中国聚变工程试验堆360°全堆建模与初步核分析

伍秋染; 杜华; 郑俞; 卢棚; 刘松林

doi:10.11884/HPLPB202234.210364

中国聚变工程试验堆360°全堆建模与初步核分析

doi: 10.11884/HPLPB202234.210364

伍秋染^{1, 2,},
杜华^{1, 2},
郑俞^{1, 2},
卢棚^{1, 3, ,},
刘松林¹

1.
中国科学院合肥物质科学研究院等离子体物理研究所, 合肥 230031
2.
中国科学技术大学, 合肥 230026
3.
合肥综合性国家科学中心能源研究院(安徽省能源实验室), 合肥 230026)

基金项目: 国家磁约束聚变能专项（2019YFE03110000, 2019YFE03110002）；国家自然科学基金青年项目（12005145）

详细信息

作者简介:
伍秋染，qiuran.wu@ipp.ac.cn

通讯作者:
卢　棚，peng.lu@ipp.ac.cn

中图分类号: TL61；TL64
计量
- 文章访问数: 801
- HTML全文浏览量: 261
- PDF下载量: 54
- 被引次数: 0
出版历程
- 收稿日期: 2021-08-24
- 修回日期: 2021-12-17
- 网络出版日期: 2021-12-30
- 刊出日期: 2022-01-11

Neutronics modeling of 360° China Fusion Engineering Test Reactor and preliminary nuclear analysis

Wu Qiuran^{1, 2
,},
Du Hua^{1, 2},
Zheng Yu^{1, 2},
Lu Peng^{1, 3
, ,},
Liu Songlin¹

1.
Institute of Plasma Physics, Hefei Institutes of Physical Science, Chinese Academy of Sciences, Hefei 230031, China
2.
University of Science and Technology of China, Hefei 230026, China
3.
Institute of Energy, Hefei Comprehensive National Science Center （Anhui Energy Laboratory, Hefei 230026, China

摘要

摘要: 基于自动化建模软件平台cosVMPT的发展，建立了包含厂房结构的中国聚变工程试验堆（CFETR） 360°全堆模型，主要结构包括中心螺线管线圈、真空室、纵场线圈、极向场线圈、内外冷屏、杜瓦，以及精细结构的水冷包层和偏滤器。空间布置上包括16个上/下窗口和6个中窗口，2个斜窗口作为NBI束通道，其余窗口内设为屏蔽块。引入“on-the-fly”（OTF）全局减方差方法以获得可靠的中子、光子通量，结果显示其在厂房内的分布不对称。验证了cosVMPT平台和OTF方法的可靠性，并与扇段模型所获得的结果进行对比，进一步确认能够通过扇段模型来简化建模计算过程的使用范围。
- CFETR /
- 360°全堆模型 /
- cosVMPT /
- OTF方法 /
- 中子学
Abstract: With the support of the modelling conversion platform cosVMPT, the 360° model is needed to solve this inaccuracy from asymmetry. The detailed structure of all main components for China Fusion Engineering Test Reactor (CFETR) has been developed. The whole model consists of Central Solenoid (CS), Vacuum Vessel (VV), Port (16 upper/lower ports, 6 equatorial ports in which 2 oblique are ones used for NBI beam channel), Thermal Shielding (VVTS & CTS), Toroidal and Poloidal Field Coils (TFC & PFC), Cryostat and the House Building. The water-cooled ceramic breeder (WCCB) blanket and water cooled divertor with full detailed structure is inserted, while spare ports are filled with shielding material. The preliminary calculation has been performed by MCNP code combining with the advanced “on-the-fly” GVR method, which was introduced to generate the global weight window to accelerate the neutron transport, and the reliable neutron and photon flux map was obtained. This work realizes the application of cosVMPT platform and OTF method in complicated fusion reactor, and it validates their robustness. In addition, the results of 360° model has been compared to that of sector model, to verify the validity and applicability of using sector model to simplify the modelling and calculation.
- CFETR /
- 360° model /
- cosVMPT /
- on-the-fly method /
- neutronics

HTML全文

图 1 CFETR 几何模型

Figure 1. Model of CFETR geometry

下载: 全尺寸图片幻灯片

图 2 建模流程

Figure 2. Process of modelling

下载: 全尺寸图片幻灯片

图 3 模型预处

Figure 3. Pre-processing of modelling

下载: 全尺寸图片幻灯片

图 4 cosVMPT 平台界面

Figure 4. Platform of cosVMPT

下载: 全尺寸图片幻灯片

图 5 CFETR 360°全堆中子学模型

Figure 5. Neutronics model of 360° CFETR

下载: 全尺寸图片幻灯片

图 6 原始CAD模型与中子学模型体积相对偏差

Figure 6. Relative difference between volume of CAD model and neutronics model

下载: 全尺寸图片幻灯片

图 7 CFETR 主机三维中子通量分布

Figure 7. Neutron flux distribution for 3D CFETR main machine

下载: 全尺寸图片幻灯片

图 8 中子、光子通量及误差分布

Figure 8. Neutron/photon flux and relative error distribution

下载: 全尺寸图片幻灯片

图 9 含 NBI 系统的 112.5° CFETR 中子通量分布

Figure 9. Neutron flux distribution for 112.5° model with 2 sets of NBI systems

下载: 全尺寸图片幻灯片

表 1 主要部件的中子/光子通量及误差

Table 1. Neutron/photon flux of main components and their relative error

component	position (x, y, z)/cm	neutron flux/ (cm⁻²·s⁻¹)	neutron flux relative error/%	photon flux/ (cm⁻²·s⁻¹)	photon flux relative error/%
blanket	(980.0, −14.5, 15.0)	3.19E+14	0.15	1.19E+14	0.28
divertor	(580.0, −14.5, −465.0)	1.75E+14	0.16	7.80E+13	0.28
vacuum vessel	(1 220.0, −14.5, 15.0)	3.65E+12	0.54	1.91E+12	0.63
center solenoid coil	(140.0, −14.5, 15.0)	9.58E+03	9.28	1.19E+04	4.01
poloidal field coil	(1 500.0, −14.5, 295.0)	4.28E+08	6.67	1.85E+08	9.10
toroidal field coil	(1 340.0, 219.5, 15.0)	3.92E+08	2.75	1.16E+08	3.03
cryostat	(1 860.0, −14.5, 15.0)	1.95E+08	1.35	5.30E+07	3.44
bio-shielding (in)	(2 100.0, −14.5, 15.0)	3.11E+05	6.66	3.55E+05	7.46
bio-shielding (out)	(5 217.5, −14.5, 15.0)	1.28E+05	7.43	2.64E+05	3.26

下载: 导出CSV
