高压保护开关缓冲电路参数优化设计

李志恒 马少翔 张鸿淇 朱帮友 张明 于克训 潘垣

李志恒, 马少翔, 张鸿淇, 等. 高压保护开关缓冲电路参数优化设计[J]. 强激光与粒子束, 2024, 36: 025009. doi: 10.11884/HPLPB202436.230158
引用本文: 李志恒, 马少翔, 张鸿淇, 等. 高压保护开关缓冲电路参数优化设计[J]. 强激光与粒子束, 2024, 36: 025009. doi: 10.11884/HPLPB202436.230158
Li Zhiheng, Ma Shaoxiang, Zhang Hongqi, et al. Parameter optimization design of snubber circuit for high voltage protection switch[J]. High Power Laser and Particle Beams, 2024, 36: 025009. doi: 10.11884/HPLPB202436.230158
Citation: Li Zhiheng, Ma Shaoxiang, Zhang Hongqi, et al. Parameter optimization design of snubber circuit for high voltage protection switch[J]. High Power Laser and Particle Beams, 2024, 36: 025009. doi: 10.11884/HPLPB202436.230158

高压保护开关缓冲电路参数优化设计

doi: 10.11884/HPLPB202436.230158
基金项目: 国家重点研发计划项目(2017YFE0300104); 国家自然科学基金项目(51821005)
详细信息
    作者简介:

    李志恒,zhihengli@hust.edu.cn

    通讯作者:

    马少翔,mashaoxiang@hust.edu.cn

  • 中图分类号: TM832

Parameter optimization design of snubber circuit for high voltage protection switch

  • 摘要: 目前的高压保护开关缓冲电路参数设计缺乏相关理论设计方法,同时缓冲电路方案由于设计过程中并未考虑分布电容影响,因此均为等参数设计方案,这种方法均压效果不够理想。为了解决目前参数设计中存在的问题,首先建立了含缓冲电路和杂散电感的MOSFET模型并对其关断过程进行了分析,从而得到了抑制电压尖峰的缓冲电路理论设计方法及表达式。针对串联均压未考虑分布电容的问题,通过构造等电位点,建立了含有分布电容的等效电路并进行分析,根据电荷方程等式得到了缓冲电路非等参数设计方法及表达式,该参数设计方法可以补偿分布电容造成的电压分布不均,并更好地指导高压保护开关的均压方案设计。为了验证参数设计的合理性进行了仿真分析,结果表明,最终得到的整体设计方案可以满足尖峰抑制以及均压的设计要求。
