直线加速器控制网测量跟踪仪测角误差标定

张翼飞 董晓浩 陈家华 孙小沛 刘芳芳

张翼飞, 董晓浩, 陈家华, 等. 直线加速器控制网测量跟踪仪测角误差标定[J]. 强激光与粒子束, 2024, 36: 074001. doi: 10.11884/HPLPB202436.230374
引用本文: 张翼飞, 董晓浩, 陈家华, 等. 直线加速器控制网测量跟踪仪测角误差标定[J]. 强激光与粒子束, 2024, 36: 074001. doi: 10.11884/HPLPB202436.230374
Zhang Yifei, Dong Xiaohao, Chen Jiahua, et al. Calibration of the tracker’s angle measurement error for linac control network[J]. High Power Laser and Particle Beams, 2024, 36: 074001. doi: 10.11884/HPLPB202436.230374
Citation: Zhang Yifei, Dong Xiaohao, Chen Jiahua, et al. Calibration of the tracker’s angle measurement error for linac control network[J]. High Power Laser and Particle Beams, 2024, 36: 074001. doi: 10.11884/HPLPB202436.230374

直线加速器控制网测量跟踪仪测角误差标定

doi: 10.11884/HPLPB202436.230374
基金项目: 国家自然科学基金联合基金项目(U1832172)
详细信息
    作者简介:

    张翼飞,zhangyifei@sari.ac.cn

  • 中图分类号: TL505

Calibration of the tracker’s angle measurement error for linac control network

  • 摘要: 根据关键设备在直线加速器隧道内的布局,控制网布设在隧道地面和墙面。跟踪仪是直线加速器控制网测量的主要仪器,跟踪仪的测角误差是影响设备精度的关键因素。根据隧道墙面和地面网点的布局以及跟踪仪测量方案,对跟踪仪所有测量状态下的水平角和垂直角进行分解;然后通过高精度三坐标测量仪和跟踪仪联动测试,对分解后的角度进行高精度求解,解算值用于修正跟踪仪的实测角度。结果表明,不管是哪种测量状态,跟踪仪实测角度值均大于解算值;地面网点垂直角和水平角的偏差与跟踪仪的标称精度基本相当;墙面点水平角超过15°时,测角误差随着角度的增加而增大,在隧道控制网测量时需要对墙面点水平角进行修正。
  • 图  1  光束线隧道横截面控制网点布局以及坐标系

    Figure  1.  Layout of control network in beamline tunnel cross-section and coordinate system

    图  2  光学隧道控制网测量方案

    Figure  2.  Control network measurement plan in optical tunnel

    图  3  跟踪仪角度测量分解

    Figure  3.  Decomposition of the tracker’s measurement angle

    图  4  棱镜球、三坐标测量仪以及坐标系

    Figure  4.  Target, CMM and coordinate system

    图  5  跟踪仪垂直角标定

    Figure  5.  Vertical angle calibration of tracker

    图  6  三角形解算示意图

    Figure  6.  Calculation based on relatiouship between sides in a triangle

    图  7  跟踪仪水平角标定

    Figure  7.  Horizontal angle calibration of tracker

    表  1  跟踪仪测量角度分解值

    Table  1.   Decomposition values of the tracker’s measurement angle

    tunnel section distance/m ground network points wall network points
    horizontal angle/(°)
    vertical angle/(°) horizontal angle/(°)
    2 4.5 111.8 10.08 32.6
    3 7.5 103.5 6.09 21.14
    4 10.5 99.73 4.36 15.43
    5 13.5 97.59 3.39 12.12
    6 16.5 96.23 2.78 9.97
    7 19.5 95.27 2.35 8.46
    8 22.5 94.57 2.04 7.34
    9 25.5 94.04 1.8 6.49
    10 28.5 93.61 1.61 5.81
    下载: 导出CSV

    表  2  垂直角前视数据

    Table  2.   Vertical angle forward looking data

    tracker CMM error/(″)
    D/mm θH/(°) θV/(°) displayed
    angle/(°)
    X/mm Y/mm Z/mm calculated
    angle /(°)
    1555.992 0.0006 90.0006 567.3841 486.9879 682.2063
    1559.096 0.0009 93.6095 3.6089 567.384 486.9884 584.0774 3.6089 0
    1559.885 0.0012 94.0399 4.0393 567.3842 486.9883 572.3393 4.0385 −2.88
    1560.978 0.0013 94.5711 4.5705 567.3843 486.9884 557.8323 4.5698 −2.52
    1562.621 0.0014 95.2702 5.2696 567.3843 486.9883 538.7067 5.2693 −1.08
    1565.269 0.0018 96.231 6.2304 567.3845 486.9882 512.3521 6.2296 −2.88
    1569.909 0.0016 97.5401 7.5395 567.3846 486.9878 474.88 7.5389 −2.16
    1578.741 0.0016 99.7302 9.7296 567.3847 486.9873 415.4226 9.7287 −3.24
    1600.258 0.0015 103.5003 13.4997 567.3843 486.9879 308.6595 13.499 −2.52
    下载: 导出CSV

    表  3  垂直角后视前标定数据

    Table  3.   Vertical angle backward looking data

    tracker CMM error/(″)
    D/mm θH/(°) θV/(°) displayed
    angle/(°)
    X/mm Y/mm Z/mm calculated
    angle /(°)
    1605.503 179.9998 89.9997 436.3315 508.5864 577.4946
    1608.703 179.9994 93.6099 3.6102 436.3322 508.586 476.2022 3.6098 −1.44
    1609.519 179.9995 94.0398 4.0401 436.3322 508.5859 464.1014 4.0401 0
    1610.635 179.9995 94.5701 4.5704 436.3323 508.5859 449.1584 4.5705 0.36
    1612.333 179.9992 95.2704 5.2707 436.3325 508.5857 429.3875 5.2706 −0.36
    1615.056 179.9993 96.2303 6.2306 436.3326 508.5855 402.2223 6.2301 −1.8
    1619.718 179.999 97.5903 7.5906 436.3327 508.5856 363.5459 7.5903 −1.08
    1628.969 179.9988 99.7306 9.7309 436.3325 508.5861 302.171 9.7307 −0.72
    1651.164 179.9986 103.5005 13.5008 436.3323 508.5859 192.0205 13.5007 −0.36
    下载: 导出CSV

    表  4  地面点水平角顺时针标定数据

    Table  4.   Horizontal angle clockwise data for ground control network

    trackerCMMerror/(″)
    D/mmθH/(°)θV/(°)displayed
    angle/(°)
    X/mmY/mmZ/mmcalculated
    angle /(°)
    1561.2880.000390.0004567.37564.4533680.3061
    1561.9921.610190.00021.6098567.742648.3293680.30591.6105−0.76
    1562.1631.800890.00041.8005567.562953.5393680.30581.801−0.36
    1562.3952.040690.00052.0403567.562860.0795680.30592.0404−1.8
    1562.7372.349990.00052.3496567.545168.5197680.30592.35−0.72
    1563.2442.750190.00042.7498567.545179.4458680.30592.7493−3.96
    1564.2213.389990.00043.3896567.566696.937680.30613.3892−3.6
    1566.0684.360590.00034.3602567.459123.5187680.30634.3601−2.52
    1570.4876.089190.00016.0888567.4737171.0359680.30686.0886−2.88
    1586.34410.08079010.0804567.459282.1039680.307810.0801−3.24
    下载: 导出CSV

    表  5  地面点水平角逆时针标定数据

    Table  5.   Horizontal angle anticlockwise data for ground control network

    tracker CMM error/(″)
    D/mm θH/(°) θV/(°) displayed
    angle/(°)
    X/mm Y/mm Z/mm calculated
    angle /(°)
    1569.297 −0.0002 90.0005 525.1197 989.4216 681.9518
    1568.723 1.61 90.0008 1.6102 525.1194 945.3409 681.952 1.6096 −2.16
    1568.735 1.7993 90.0008 1.7995 525.1193 940.1496 681.9519 1.7992 −1.08
    1568.779 2.041 90.0008 2.0412 525.1193 933.5449 681.9518 2.0404 −2.88
    1568.873 2.3492 90.0007 2.3494 525.1193 925.1026 681.952 2.3486 −2.88
    1569.079 2.7792 90.0011 2.7794 525.1191 913.3313 681.952 2.779 −1.44
    1569.525 3.3902 90.001 3.3904 525.1187 896.5895 681.9518 3.3892 −4.32
    1570.601 4.3604 90.0011 4.3606 525.1183 869.9824 681.9518 4.3601 −1.8
    1573.637 6.0905 90.001 6.0907 525.1182 822.4136 681.9513 6.0897 −3.6
    1586.219 10.0796 90.0009 10.0798 525.1182 711.7248 681.9501 10.0788 −3.6
    下载: 导出CSV

    表  6  墙面点水平角顺时针标定数据

    Table  6.   Horizontal angle clockwise data for wall control network

    tracker CMM error/(″)
    D/mm θH/(°) θV/(°) displayed
    angle/(°)
    X/mm Y/mm Z/mm calculated
    angle /(°)
    1561.288 0.0003 90.0004 567.3756 4.4533 680.3061
    1569.678 5.8107 90.0003 5.8104 567.4584 163.361 680.3068 5.8106 0.72
    1571.728 6.4904 90.0001 6.4901 567.5732 182.1064 680.3069 6.4898 −1.08
    1574.603 7.3401 90.0001 7.3398 567.4812 205.6098 680.3071 7.3398 0
    1578.941 8.4601 90 8.4598 567.4809 236.7345 680.3075 8.4595 −1.08
    1585.798 9.9704 89.9999 9.9701 567.4807 278.994 680.3078 9.9695 −2.16
    1597.976 12.1196 89.9999 12.1193 567.4584 339.8554 680.3083 12.1159 −12.24
    1620.553 15.429 89.9996 15.4287 567.3514 435.5624 680.3085 15.4279 −2.88
    1675.225 21.1393 89.9992 21.139 567.3539 608.5579 680.3097 21.1376 −5.04
    1856.061 32.6204 89.9994 32.6201 567.3552 1004.9197 680.3116 32.6174 −9.72
    下载: 导出CSV

    表  7  墙面点水平角逆时针标定数据

    Table  7.   Horizontal angle anticlockwise data for wall control network

    trackerCMMerror/(″)
    D/mmθH/(°)θV/(°)displayed
    angle/(°)
    X/mmY/mmZ/mmcalculated
    angle/(°)
    1569.297−0.000290.0005525.1197989.4216681.9518
    1573.0465.810690.00095.8108525.1181830.1243681.95165.81−2.88
    1574.5446.489790.0016.4899525.1182811.4113681.95116.4893−2.16
    1576.747.340790.00097.3409525.1182787.9031681.9517.3402−2.52
    1580.1658.460790.0018.4609525.1182756.8625681.95058.4599−3.6
    1585.7679.969990.00099.9701525.1183714.7948681.95029.9692−3.24
    1595.74512.120990.000912.1211525.1184654.2506681.9512.1203−2.88
    1615.81415.429690.001115.4298525.1178559.3949681.949815.4285−4.68
    1664.96521.139490.000921.1396525.1165388.7797681.948521.1382−5.04
    1831.18732.619190.001132.6193525.11911.993681.946532.6174−6.84
    下载: 导出CSV
  • [1] 蔡国柱. 大型离子加速器先进准直安装方法研究[D]. 兰州: 中国科学院近代物理研究所, 2014: 39-45

    Cai Guozhu. Research on alignment and installation of large ion accelerator[D]. Lanzhou: Institute of Modern Physics, Chinese Academy of Sciences, 2014: 39-45
    [2] 张正禄. 工程测量学[M]. 2版. 武昌: 武汉大学出版社, 2013

    Zhang Zhenglu. Engineering geodesy[M]. 2nd ed. Wuchang: Wuhan University Publishing, 2013
    [3] 林嘉睿, 邾继贵, 郭寅, 等. 现场大空间测量中精密三维坐标控制网的建立[J]. 机械工程学报, 2012, 48(4):6-11 doi: 10.3901/JME.2012.04.006

    Lin Jiarui, Zhu Jigui, Guo Yin, et al. Establishment of precise three-dimensional coordinate control network in field large-space measurement[J]. Journal of Mechanical Engineering, 2012, 48(4): 6-11 doi: 10.3901/JME.2012.04.006
    [4] 杨丁亮, 邹进贵. 激光跟踪仪进行控制网精度估算与分析[J]. 测绘通报, 2020(s1):41-44

    Yang Dingliang, Zou Jingui. Precision estimation and analysis of control network of laser tracker[J]. Bulletin of Surveying and Mapping, 2020(s1): 41-44
    [5] 郭迎钢, 李宗春, 李广云, 等. 粒子加速器工程控制网研究进展与展望[J]. 测绘通报, 2020(1):136-141

    Guo Yinggang, Li Zongchun, Li Guangyun, et al. Progress and prospect of engineering control network for particle accelerator[J]. Bulletin of Surveying and Mapping, 2020(1): 136-141
    [6] 王小龙, 康玲, 董岚, 等. 附有高程约束的三维平差方法研究[J]. 强激光与粒子束, 2022, 34:084001

    Wang Xiaolong, Kang Ling, Dong Lan, et al. Research on three-dimensional adjustment with elevation constraints[J]. High Power Laser and Particle Beams, 2022, 34: 084001
    [7] 黎建州. 激光跟踪仪测量精度评定方法研究[D]. 武汉: 武汉大学, 2017: 7-11

    Li Jianzhou. Research on evaluation method of accuracy of laser tracker[D]. Wuhan: Wuhan University, 2017: 7-11
    [8] 甘霖, 李晓星. 激光跟踪仪现场测量精度检测[J]. 北京航空航天大学学报, 2009, 35(5):612-614

    Gan Lin, Li Xiaoxing. Site measuring accuracy testing of laser tracker[J]. Journal of Beijing University of Aeronautics and Astronautics, 2009, 35(5): 612-614
    [9] 杨振, 贺磊. 利用激光跟踪仪建立高精度微型测边网[J]. 红外与激光工程, 2008, 37(s1):137-140

    Yang Zhen, He Lei. Establishing high-precision subminiature ranging network based on laser tracker[J]. Infrared and Laser Engineering, 2008, 37(s1): 137-140
    [10] 林嘉睿, 邾继贵, 张皓琳, 等. 激光跟踪仪测角误差的现场评价[J]. 仪器仪表学报, 2012, 33(2):463-468

    Lin Jiarui, Zhu Jigui, Zhang Gaolin, et al. Field evaluation of laser tracker angle measurement error[J]. Chinese Journal of Scientific Instrument, 2012, 33(2): 463-468
    [11] 李辉, 伍嘉豪, 赵伟康, 等. 基于非水平位移的激光跟踪仪测角误差标定方法[J]. 新技术新工艺, 2021(2):73-76

    Li Hui, Wu Jiahao, Zhao Weikang, et al. Calibration method of angle error of laser tracker based on non-horizontal displacement[J]. New Technology & New Process, 2021(2): 73-76
    [12] 欧阳健飞, 刘万里, 闫勇刚, 等. 激光跟踪仪坐标测量精度的研究[J]. 红外与激光工程, 2008, 37(s1):15-18

    Ouyang Jianfei, Liu Wanli, Yan Yonggang, et al. Coordinate measuring accuracy of laser tracker[J]. Infrared and laser Engineering, 2008, 37(s1): 15-18
    [13] 马郦群, 王继虎, 曹铁泽, 等. 激光跟踪仪测角误差的位移标定法[J]. 计量学报, 2009, 30(5A):76-78

    Ma Liqun, Wang Jihu, Cao Tieze, et al. Calibration for angular error of laser tracker by small displacement[J]. Acta Metrologica Sinica, 2009, 30(5A): 76-78
    [14] 谢政委, 林嘉睿, 邾继贵, 等. 基于空间长度约束的坐标控制场精度增强方法[J]. 中国激光, 2015, 42:0108005 doi: 10.3788/CJL201542.0108005

    Xie Zhengwei, Lin Jiarui, Zhu Jigui, et al. Accuracy enhancement method for coordinate control field based on space length constraint[J]. Chinese Journal of Lasers, 2015, 42: 0108005 doi: 10.3788/CJL201542.0108005
    [15] 张翼飞, 金利民, 樊奕辰, 等. 一种评价三维控制网精度的方法[J]. 测绘通报, 2018(6):126-129

    Zhang Yifei, Jin Limin, Fan Yichen, et al. A method for evaluating the precision of 3D control network[J]. Bulletin of Surveying and Mapping, 2018(6): 126-129
    [16] 张振虎. 激光跟踪仪结合全站仪的三维控制网测量及其精度分析[J]. 北京测绘, 2019, 33(6):708-712

    Zhang Zhenhu. Survey and accuracy analysis for three-dimensional control network using laser tracker and total station[J]. Beijing Surveying and Mapping, 2019, 33(6): 708-712
