高能光源磁铁的三坐标标定技术

韩圆颖; 董岚; 王铜; 卢尚; 闫路平; 张露彦; 刘晓阳; 闫皓月; 门玲鸰; 王小龙; 李波; 梁静; 马娜; 何振强; 柯志勇

doi:10.11884/HPLPB202436.230386

高能光源磁铁的三坐标标定技术

doi: 10.11884/HPLPB202436.230386

韩圆颖^1,,
董岚^{1, 2, ,},
王铜^{1, 2},
卢尚¹,
闫路平¹,
张露彦¹,
刘晓阳¹,
闫皓月¹,
门玲鸰^{1, 2},
王小龙^{1, 2},
李波^{1, 2},
梁静^{1, 2},
马娜^{1, 2},
何振强^{1, 2},
柯志勇^{1, 2}

1.
中国科学院高能物理研究所，北京 100049
2.
东莞中子科学中心，广东东莞 523803

详细信息

作者简介:
韩圆颖，hanyy@ihep.ac.cn

通讯作者:
董　岚，dongl@ihep.ac.cn。

中图分类号: TL506
计量
- 文章访问数: 149
- HTML全文浏览量: 67
- PDF下载量: 25
- 被引次数: 0
出版历程
- 收稿日期: 2024-02-01
- 修回日期: 2024-06-17
- 录用日期: 2024-06-17
- 网络出版日期: 2024-07-08
- 刊出日期: 2024-08-16

Three-dimensional coordinate calibration technology for high energy photon source magnets

Han Yuanying^1
,,
Dong Lan^{1, 2
, ,},
Wang Tong^{1, 2},
Lu Shang¹,
Yan Luping¹,
Zhang Luyan¹,
Liu Xiaoyang¹,
Yan Haoyue¹,
Men Lingling^{1, 2},
Wang Xiaolong^{1, 2},
Li Bo^{1, 2},
Liang Jing^{1, 2},
Ma Na^{1, 2},
He Zhenqiang^{1, 2},
Ke Zhiyong^{1, 2}

1.
Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
2.
Dongguan Neutron Science Center, Dongguan 523803, China

摘要

摘要: 针对高能同步辐射光源需要进行大批量磁铁的中心引出标定，提出了一种基于三坐标测量机的磁铁机械中心标定方案，确定了编写自动测量程序的流程和方法,参与完成了加速器中多种类型磁铁的标定。对176块储存环六极铁的三坐标机测量数据进行分析，结果表明：每块磁铁进行两遍机械中心标定，获得准直基准点的标定重复性在0.01 mm之内；极缝间距离的实测值与设计值标准偏差均在0.015 mm之内；标定效率相较激光跟踪仪提高了2倍。这种借助三坐标测量机的磁铁标定方法可以提高标定精度，降低人力成本，提高工作效率，能为加速器工程中磁铁中心的引出标定工作提供参考，保证加速器装置的安装顺利，满足加速器准直测量的工程进度要求。
- 三坐标测量机 /
- 机械中心标定 /
- 加速器 /
- 准直测量
Abstract: Aiming at the High Energy Photon Source which needs to calibrate the center of a large number of magnets, a scheme of calibrating the center of magnetic machinery based on coordinate measuring machine (CMM) is proposed, the process and method of writing automatic measuring program are determined, and the calibration of various types of magnets in the accelerator is completed. The results show that the calibration repeatability of the reference point of collimation is within 0.01 mm by calibrating the mechanical center twice for each magnet. The standard deviation between the measured value and the design value is within 0.015 mm. The calibration efficiency is 2 times higher than that of the laser tracker. This method of magnet calibration with CMM can improve the calibration accuracy, reduce the labor cost, improve the work efficiency, provide reference for the magnet center extraction calibration in the accelerator work, ensure the smooth installation of the accelerator device, and meet the requirements of the accelerator alignment measurement project schedule.
- coordinate measuring machine /
- mechanical center calibration /
- accelerator /
- alignment survey

HTML全文

图 1 三坐标机标定磁铁

Figure 1. CMM calibration of magnets

下载: 全尺寸图片幻灯片

图 2 激光跟踪仪标定磁铁

Figure 2. Laser tracker calibration of magnets

下载: 全尺寸图片幻灯片

图 3 六极铁极头示意图

Figure 3. Diagram of six iron heads

下载: 全尺寸图片幻灯片

图 4 极平面点位置分布图

Figure 4. Position distribution diagram of polar plane points

下载: 全尺寸图片幻灯片

图 5 六极铁标定坐标系

Figure 5. Hexapole iron calibration coordinate system

下载: 全尺寸图片幻灯片

图 6 三坐标机自动测量

Figure 6. Coordinate machine automatic measurement

下载: 全尺寸图片幻灯片

图 7 激光跟踪仪和三坐标机极头实测数据对比

Figure 7. Comparison of measured data between laser tracker and pole head of coordinate machine

下载: 全尺寸图片幻灯片

表 1 三坐标机参与标定的磁铁数量统计

Table 1. Statistics of the number of magnets involved in calibration by the coordinate machine

type of magnet	corrector magnet	hexacode iron	quadrupole iron	transport line four grade iron
quantity	195	176	30	43

下载: 导出CSV

表 2 HEPS磁铁预准直误差分析

Table 2. Analysis of precollimation error of HEPS magnet mm

magnetic center elicits calibration error	pre-collimation measurement error	pre-collimation adjustment deviation	magnets lock the momentum	the opening and closing momentum of the magnet	magnets transport momentum
0.010	0.010	0.010	0.010	0.010	0.020

下载: 导出CSV

表 3 磁铁极头和外基准面的平面拟合标准偏差对比(储存环176块六极铁)

Table 3. Comparison of the standard deviation of the plane fit between the magnet head and the external datum plane

instrument	standard deviation/mm
instrument	pole seam middle/pole plane	left and right plane	top plane
tracker	0.018	0.045	0.026
CMM	0.009	0.028	0.013

下载: 导出CSV

表 4 HEPS六极铁的标定重复性

Table 4. Calibration repeatability of HEPS sextupole

	maximum positive deviation/mm	minimum negative deviation/mm	standard deviation/mm
ΔX	0.009	−0.009	0.003
ΔY	0.009	−0.008	0.002
ΔZ	0.005	−0.005	0.001

下载: 导出CSV

表 5 HEPS环六极铁极缝偏差统计(176块铁)

Table 5. Pole seam deviation statistics of sextupole of HEPS sextupole

magnet type	maximum positive deviation/mm	minimum negative deviation/mm	standard deviation/mm
SF1/2	0.050	−0.045	0.012
SD1/4	0.047	−0.041	0.014
SD2/3	0.062	−0.082	0.014

下载: 导出CSV
