辅助放电针对气体间隙直流自击穿特性的影响

石凌 谢霖燊 郭帆 贾伟 王海洋 陈志强 程乐 王艺 吴刚 肖晶 梅锴盛 王戈飞 花见涛

石凌, 谢霖燊, 郭帆, 等. 辅助放电针对气体间隙直流自击穿特性的影响[J]. 强激光与粒子束, 2024, 36: 055013. doi: 10.11884/HPLPB202436.230371
引用本文: 石凌, 谢霖燊, 郭帆, 等. 辅助放电针对气体间隙直流自击穿特性的影响[J]. 强激光与粒子束, 2024, 36: 055013. doi: 10.11884/HPLPB202436.230371
Shi Ling, Xie Linshen, Guo Fan, et al. Influence of auxiliary discharge needle on direct current self-breakdown characteristics of the gas gap[J]. High Power Laser and Particle Beams, 2024, 36: 055013. doi: 10.11884/HPLPB202436.230371
Citation: Shi Ling, Xie Linshen, Guo Fan, et al. Influence of auxiliary discharge needle on direct current self-breakdown characteristics of the gas gap[J]. High Power Laser and Particle Beams, 2024, 36: 055013. doi: 10.11884/HPLPB202436.230371

辅助放电针对气体间隙直流自击穿特性的影响

doi: 10.11884/HPLPB202436.230371
基金项目: 强脉冲辐射环境模拟与效应全国重点实验室基金项目
详细信息
    作者简介:

    石 凌,shiling@nint.ac.cn

  • 中图分类号: TM831

Influence of auxiliary discharge needle on direct current self-breakdown characteristics of the gas gap

  • 摘要: 为降低气体放电间隙直流条件下自击穿电压分散性,尽可能不影响其自击穿电压,基于环形电极放电间隙,设计了一种在阴极中心植入辅助放电针的辅助放电电极结构。通过电场仿真,研究了辅助放电针直径、长度和顶部倒角对放电间隙场畸变的影响。实验研究了放电间隙无辅助放电针和植入辅助放电针后,其在干燥空气和SF6气体中的直流自击穿特性。结果表明:辅助放电针直径越小、长度越长,电极环对其电场屏蔽作用越弱,放电间隙场畸变强度越大;辅助放电针对SF6气体放电间隙直流自击穿电压影响较小,随着场畸变系数的增大,同一气压下干燥空气自击穿电压下降百分数为SF6气体自击穿电压下降百分数的2~3倍;辅助放电针对直流条件下干燥空气和SF6气体放电间隙自击穿电压稳定性具有有益作用,分散性减小百分数较无辅助放电针结构均提高约25%。
  • 图  1  电极结构剖面图

    Figure  1.  Profile of electrode structures

    图  2  电极间隙电场分布

    Figure  2.  Electric field distribution in electrode gap

    图  3  场畸变系数变化图

    Figure  3.  Variation diagram of field distortion coefficient

    图  4  实验平台示意图

    Figure  4.  Schematic diagram of experimental platform

    图  5  干燥空气中击穿电压及击穿电压标准差变化图

    Figure  5.  Variation diagram of breakdown voltage and its standard deviation in dry air

    图  6  SF6气体中击穿电压及击穿电压标准差变化图

    Figure  6.  Variation diagram of breakdown voltage and breakdown voltage standard deviation in SF6

  • [1] 丛培天. 中国脉冲功率科技进展简述[J]. 强激光与粒子束, 2020, 32:025002 doi: 10.11884/HPLPB202032.200040

    Cong Peitian. Review of Chinese pulsed power science and technology[J]. High Power Laser and Particle Beams, 2020, 32: 025002 doi: 10.11884/HPLPB202032.200040
    [2] 谢瑞, 刘军, 何湘宁. 脉冲功率技术在环境保护中的应用[J]. 电力电子技术, 2010, 44(4):59-60,92 doi: 10.3969/j.issn.1000-100X.2010.04.024

    Xie Rui, Liu Jun, He Xiangning. Pulsed power technology in environmental applications[J]. Power Electronics, 2010, 44(4): 59-60,92 doi: 10.3969/j.issn.1000-100X.2010.04.024
    [3] 韩旻, 邹晓兵, 张贵新. 脉冲功率技术基础[M]. 北京: 清华大学出版社, 2010

    Han Min, Zou Xiaobing, Zhang Guixin. Fundamentals of pulse power technology[M]. Beijing: Tsinghua University Press, 2010
    [4] 王莹. 脉冲功率科学与技术[M]. 北京: 北京航空航天大学出版社, 2010

    Wang Ying. Science and technology on pulsed power[M]. Beijing: Beihang University Press, 2010
    [5] Wang Hu, Chang Jiasen, Tong Xin, et al. Study on the characteristics of the gas switch electrode erosion[J]. High Voltage Apparatus, 2011, 47(9): 6-11.
    [6] 孙昊, 刘轩东. 脉冲等离子体作用下SF6气体间隙的极限导通特性[J]. 电工技术, 2021(13):20-23

    Sun Hao, Liu Xuandong. Breakdown performance limit of a SF6 Gas gap ignited by pulsed discharge plasma[J]. Electric Engineering, 2021(13): 20-23
    [7] 黄涛, 罗维熙, 丛培天, 等. 不同电流下气体开关电极烧蚀特性实验研究[J]. 强激光与粒子束, 2014, 26:045042 doi: 10.3788/HPLPB20142604.45042

    Huang Tao, Luo Weixi, Cong Peitian, et al. Experimental study on electrode erosion characteristics of spark gas switch under different current[J]. High Power Laser and Particle Beams, 2014, 26: 045042 doi: 10.3788/HPLPB20142604.45042
    [8] 税荣杰, 陈学秒, 王桂吉, 等. 较高场畸变系数的大电流三电极气体开关[J]. 强激光与粒子束, 2023, 35:065003 doi: 10.11884/HPLPB202335.220349

    Shui Rongjie, Chen Xuemiao, Wang Guiji, et al. High-current three-electrode gas switch with high field distortion coefficient[J]. High Power Laser and Particle Beams, 2023, 35: 065003 doi: 10.11884/HPLPB202335.220349
    [9] 崔光曦, 李俊娜, 王海洋, 等. 纳秒脉冲电压下两种自触发开关的设计与实验研究[J]. 强激光与粒子束, 2023, 35:075003 doi: 10.11884/HPLPB202335.220415

    Cui Guangxi, Li Junna, Wang Haiyang, et al. Design and experimental study of two types of low jitter self-triggered switches under nanosecond pulse voltage[J]. High Power Laser and Particle Beams, 2023, 35: 075003 doi: 10.11884/HPLPB202335.220415
    [10] 孙铁平, 乔开来, 丛培天, 等. 快前沿直线脉冲变压器多间隙气体开关直流自击穿特性[J]. 强激光与粒子束, 2011, 23:267-271 doi: 10.3788/HPLPB20112301.0267

    Sun Tieping, Qiao Kailai, Cong Peitian, et al. Self-breakdown charicteristic of multi-gap switch for fast linear transformer driver[J]. High Power Laser and Particle Beams, 2011, 23: 267-271 doi: 10.3788/HPLPB20112301.0267
    [11] 魏浩, 孙凤举, 刘鹏, 等. ±100kV三电极场畸变气体火花开关[J]. 强激光与粒子束, 2012, 24(4):881-884 doi: 10.3788/HPLPB20122404.0881

    Wei Hao, Sun Fengju, Liu Peng, et al. ±100 kV three-electrode field-distortion gas spark switch[J]. High Power Laser and Particle Beams, 2012, 24(4): 881-884 doi: 10.3788/HPLPB20122404.0881
    [12] 党腾飞, 尹佳辉, 孙凤举, 等. 电极结构对触发管型开关击穿特性的影响[J]. 强激光与粒子束, 2015, 27:065004 (Dang Tengfei, Yin Jiahui, Sun Fengju, et al. Influence of electrode structure on breakdown characteristics of trigatron switch[J]. High Power Laser and Particle Beams, 2015, 27: 065004 doi: 10.11884/HPLPB201527.065004

    Dang Tengfei, Yin Jiahui, Sun Fengju, et al. Influence of electrode structure on breakdown characteristics of trigatron switch[J]. High Power Laser and Particle Beams, 2015, 27: 065004 doi: 10.11884/HPLPB201527.065004
    [13] 罗维熙, 丛培天, 孙铁平, 等. 电极材料对气体火花开关静态性能的影响[J]. 强激光与粒子束, 2016, 28:015022 doi: 10.11884/HPLPB201628.015022

    Luo Weixi, Cong Peitian, Sun Tieping, et al. Influence of electrode materials on static performance of gas spark switch[J]. High Power Laser and Particle Beams, 2016, 28: 015022 doi: 10.11884/HPLPB201628.015022
    [14] 翟戎骁, 黄涛, 丛培天, 等. 气体开关触发间隙与过压间隙击穿特性研究[J]. 原子能科学技术, 2018, 52(10):1904-1910

    Zhai Rongxiao, Huang Tao, Cong Peitian, et al. Study on breakdown characteristic of trigger gap and overvoltage gap in gas switch[J]. Atomic Energy Science and Technology, 2018, 52(10): 1904-1910
    [15] 黄种亮, 徐启福, 来定国, 等. 环形阴极宏观场增强因子计算研究[J]. 原子能科学技术, 2020, 54(8):1508-1512 doi: 10.7538/yzk.2019.youxian.0629

    Huang Zhongliang, Xu Qifu, Lai Dingguo, et al. Study on macroscopic field enhancement factor of annulus cathode[J]. Atomic Energy Science and Technology, 2020, 54(8): 1508-1512 doi: 10.7538/yzk.2019.youxian.0629
    [16] 王伟, 屠幼萍. 高电压技术[M]. 北京: 机械工业出版社, 2011

    Wang Wei, Tu Youping. High voltage technology[J]. Beijing: China Machine Press, 2011
    [17] Yudin A S, Martemyanov S S, Bukharkin A A, et al. Triggered spark gap switch with gas circulation for repetitively operated multistage Marx generator[C]//Proceedings of the 2018 20th International Symposium on High-Current Electronics. 2018: 166-169.
    [18] Kim A, Frolov S, Alexeenko V, et al. Prefire probability of the switch type fast LTD[C]//Proceedings of 2009 IEEE Pulsed Power Conference. 2009: 565-570.
    [19] 刘现飞, 唐钊, 刘轩东. 气体介质对多间隙气体开关电晕均压与自击穿特性的影响[J]. 强激光与粒子束, 2020, 32:025012 doi: 10.11884/HPLPB202032.0358

    Liu Xianfei, Tang Zhao, Liu Xuandong. Effect of gas medium on corona discharge for voltage balance and self-breakdown characteristics in multi-gaps gas switch[J]. High Power Laser and Particle Beams, 2020, 32: 025012 doi: 10.11884/HPLPB202032.0358
    [20] 姜晓峰, 梁天学, 王志国, 等. 环形电极单间隙电晕放电伏安特性[J]. 强激光与粒子束, 2012, 24(4):835-838 doi: 10.3788/HPLPB20122404.0835

    Jiang Xiaofeng, Liang Tianxue, Wang Zhiguo, et al. V-I characteristics of corona gas gap for annular electrode[J]. High Power Laser and Particle Beams, 2012, 24(4): 835-838 doi: 10.3788/HPLPB20122404.0835
