LD端面泵浦Tm:SrF2电光调Q激光器

吴广 张振 王韬 季来林 崔勇 高妍琦 隋展

吴广, 张振, 王韬, 等. LD端面泵浦Tm:SrF2电光调Q激光器[J]. 强激光与粒子束, 2024, 36: 061005. doi: 10.11884/HPLPB202436.230140
引用本文: 吴广, 张振, 王韬, 等. LD端面泵浦Tm:SrF2电光调Q激光器[J]. 强激光与粒子束, 2024, 36: 061005. doi: 10.11884/HPLPB202436.230140
Wu Guang, Zhang Zhen, Wang Tao, et al. Laser-diode end-pumped electro-optic Q-switched Tm:SrF2 laser[J]. High Power Laser and Particle Beams, 2024, 36: 061005. doi: 10.11884/HPLPB202436.230140
Citation: Wu Guang, Zhang Zhen, Wang Tao, et al. Laser-diode end-pumped electro-optic Q-switched Tm:SrF2 laser[J]. High Power Laser and Particle Beams, 2024, 36: 061005. doi: 10.11884/HPLPB202436.230140

LD端面泵浦Tm:SrF2电光调Q激光器

doi: 10.11884/HPLPB202436.230140
详细信息
    作者简介:

    吴 广,wg1553480@163.com

    通讯作者:

    季来林,jsycjll@siom.ac.cn

    高妍琦,liufenggyq@siom.ac.cn

  • 中图分类号: TN248.1

Laser-diode end-pumped electro-optic Q-switched Tm:SrF2 laser

  • 摘要: 高掺杂浓度的Tm3+增益介质能通过交叉弛豫过程提高激光器的量子效率,但同时也会增加能量上转换带来的损耗,从而限制激光器效率的进一步提升。对Tm:SrF2晶体的荧光特性以及激光性能展开研究。在激光二极管(LD)端面泵浦下,实现最大功率2.99 W的自由运转输出,激光器的泵浦阈值为0.89 W,中心波长1851 nm,斜效率高达82.1%。采用KTP电光调Q开关演示了Tm:SrF2激光器的电光调Q输出特性。在500 Hz重复频率下,获得了1.02 mJ的最大单脉冲能量,泵浦阈值为2.01 W,最短脉冲宽度为45 ns,对应峰值功率为22.67 kW。实验结果表明,基于LD泵浦的Tm:SrF2激光器具有非常高的效率,有望成为中红外光学参量振荡器(OPO)和光学参量放大器(OPA)的理想泵浦源。
  • 图  1  Tm:SrF2晶体荧光特性

    Figure  1.  Fluorescence characteristics of Tm:SrF2 crystal

    图  2  Tm:SrF2电光调Q激光器装置图

    Figure  2.  Schematic diagram of electro-optical Q-switched Tm:SrF2 laser

    图  3  谐振腔不同位置处的横模光斑半径

    Figure  3.  Transverse mode spot radius at different positions of the resonant cavity

    图  4  激光器脉冲宽度与腔长的关系

    Figure  4.  Relationship between laser pulse width and cavity length

    图  5  Tm:SrF2激光器自由运转输出特性

    Figure  5.  Output characteristics of free running Tm:SrF2 laser

    图  6  Tm:SrF2激光器电光调Q输出特性

    Figure  6.  Output characteristics of electro-optic Q-switched Tm:SrF2 laser

    表  1  掺Tm块状晶体的激光性能

    Table  1.   Laser performance of Tm-doped bulk crystals

    material doping concentration/% output power/W slope efficiency/% photon quantum efficiency reference
    Tm:YAG 3.5 25.40 41.2 1.05 [6]
    Tm:YAP 3.0 6.35 60.4 1.51 [7]
    Tm:YLF 2.5 8.50 53.4 1.23 [8]
    Tm:LuAG 3.5 3.70 54.6 1.39 [9]
    Tm:SrF2 5.2 0.24 50.0 1.28 [10]
    Tm:CaF2 3.0 2.71 70.3 1.68 [18]
    Tm:SrF2 2.0 2.99 82.1 1.92 this paper
    下载: 导出CSV
  • [1] Fried N M. Recent advances in infrared laser lithotripsy [Invited][J]. Biomedical Optics Express, 2018, 9(9): 4552-4568. doi: 10.1364/BOE.9.004552
    [2] Henderson S W, Suni P J M, Hale C P, et al. Coherent laser radar at 2 μm using solid-state lasers[J]. IEEE Transactions on Geoscience and Remote Sensing, 1993, 31(1): 4-15. doi: 10.1109/36.210439
    [3] Targ R, Steakley B C, Hawley J G, et al. Coherent lidar airborne wind sensor II: flight-test results at 2 and 10 μm[J]. Applied Optics, 1996, 35(36): 7117-7127. doi: 10.1364/AO.35.007117
    [4] Leindecker N, Marandi A, Byer R L, et al. Octave-spanning ultrafast OPO with 2.6-6.1µm instantaneous bandwidth pumped by femtosecond Tm-fiber laser[J]. Optics Express, 2012, 20(7): 7046-7053. doi: 10.1364/OE.20.007046
    [5] Lippert E, Fonnum H, Arisholm G, et al. A 22-watt mid-infrared optical parametric oscillator with V-shaped 3-mirror ring resonator[J]. Optics Express, 2010, 18(25): 26475-26483. doi: 10.1364/OE.18.026475
    [6] Jin Lin, Liu Pian, Huang Haitao, et al. High average power of Q-switched Tm: YAG slab laser[J]. Optics Communications, 2016, 372: 241-244. doi: 10.1016/j.optcom.2016.04.026
    [7] Kwiatkowski J. Power and spectral analyses in diode-pumped c-cut Pbnm Tm: YAP laser[J]. Chinese Optics Letters, 2020, 18: 091401. doi: 10.3788/COL202018.091401
    [8] Na Quanxin, Xu Changwen, Huang Zhiyang, et al. High-power and high-efficiency short wavelength operation of a Tm: YLF laser at 1.83 μm[J]. Optics Letters, 2019, 44(17): 4403-4406. doi: 10.1364/OL.44.004403
    [9] Li Shutao, Niu C, Wen Y, et al. Laser characteristics of LD end-pumped CW and Q-switched Tm: LuYAG laser[J]. Infrared Physics & Technology, 2020, 111: 103559.
    [10] Sottile A, Damiano E, Rabe M, et al. Widely tunable, efficient 2 µm laser in monocrystalline Tm3+: SrF2[J]. Optics Express, 2018, 26(5): 5368-5380. doi: 10.1364/OE.26.005368
    [11] Berthomé Q, Grisard A, Faure B, et al. Actively Q-switched tunable single-longitudinal-mode 2 µm Tm: YAP laser using a transversally chirped volume Bragg grating[J]. Optics Express, 2020, 28(4): 5013-5021. doi: 10.1364/OE.384499
    [12] Liu Jian, Dong Jifei, Wang Yinyin, et al. Tm: YAG single-crystal fiber laser[J]. Optics Letters, 2021, 46(18): 4454-4457. doi: 10.1364/OL.434618
    [13] Shaw L B, Chang R S F, Djeu N. Measurement of up-conversion energy-transfer probabilities in Ho: Y3A15O12 and Tm: Y3A15O12[J]. Physical Review B, 1994, 50(10): 6609-6619. doi: 10.1103/PhysRevB.50.6609
    [14] Zhang Zhen, Guo Xinsheng, Wang Jingya, et al. High-efficiency 2 μm continuous-wave laser in laser diode-pumped Tm3+, La3+: CaF2 single crystal[J]. Optics Letters, 2018, 43(17): 4300-4303. doi: 10.1364/OL.43.004300
    [15] Ma Fengkai, Su Fang, Zhou Rongfu, et al. The defect aggregation of RE3+ (RE = Y, La ~ Lu) in MF2 (M = Ca, Sr, Ba) fluorites[J]. Materials Research Bulletin, 2020, 125: 110788. doi: 10.1016/j.materresbull.2020.110788
    [16] Doualan J L, Camy P, Moncorgé R, et al. Latest developments of bulk crystals and thin films of rare-earth doped CaF2 for laser applications[J]. Journal of Fluorine Chemistry, 2007, 128(4): 459-464. doi: 10.1016/j.jfluchem.2006.12.017
    [17] Liu Jingjing, Zhang Cheng, Zhang Zhen, et al. 1886-nm mode-locked and wavelength tunable Tm-doped CaF2 lasers[J]. Optics Letters, 2019, 44(1): 134-137. doi: 10.1364/OL.44.000134
    [18] Wang Yangxiao, Liu Wenxin, Zhang Zhonghan, et al. Laser-diode-pumped Tm: SrF2 single crystal for high efficiency CW laser operation at ~2 µm[J]. Optics Letters, 2022, 47(5): 1117-1120. doi: 10.1364/OL.449484
    [19] Liu Wenxin, Zu Yuqian, Wang Yangxiao, et al. Active Q-switching operation of a Tm: SrF2 single crystal fiber laser near 2 µm[J]. Optical Materials Express, 2021, 11(9): 2877-2882. doi: 10.1364/OME.436045
    [20] Ma Weiwei, Qian Xiaobo, Wang Jingya, et al. Highly efficient dual-wavelength mid-infrared CW Laser in diode end-pumped Er: SrF2 single crystals[J]. Scientific Reports, 2016, 6: 36635. doi: 10.1038/srep36635
    [21] Camy P, Doualan J L, Renard S, et al. Tm 3+: CaF2 for 1.9 μm laser operation[J]. Optics Communications, 2004, 236(4/6): 395-402.
    [22] Degnan J J. Theory of the optimally coupled Q-switched laser[J]. IEEE Journal of Quantum Electronics, 1989, 25(2): 214-220. doi: 10.1109/3.16265
