Blumlein传输线的解析分析

  • 摘要: 在传输线应用中,负载终端匹配设计是一个重要问题。用拉普拉斯变换方法严格求解Blumlein传输线的电报方程,研究在纯电阻负载和带分布参数负载情况下,波在传输线中的瞬态传输过程,得到了清晰的物理图像,结果与通常的行波传播分析法完全一致。



    Abstract: Termination match is a key for the design of transmission line. This paper, using Laplace transform method, describes exactly the transient transmission process of a Blumlein transmission line with a load which are pure resistivity or have distributed parameter. The results are about the same as that of the travel wave method..



/
