连续激光辐照ZnSe/MgF2/K9滤光片的透射特性研究

CW laserinduced transmission change in ZnSe/MgF2/K9 filter

  • 摘要: 分析了连续激光辐照ZnSe/MgF2/K9滤光片引起透射特性的变化。在室温条件下,用波长0.632 8μm激光作为探测光束,测量了1.06μm连续激光辐照ZnSe/MgF2/K9滤光片温升引起薄膜折射率的改变,导致探测光束通过干涉滤光片后透过率的热致非线性变化。在光斑直径0.75mm条件下,测量了不同功率激光辐照ZnSe/MgF2/K9滤光片引起温升随时间的变化。在激光功率30W,辐照时间2.52s条件下,实验观测到ZnSe/MgF2/K9滤光片薄膜破坏温度约为90℃,辐照时间10s时干涉滤光片形成的薄膜龟裂形貌。



    Abstract: The transmission change of ZnSe/MgF2/K9 filter induced by CW laser(1.06μm) is analyzed in this paper. At room temperature, the change of the film ' s refractive index induced by heating is measured with the detecting laser beam (0632 8μm). As a result of this change, the filter's transmission varies nonlinearly. When laser beam of different power with the spot diameter 0.75mm irradiated on the ZnSe/MgF2/K9 filter, temperature change responding to irradiation time is measured. Typical experiment results are as follows : The film temperature damage threshold is 90℃ with laser power 30W and irradiation time 2.52s, checked surface of the film is formed with irradiation time 10s.



/
