新型全固态模块化多电平特种高压电源优化设计

李玉山 钱伟刚 滕甲训 孙孝峰

李玉山, 钱伟刚, 滕甲训, 等. 新型全固态模块化多电平特种高压电源优化设计[J]. 强激光与粒子束, 2024, 36: 025007. doi: 10.11884/HPLPB202436.230322
引用本文: 李玉山, 钱伟刚, 滕甲训, 等. 新型全固态模块化多电平特种高压电源优化设计[J]. 强激光与粒子束, 2024, 36: 025007. doi: 10.11884/HPLPB202436.230322
Li Yushan, Qian Weigang, Teng Jiaxun, et al. Optimization desigh of new all-solid-state modular multilevel special high-voltage power supply[J]. High Power Laser and Particle Beams, 2024, 36: 025007. doi: 10.11884/HPLPB202436.230322
Citation: Li Yushan, Qian Weigang, Teng Jiaxun, et al. Optimization desigh of new all-solid-state modular multilevel special high-voltage power supply[J]. High Power Laser and Particle Beams, 2024, 36: 025007. doi: 10.11884/HPLPB202436.230322

新型全固态模块化多电平特种高压电源优化设计

doi: 10.11884/HPLPB202436.230322
基金项目: 河北省自然科学基金重点项目(E2021203162);河北省重点研发计划项目(19214405D)
详细信息
    作者简介:

    李玉山,liyushan@qvc.edu.cn

    通讯作者:

    滕甲训,tengjiaxun@qq.com

    孙孝峰,sxf@ysu.edu.cn

  • 中图分类号: TK513.5

Optimization desigh of new all-solid-state modular multilevel special high-voltage power supply

  • 摘要: 模块化多电平换流器(MMC)已成为新型全固态特种高压电源的有效解决方案,对其进行轻量化设计以节约设备空间成本成为当前研究热点。MMC中限制功率密度提升的首要因素为子模块大尺寸电容,为降低MMC对子模块容值的需求,提高系统功率密度,提出一种改进型MMC(I-MMC)拓扑。应用隔离型开关电容变换器,实现上下桥臂一对子模块高频链互联。研究中相单元内上、下桥臂子模块对并联的高频链两侧采用同步控制,使子模块电容之间呈现开关电容特性,实现波动功率在电容之间的自由传递,进而消除相位相反的基频与3倍频波动分量。结合MMC运行调制比和功率因数分析基频与3倍频波动分量消除后子模块电容取值,完成模块化设计。所提方案可将子模块电容减小至常规MMC的1/4。仿真与实验结果验证了所提拓扑方案的正确性与有效性。
  • 图  1  常规MMC及I-MMC拓扑图

    Figure  1.  Topology diagram of conventional MMC and I-MMC

    图  2  子模块电容能量流动过程波形

    Figure  2.  Energy flow path between sub-module capacitors

    图  3  子模块电容能量流动过程

    Figure  3.  Sub-module capacitor energy flow path

    图  4  I-MMC等效模型图

    Figure  4.  Diagram of I-MMC equivalent models

    图  5  容值比与调制比和功率因数角关系

    Figure  5.  Relationship between capacitance ratio, modulationratio and power factor angle

    图  6  组合式模块单元

    Figure  6.  Combined modular unit

    图  7  容值668 μF上下桥臂子模块电压

    Figure  7.  Voltage waveforms of upper and lower bridge arm submodules

    图  8  模型2容值177 μF上下桥臂子模块电压

    Figure  8.  Voltage waveforms of upper and lower bridge arm sub-modules in model 2

    图  9  仿真波形

    Figure  9.  Simulation waveforms

    图  10  实验波形

    Figure  10.  Experimental waveforms

    表  1  仿真参数

    Table  1.   Simulation parameters

    model Udc/kV Uac/kV P/MW f/Hz fc/kHz number of
    bridge arm submodules
    Larm/mH C/μF transformer
    conversion ratio
    L/μH fH/kHz
    MMC 12 12 1.2 50 2 4 10 668
    I-MMC 4.9 4.9 1.2 50 2 4 10 668/177 1∶1 9 20
    下载: 导出CSV

    表  2  实验参数

    Table  2.   Experimental parameters

    Udc/VUac/VP/kWf/Hzfc/kHzLarm/mHC/μFtransformer conversion ratioL/μHfH/kHz
    2402401.250261101:14.320
    下载: 导出CSV
  • [1] 姜松, 邱力文, 饶俊峰, 等. 新型全固态高压多电平波形发生器的研制[J]. 强激光与粒子束, 2019, 31:115003 doi: 10.11884/HPLPB201931.190124

    Jiang Song, Qiu Liwen, Rao Junfeng, et al. Development of a new all-solid-state high voltage multilevel waveform generator[J]. High Power Laser and Particle Beams, 2019, 31: 115003 doi: 10.11884/HPLPB201931.190124
    [2] 汤广福, 罗湘, 魏晓光. 多端直流输电与直流电网技术[J]. 中国电机工程学报, 2013, 33(10):8-17

    Tang Guangfu, Luo Xiang, Wei Xiaoguang. Multi-terminal HVDC and DC-grid technology[J]. Proceedings of the CSEE, 2013, 33(10): 8-17
    [3] 徐旭哲, 周杨, 孙鹞鸿. 磁隔离触发式10 kV级联型脉冲电源研制[J]. 强激光与粒子束, 2016, 28:075001 doi: 10.11884/HPLPB201628.075001

    Xu Xuzhe, Zhou Yang, Sun Yaohong. Development of 10 kV cascaded pulse power supply based on magnetic isolation trigger[J]. High Power Laser and Particle Beams, 2016, 28: 075001 doi: 10.11884/HPLPB201628.075001
    [4] 滕甲训, 赵巍, 潘禹卓, 等. 基于开关电容结构的MMC子模块波动功率耦合方案及其参数约束[J]. 中国电机工程学报, 2021, 41(21):7449-7463

    Teng Jiaxun, Zhao Wei, Pan Yuzhuo, et al. A fluctuating power coupling method for submodules of MMC based on switched-capacitors and its parameters constraint[J]. Proceedings of the CSEE, 2021, 41(21): 7449-7463
    [5] 滕甲训, 潘禹卓, 卜泽敏, 等. 基于谐振式推挽结构的三端口MMC-SST波动功率耦合方案研究[J]. 中国电机工程学报, 2022, 42(6):2308-2320

    Teng Jiaxun, Pan Yuzhuo, Bu Zemin, et al. Research on fluctuating power coupling scheme of three-port MMC-SST based on resonant push-pull structure[J]. Proceedings of the CSEE, 2022, 42(6): 2308-2320
    [6] Debnath S, Qin Jiangchao, Saeedifard M. Control and stability analysis of modular multilevel converter under low-frequency operation[J]. IEEE Transactions on Industrial Electronics, 2015, 62(9): 5329-5339. doi: 10.1109/TIE.2015.2414908
    [7] 董鹏, 蔡旭, 吕敬. 大幅减小子模块电容容值的MMC优化方法[J]. 中国电机工程学报, 2018, 38(18):5369-5380

    Dong Peng, Cai Xu, Lü Jing. Optimized method of MMC for greatly reducing the capacitance of the submodules[J]. Proceedings of the CSEE, 2018, 38(18): 5369-5380
    [8] 李笑倩, 刘文华, 孙树敏, 等. 利用环流的MMC电容电压波动抑制方法[J]. 电力电子技术, 2018, 52(11):30-32,74

    Li Xiaoqian, Liu Wenhua, Sun Shumin, et al. Capacitor voltage ripple suppression method of MMC using circulating current[J]. Power Electronics, 2018, 52(11): 30-32,74
    [9] 黄守道, 彭也伦, 廖武. 模块化多电平型变流器电容电压波动及其抑制策略研究[J]. 电工技术学报, 2015, 30(7):62-71

    Huang Shoudao, Peng Yelun, Liao Wu. Study of capacitor voltage fluctuation and its suppression for modular multilevel converter[J]. Transactions of China Electrotechnical Society, 2015, 30(7): 62-71
    [10] Du Sixing, Wu Bin, Zargari N R, et al. A flying-capacitor modular multilevel converter for medium-voltage motor drive[J]. IEEE Transactions on Power Electronics, 2017, 32(3): 2081-2089. doi: 10.1109/TPEL.2016.2565510
    [11] Li Binbin, Zhou Shaoze, Xu Dianguo, et al. A hybrid modular multilevel converter for medium-voltage variable-speed motor drives[J]. IEEE Transactions on Power Electronics, 2017, 32(6): 4619-4630. doi: 10.1109/TPEL.2016.2598286
    [12] 李国庆, 王威儒, 辛业春, 等. 模块化多电平换流器子模块分组排序调制策略[J]. 高电压技术, 2018, 44(7):2107-2114

    Li Guoqing, Wang Weiru, Xin Yechun, et al. Sub-module grouping modulation strategy of modular multilevel converter[J]. High Voltage Engineering, 2018, 44(7): 2107-2114
    [13] Tu Chunming, Xiao Fan, Lan Zheng, et al. Analysis and control of a novel modular-based energy router for DC microgrid cluster[J]. IEEE Journal of Emerging and Selected Topics in Power Electronics, 2019, 7(1): 331-342. doi: 10.1109/JESTPE.2018.2878004
    [14] 班明飞, 申科, 王建赜, 等. 基于准比例谐振控制的MMC新型环流抑制器[J]. 电力系统自动化, 2014, 38(11):85-89,129

    Ban Mingfei, Shen Ke, Wang Jianze, et al. A novel circulating current suppressor for modular multilevel converters based on quasi-proportional-resonant control[J]. Automation of Electric Power Systems, 2014, 38(11): 85-89,129
    [15] 徐政, 屠卿瑞, 管敏渊, 等. 柔性直流输电系统[M]. 北京: 机械工业出版社, 2012

    Xu Zheng, Tu Qingrui, Guan Minyuan, et al. Flexible DC transmission system[M]. Beijing: China Machine Press, 2012
