Numerical simulation study on refractive index regulation characteristics and coupling transmission of all-solid anti-resonant fiber
-
摘要: 1 μm 波段高功率掺镱光纤激光器在激光加工、生物医疗及国防安全等领域应用广泛，然而，随着输出功率持续提升，传统大纤芯光纤易受模式不稳定与受激拉曼散射等非线性效应影响。全固态反谐振石英光纤（AS-ARF）基于其独特的反谐振导光机理，可在实现超大模场传输的同时抑制高阶模，为兼顾高功率与高光束质量提供了创新技术路径。然而，面向高功率增益应用的有源掺镱（Yb）AS-ARF，其纤芯折射率起伏对模式特性的影响机制及“阶跃光纤-AS-ARF”熔接传输特性尚未得到系统研究，制约了实用化进程。针对上述问题，通过构建六环结构AS-ARF模型，结合理论推导与数值仿真模拟，研究了折射率起伏对光纤导光特性的影响，明确了维持原有导光机制的折射率变化临界值，验证了该光纤在目标波长下的低损耗、大模场面积及良好的光束质量保持能力；同时探究了阶跃光纤与AS-ARF熔接耦合场景的光传输规律，仿真结果表明当入射光束直径与AS-ARF纤芯直径匹配时，传输能量衰减<2%。本研究实现了对有源AS-ARF核心调控参数的量化，为Yb3+-AS-ARF的制备工艺优化（重点关注折射率均匀性控制）及实际耦合方案的设计提供了理论基础。Abstract:
Background High-power Yb-doped fiber lasers operating in the 1 μm band have been widely applied in fields such as laser processing, biomedicine, and national defense security. However, with the continuous increase in output power, traditional large-core fibers are susceptible to transverse mode instability (TMI) and stimulated Raman scattering (SRS), among other nonlinear effects. Based on their unique anti-resonant light-guiding mechanism, all-solid anti-resonant silica fibers (AS-ARFs) can realize ultra-large mode area (LMA) propagation while suppressing higher-order modes (HOMs), thus providing an innovative technical approach for balancing high power and high beam quality. Nevertheless, for active Yb-doped AS-ARFs targeting high-power gain applications, the influence mechanism of core refractive index fluctuations on mode characteristics and the fusion-splicing transmission characteristics of “step-index fiber - AS-ARF” structures have not been systematically investigated, which restricts their practical application process.Purpose To address the above problems, this study aims to clarify the critical value of refractive index variation for maintaining the original light-guiding mechanism of AS-ARFs, verify their capabilities of low loss, large mode area and beam quality maintenance, explore the fusion-splicing coupling transmission laws between SIFs and AS-ARFs, quantify the core control parameters of active AS-ARFs, and provide theoretical support for their fabrication process optimization and coupling scheme design.Methods A six-ring AS-ARF theoretical model was constructed, combined with theoretical derivation and numerical simulation: Comsol Multiphysics was used to analyze the mode characteristics and the influence of refractive index fluctuations, and the Rsoft-BeamPROP module (based on the beam propagation method) was adopted to simulate the light transmission laws in the fusion-splicing coupling scenario.Results The critical value of refractive index variation was clarified; the designed AS-ARFs were verified to have the characteristics of low loss, large mode area and excellent beam quality at the target wavelength; the fusion-splicing coupling transmission laws were revealed, and the transmitted energy attenuation was less than 2% when the incident beam diameter matched the core diameter of AS-ARFs.Conclusions This study realizes the quantification of core control parameters for active AS-ARFs, laying an important theoretical foundation for the fabrication process optimization of Yb3+-doped AS-ARFs (with a focus on refractive index uniformity control) and the design of practical coupling schemes. -
图 2 Comsol仿真理论模型示意图
Figure 2. Schematic diagram of COMSOL simulation theoretical model
图 3 “阶跃光纤-AS-ARF”熔接耦合模型示意图
Figure 3. Schematic diagram of fusion coupling model of “step fiber-AS-ARF”
图 4 基模限制损耗曲线以及在谐振波长和反谐振波长下的基模模式分布
Figure 4. FM CL curve and distribution of FM modes at resonant and anti resonant wavelengths
图 5 折射率起伏Δn在-1×10−4～2×10−4范围内的基模限制损耗曲线(FM CL)、高阶模抑制比（HOMLR）曲线及典型Δn值下的模式仿真
Figure 5. Fundamental Mode Confinement Loss (FM CL) curves, Higher-Order Mode Suppression Ratio (HOMLR) curves in the range of refractive index fluctuation Δn from -1×10−4 to 2×10−4 and mode simulation results under typical Δn values
图 6 入射光直径为20 μm时AS-ARF的xoz截面能量分布及纤芯能量沿z轴强度曲线的传播仿真
Figure 6. Simulated propagation of the xoz cross-sectional energy distribution and the core energy intensity curve along the z-axis of AS-ARF at an incident light diameter of 20 μm
图 7 不同入射光直径（DL）下AS-ARF纤芯能量沿 z 轴强度曲线、xOz 截面能量分布、xOy 截面纤芯能量分布及入射光直径 140 μm 时的传播特性仿真
Figure 7. Simulations of the core energy intensity curves along the z-axis, xOz cross-sectional energy distribution, xoy cross-sectional core energy distribution of AS-ARF under different incident light diameters (DL), and the propagation characteristics at an incident DL of 140 μm
表 1 理论模型仿真参数
Table 1. Theoretical model simulation parameters
Parameter Value/μm D 290 dco 100 dac 50 dcl 68 t 1.2 n1 1.467 n0 1.4502
