of the electron current on the side wall of anode 2 with the peak voltage is 1.5 MV, curves 1 and 2 stands for the axial gap length of 6mm and 5mm respectively
