振动线测量技术在高能同步辐射光源增强器预准直单元中的应用

闫路平 刘晓阳 王小龙 董岚 王铜 门玲鸰 卢尚 韩圆颖 张露彦 闫皓月 马娜 何振强 柯志勇 李波 梁静

闫路平, 刘晓阳, 王小龙, 等. 振动线测量技术在高能同步辐射光源增强器预准直单元中的应用[J]. 强激光与粒子束, 2023, 35: 124003. doi: 10.11884/HPLPB202335.230125
引用本文: 闫路平, 刘晓阳, 王小龙, 等. 振动线测量技术在高能同步辐射光源增强器预准直单元中的应用[J]. 强激光与粒子束, 2023, 35: 124003. doi: 10.11884/HPLPB202335.230125
Yan Luping, Liu Xiaoyang, Wang Xiaolong, et al. Application of vibration wire measurement technology to pre-alignment units of High Energy Photon Source booster[J]. High Power Laser and Particle Beams, 2023, 35: 124003. doi: 10.11884/HPLPB202335.230125
Citation: Yan Luping, Liu Xiaoyang, Wang Xiaolong, et al. Application of vibration wire measurement technology to pre-alignment units of High Energy Photon Source booster[J]. High Power Laser and Particle Beams, 2023, 35: 124003. doi: 10.11884/HPLPB202335.230125

振动线测量技术在高能同步辐射光源增强器预准直单元中的应用

doi: 10.11884/HPLPB202335.230125
基金项目: 国家自然科学基金项目(12075264)
详细信息
    作者简介:

    闫路平,yanluping@ihep.ac.cn

    通讯作者:

    董 岚,dongl@ihep.ac.cn

  • 中图分类号: TL505

Application of vibration wire measurement technology to pre-alignment units of High Energy Photon Source booster

  • 摘要: 高能同步辐射光源(HEPS)的预准直单元数量庞大,且磁铁准直精度要求极高,为检验HEPS增强器预准直单元磁铁准直精度,需要在实验厅按照一定比例对其进行振动线磁中心验证测量。基于预研阶段已研发的振动线系统,详细介绍了振动线磁中心测量原理及扫描方法,研究了HEPS增强器两铁单元的磁中心准直精度检测方法并进行了验证实验。设计并搭建了振动线高精度重复定位夹持机构装置,研究了振动线下垂量的修正方法,并对增强器两铁单元的磁中心扫描结果进行拟合分析。实验结果表明,HEPS增强器两铁单元满足磁铁间相对位置误差优于 50 μm的预准直精度要求。
  • 图  1  HEPS增强器布局图

    Figure  1.  Layout diagram of HEPS booster

    图  2  增强器预准直单元振动线磁中心测量系统

    Figure  2.  Vibration wire magnetic center measurement system of pre-alignment unit of booster

    图  3  四极磁铁水平和垂直磁中心测量方法示意图

    Figure  3.  Schematic diagram of measuring methods for horizontal and vertical magnetic centers of quadrupole magnets

    图  4  六极磁铁水平磁中心测量方法示意图

    Figure  4.  Schematic diagram of measuring method of horizontal magnetic center of sextupole magnet

    图  5  陶瓷双锥丝线重复定位装置

    Figure  5.  Ceramic double cone thread repeat positioning device

    图  6  振动线测量程序

    Figure  6.  Vibrating wire measurement program

    图  7  振动线数据处理程序

    Figure  7.  Vibrating wire data processing program

    图  8  振动线磁中心扫描简意图

    Figure  8.  Simplified schematic of magnetic center scan of vibrating wire

    图  9  振动线垂度示意图

    Figure  9.  Schematic diagram of vibrating wire sag

    表  1  四六极铁设计参数

    Table  1.   Design parameters of the quadrupole and sextupole magnets

    magnet max.
    field
    min.
    field


    aperture
    /mm
    magnetic
    length
    /mm
    core
    length
    /m
    turns per
    pole
    max. of
    current
    /A
    min. of
    current
    /A
    good field
    region
    /mm
    field
    errors
    max.
    of power
    loss
    /kW
    water
    pressure
    drop
    /(kg·cm−2)
    water flow
    velocity
    /(m·s−1)
    temperature
    rise
    /℃
    weight
    /kg
    BS1QD13 33 T/m 1.5 T/m 40 300 290 13 411 19 ±16 5×10−4 3 3 2.45 5.7 345
    BS1SD6 1000 T/m2 30 T/m2 40 200 194 8 135.3 4.1 ±16 1×10−3 0.33 3 1.89 3 75
    下载: 导出CSV

    表  2  陶瓷双锥重复定位精度

    Table  2.   Ceramic double cone repeat positioning accuracy

    vibrating wire repeated
    positioning method
    cone
    angle
    deviation
    Xmax/μm
    deviation
    Ymax/μm
    deviation
    Xmin/μm
    deviation
    Ymin/μm
    deviation
    Xsat/μm
    deviation
    Ysat/μm
    compared with
    previous time
    70° 8.3 4.4 0.1 0.2 2.7 1.3
    90° 4.9 1.1 0.0 0.0 0.9 0.3
    110° 5.9 4.9 0.0 0 1.4 1.4
    compared with the
    initial zero
    70° 18.9 3.0 0.0 1.1 6.4 0.6
    90° 5.5 2.4 0.0 0.0 1.0 0.6
    110° 6.0 6.4 0.0 0.1 1.6 1.9
    下载: 导出CSV

    表  3  振动线与预准直单元水平磁轴准直

    Table  3.   The vibrating wire is aligned on the horizontal magnetic axis of the pre-alignment unit

    position operator lattice value horizontal offset/mm
    fixed end magnetic axis point 1 −50.0 −1.000
    2 −50.0 −1.000
    fixed end vibrating wire 1 −50.2 −1.004
    2 −50.0 −1.000
    free end magnetic axis point 1 −50.0 −1.000
    2 −50.0 −1.000
    free end vibrating wire 1 −50.2 −1.004
    2 −50.3 −1.006
    下载: 导出CSV

    表  4  振动线与预准直单元垂直磁轴准直

    Table  4.   The vibrating wire is aligned on the vertical magnetic axis of the pre-alignment unit

    position visual distance of the
    instrument from each
    measuring point/mm
    lattice
    value
    lattice value
    deviation
    vertical
    offset/mm
    vertical offset
    deviation/mm
    lattice
    value
    lattice value
    deviation
    vertical
    offset/mm
    vertical offset
    deviation/mm
    operator 1 operator 2
    vibrating wire of the fixed
    end of the quadrupole
    magnet
    2550 −41.0 50.0 −0.820 1.000 −41.5 51.0 −0.830 1.020
    magnetic axis point of the
    fixed end of the
    quadrupole magnet
    2295 9.0 0.180 9.5 0.190
    vibrating wire of the free
    end of the sextupole
    magnet
    2550 −43.0 50.0 −0.860 1.000 −43.0 50.5 −0.860 1.010
    magnetic axis point of the
    free end of the sextupole
    magnet
    2305 7.0 0.140 7.5 0.150
    下载: 导出CSV

    表  5  预准直单元四六极磁铁位置的振动线下垂量

    Table  5.   Sag of vibration wire at the position of pre-alignment unit quadrupole and sextupole magnets

    type of magnet L/mm δh/mm f1/Hz z1/mm z3/mm S(z)/mm
    quadrupole magnet 7453.0 1.8 18.36 1272.0 1592.0 −0.218
    sextupole magnet 18.30 1713.0 1931.0 −0.236
    下载: 导出CSV

    表  6  预准直单元振动线磁中心扫描重复性

    Table  6.   Repeatability of vibrating-wire magnetic center scanning in pre-alignment unit

    type of
    magnet
    timesX/mmX deviation/mmY/mmY deviation/mmX/mmX deviation/mmY/mmY deviation/mm
    magnetic center of fixed endmagnetic center of free end
    quadrupole
    magnet
    the first time−1.0020.0020.997−0.002−1.0020.0010.997−0.003
    the second time−1.0000.995−1.0010.994
    sextupole
    magnet
    the first time−0.959−0.0040.9890.006−0.965−0.0040.9890.001
    the second time−0.9630.995−0.9690.990
    下载: 导出CSV

    表  7  高能光源增强器预准直单元振动线扫描三维磁中心拟合偏差

    Table  7.   Fit deviation of vibration line scanning of 3D magnetic center of the pre-alignment unit of the High Energy Photon Source booster

    vibration wire fixation mode magnet inlet and outlet X/mm Y/mm Z/mm
    fixed end BS1QD13EN 0.003 −0.003 0.000
    free end BS1QD13EX −0.017 0.010 320.000
    fixed end BS1SD6EN 0.017 −0.007 441.000
    free end BS1SD6EX −0.003 0.000 661.000
    下载: 导出CSV
  • [1] 焦毅, 潘卫民. 高能同步辐射光源[J]. 强激光与粒子束, 2022, 34:104002 doi: 10.11884/HPLPB202234.220080

    Jiao Yi, Pan Weimin. High energy photon source[J]. High Power Laser and Particle Beams, 2022, 34: 104002 doi: 10.11884/HPLPB202234.220080
    [2] Jiao Yi, Xu Gang, Cui Xiaohao, et al. The HEPS project[J]. Journal of Synchrotron Radiation, 2018, 25(6): 1611-1618. doi: 10.1107/S1600577518012110
    [3] Jiao Yi, Chen Fusan, He Ping, et al. Modification and optimization of the storage ring lattice of the High Energy Photon Source[J]. Radiation Detection Technology and Methods, 2020, 4(4): 415-424. doi: 10.1007/s41605-020-00189-7
    [4] Meng Cai, He Xiang, Jiao Yi, et al. Physics design of the HEPS LINAC[J]. Radiation Detection Technology and Methods, 2020, 4(4): 497-506. doi: 10.1007/s41605-020-00205-w
    [5] Guo Yuanyuan, Wei Yuanyuan, Peng Yuemei, et al. The transfer line design for the HEPS project[J]. Radiation Detection Technology and Methods, 2020, 4(4): 440-447. doi: 10.1007/s41605-020-00209-6
    [6] 于成浩, 殷立新, 杜涵文, 等. 上海光源准直测量方案设计[J]. 强激光与粒子束, 2006, 18(7):1167-1172

    Yu Chenghao, Yin Lixin, Du Hanwen, et al. Survey and alignment design of Shanghai synchrotron radiation facility[J]. High Power Laser and Particle Beams, 2006, 18(7): 1167-1172
    [7] Temnykh A, Levashov Y, Wolf Z. A study of undulator magnets characterization using the vibrating wire technique[J]. Nuclear Instruments and Methods in Physics Research Section A: Accelerators, Spectrometers, Detectors and Associated Equipment, 2010, 622(3): 650-656.
    [8] Kang Wen, Liu Lei, Yu Yongji, et al. Design of the magnets for the HEPS injector[J]. Radiation Detection Technology and Methods, 2022, 6(2): 143-149. doi: 10.1007/s41605-022-00314-8
    [9] Peng Yuemei, Duan Zhe, Guo Yuanyuan, et al. Design of the HEPS booster lattice[J]. Radiation Detection Technology and Methods, 2020, 4(4): 425-432. doi: 10.1007/s41605-020-00202-z
    [10] 吴蕾. 振动线测量技术研究[D]. 北京: 中国科学院高能物理研究所, 2016

    Wu Lei. Research of vibrating wire measurement technique[D]. Beijing: Institute of High Energy Physics, Chinese Academy of Sciences, 2016
    [11] Arpaia P, Buzio M, Perez J J G, et al. Magnetic field measurements on small magnets by vibrating wire systems[C]//2011 IEEE International Instrumentation and Measurement Technology Conference. 2011: 1-4.
    [12] Wolf Z. A vibrating wire system for quadrupole fiducialization[R]. Menlo Park: SLAC National Accelerator Laboratory, 2010.
    [13] Wu Lei, Li Chunhua, Wang Xiaolong, et al. Research development of high precision installation and alignment system for HEPS[C]//6th International Particle Accelerator Conference. 2015: 2924-2926.
    [14] 赵籍九, 尹兆升. 粒子加速器技术[M]. 北京: 高等教育出版社, 2006

    Zhao Jijiu, Yin Zhaosheng. Particle accelerator technology[M]. Beijing: Higher Education Press, 2006
    [15] Fukami K, Azumi N, Inoue S, et al. Performance verification of a precise vibrating-wire magnet alignment technique for next-generation light sources[J]. Review of Scientific Instruments, 2019, 90: 054703. doi: 10.1063/1.5086505
    [16] Jain A, Anerella M, Ganetis G, et al. Vibrating wire R&D for alignment of multipole magnets in NSLS-II[C]//10th International Workshop on Accelerator Alignment. 2008.
    [17] 闫路平, 董岚, 王铜, 等. 一种关于线的重复定位装置: 214843081U[P]. 2021-11-23

    Yan Luping, Dong Lan, Wang Tong, et al. A device for repeated positioning of wires: 214843081U[P]. 2021-11-23
    [18] 闫路平, 董岚, 王铜, 等. 粒子加速器丝线位置测量电容传感器标定方法[J]. 强激光与粒子束, 2022, 34:114002 doi: 10.11884/HPLPB202234.220447

    Yan Luping, Dong Lan, Wang Tong, et al. Calibration method of capacitance sensor for particle accelerator wire position measurement[J]. High Power Laser and Particle Beams, 2022, 34: 114002 doi: 10.11884/HPLPB202234.220447
    [19] Jain A. High precision alignment of multipoles[C]//Low Emittance Rings 2010 Workshop. 2010.
    [20] Jain A. Precision alignment of multipoles on a girder for NSLS-II[C]//17th International Magnetic Measurement Workshop. 2011.
    [21] 吴蕾, 王小龙, 李春华, 等. 振动线准直技术的原理和研究概述[J]. 强激光与粒子束, 2013, 25(10):2479-2486 doi: 10.3788/HPLPB20132510.2479

    Wu Lei, Wang Xiaolong, Li Chunhua, et al. Theory and research overview of vibrating wire technique[J]. High Power Laser and Particle Beams, 2013, 25(10): 2479-2486 doi: 10.3788/HPLPB20132510.2479
    [22] Jain A, He Ping, Ganetis G. Measurement of wire sag in a vibrating wire setup[C]//15th International Magnet Measurement Workshop. 2007.
    [23] 王科, 杨治勇, 廖树清, 等. 脉冲紧线磁轴测量方法中金属丝下垂的影响分析[J]. 核技术, 2015, 38:080201 doi: 10.11889/j.0253-3219.2015.hjs.38.080201

    Wang Ke, Yang Zhiyong, Liao Shuqing, et al. Analysis of the wire sag in the pulsed taut-wire technique[J]. Nuclear Techniques, 2015, 38: 080201 doi: 10.11889/j.0253-3219.2015.hjs.38.080201
    [24] Zhang C, Mitsuda C, Kajimoto K. Eigenfrequency wire alignment system for magnet fiducialization[C]//14th International Workshop on Accelerator Alignment. 2016.
    [25] Zhang C, Azumi N, Fukami K, et al. Magnet alignment monitoring system with eigenfrequency-based wire sag correction[J]. Measurement Science and Technology, 2021, 32: 075009. doi: 10.1088/1361-6501/abe5e4
