等离子体电极电光开关驱动电源系统

Driving system of electrooptical switch with plasma electrodes

  • 摘要: 介绍了通光口径为300mm×300mm的等离子体电极电光开关驱动电源系统原理。该系统能产生时序上严格关联的两路幅值3kV、脉宽为500ms预电离高压脉冲;两路电压幅值为7kV、电流峰值为2kA的阻尼大电流、低抖动主放电脉冲;一路幅值为12kV、脉宽500ns低抖动矩形高压开关脉冲。这五路高压脉冲通过3根同轴电缆加载到充有惰性气体的纵向普克尔盒两边的阴阳电极上,对激光形成等离子体电极电光开关。



    Abstract: This paper describes the principle of plasma electrooptical switch driving system. The system use plasma electrooptical switch system in high power ICF drivers based on large aperture size (for example, 300mm×300mm) multipass amplifier array scheme. The systems can product strict sequential correlated five highvoltage strongcurrent pulses. These pulses are loaded on longitudinal Pockels cell full of inert gas through three coaxial cables. As the electrooptical switch with plasma electrodes has unique advantage of high efficient, fast for on/off, high precision, large aperture size and high laser damage threshold, it has become an ideal switch system in new generation of ultrahigh power laser system.



/
