直线感应加速器组元的双脉冲改造

Doublepulse reconstruction of a singlepulse LIA module

  • 摘要: 对用于单脉冲直线感应加速器的加速组元进行了双脉冲改造的初步尝试:利用传输线延时获得了双脉冲馈入;用铁氧体作为磁芯材料,在感应腔上得到了双脉冲腔压波形。结果表明,现有组元功率系统经过简单的改造,可以获得两个甚至多个脉冲输出;在伏秒值允许的范围内,铁氧体磁芯的感应腔可以感应出双脉冲波形。为以后多脉冲直线感应加速器的改造和设计提供了一个方向,也提出了一些有待解决的问题。



    Abstract: A doublepulse line induced accelerator (LIA) module is reconstructed based on a usual singlepulse LIA module. By changing the length of one of the cables between the inductive cell and the Blumlein pulse forming line, two induction pulses are generated by the ferrite cores inductive cell. The interval time of the pulses is adjustable by changing the lengths of the cable, also the input voltage is changed in different experiments. The results show that it is possible for the existing LIA power system to generate multipulses; the ferrite cores of LIA can induct multipulses when their voltagesecond range is enough; and the resetting effect of the cores is tied up with the resetting time and resetting voltage.



/
