高温气冷堆主氦风机变阻力工况调试方法

叶林 严义杰 徐伟强 赵峰 陈光建 李超 朱英杰

叶林, 严义杰, 徐伟强, 等. 高温气冷堆主氦风机变阻力工况调试方法[J]. 强激光与粒子束, 2024, 36: 076001. doi: 10.11884/HPLPB202436.230444
引用本文: 叶林, 严义杰, 徐伟强, 等. 高温气冷堆主氦风机变阻力工况调试方法[J]. 强激光与粒子束, 2024, 36: 076001. doi: 10.11884/HPLPB202436.230444
Ye Lin, Yan Yijie, Xu Weiqiang, et al. Commission method of the primary helium circulator of HTGR under variable resistance condition[J]. High Power Laser and Particle Beams, 2024, 36: 076001. doi: 10.11884/HPLPB202436.230444
Citation: Ye Lin, Yan Yijie, Xu Weiqiang, et al. Commission method of the primary helium circulator of HTGR under variable resistance condition[J]. High Power Laser and Particle Beams, 2024, 36: 076001. doi: 10.11884/HPLPB202436.230444

高温气冷堆主氦风机变阻力工况调试方法

doi: 10.11884/HPLPB202436.230444
基金项目: 华能集团高温气冷堆示范工程调试关键技术研究(HNKJ15-H19)
详细信息
    作者简介:

    叶 林,yelin@sdwgs.chng.com.cn

    通讯作者:

    严义杰,yyjwolf9527@163.com

  • 中图分类号: TL334

Commission method of the primary helium circulator of HTGR under variable resistance condition

  • 摘要: 高温气冷堆主氦风机调试期间,由于一回路阻力低于设计工况,因而主氦风机无法完成全转速范围性能测试。基于主氦风机的理论特性与相似原理开发主氦风机不同阻力工况调试参数的推算方法。结合主氦风机单体试验工况点,准确推算主氦风机冷态与热态性能试验的工况点参数,并指导完成高温气冷堆主氦风机全转速、满功率性能测试。通过对主氦风机调试与出厂试验结果的对比分析,验证本推算方法的可行性,并给出空气介质与氦气介质工况转换的修正因子。通过主氦风机调试与运行数据的对比分析,可以看出本文提供的主氦风机调试工况具有足够的包络性,能够覆盖高温气冷堆运行期间主氦风机的所有运行工况,证明了本文提供的变阻力工况主氦风机调试方法满足高温气冷堆主氦风机性能验证需求,可用于指导后续高温气冷堆的主氦风机调试工作。
  • 图  1  HTR-PM一回路流程图

    Figure  1.  Primary loop flowchart of HTR-PM

    图  2  离心风机工作特性与管网阻力关系示意图

    Figure  2.  Relationship between the characteristics of centrifugal fans and the resistance of pipe network

    图  3  离心叶轮工质流动示意图

    Figure  3.  Schematic diagram of working medium flow in centrifugal impeller

    图  4  离心叶轮出口速度三角形示意图

    Figure  4.  Schematic diagram of centrifugal impeller outlet velocity triangle

    图  5  主氦风机冷态试验运行点在其性能曲线上的分布

    Figure  5.  Distribution of the cold test operation points of the primary helium circulator on its performance curve

    图  6  主氦风机热态试验运行点在其性能曲线上的分布

    Figure  6.  Distribution of thermal test operation points of the primary helium circulator on its performance curve

    表  1  主氦风机的主要参数[3]

    Table  1.   Main parameters of primary helium circulator

    working fluid pressure/MPa flow rate/(kg/s) pressure rise/kPa rated speed/(r/min) rated electrical power/kW
    helium 7 96 200 4000 4500
    下载: 导出CSV

    表  2  主氦风机试验介质压力换算

    Table  2.   Conversion of test pressure of primary helium circulator

    test working fluid temperature/℃ pressure/MPa power*/kW density/(kg/m3)
    monomeric test air 19.3 0.10 1019.1 1.19
    cold test air 25.0 0.45 4500.0 5.27
    hot test helium 250.0 5.73 4500.0 5.27
    *: $ {n}_{\max} $ is equal to 4000 r/min
    下载: 导出CSV

    表  3  不同工况下主氦风机运行情况

    Table  3.   Operation of primary helium circulator under different working conditions

    work condition speed/(r/min) current/A voltage/V power/kW pressure rise/kPa flow rate/(kg/s) pressure/MPa inlet temperature/℃
    3600 523.7 5614 4218 122.2 127.3 6.9 239.9
    4000 516 6147 4648 145.2 116.0 5.31 235.9
    3800 580 6000 4500 200 96 7.0 243
    ①: primary helium circulator operation at 200 MW
    ②: the hot function test of primary helium circulator
    ③: rated parameters and some design limits for primary helium circulator
    下载: 导出CSV
  • [1] Reutler H, Lohnert G H. Advantages of going modular in HTRs[J]. Nuclear Engineering and Design, 1984, 78(2): 129-136. doi: 10.1016/0029-5493(84)90298-X
    [2] 曾斌, 李言瑞. 高温气冷堆如何助力“双碳”?[J]. 能源, 2022, 15(8):31-34

    Zeng Bin, Li Yanrui. How high-temperature gas-cooled reactors can help carbon peaking and carbon neutrality?[J]. Energy, 2022, 15(8): 31-34
    [3] 邹德宝. 高温气冷堆核电站示范工程主氦风机技术概述[J]. 防爆电机, 2011, 46(4):5-7

    Zou Debao. Technical overview on main helium ventilator of high-temperature gas-cooled reactor nuclear power plant[J]. Explosion-Proof Electric Machine, 2011, 46(4): 5-7
    [4] Gambini M, Vellini M. Turbomachinery: fundamentals, selection and preliminary design[M]. Cham: Springer, 2021: 89-107.
    [5] 张作义, 原鲲. 我国高温气冷堆技术及产业化发展[J]. 现代物理知识, 2018, 30(4): 3-10

    Zhang Zuoyi, Yuan Kun. High temperature gas cooled reactor technology and industrial development in China[J]. Modern Physics, 2018, 30(4): 8-9
    [6] 周惠忠, 王捷, 汤全法. HTR-10主氦循环风机的设计、试验和运行[J]. 核动力工程, 2004, 25(1):54-58

    Zhou Huizhong, Wang Jie, Tang Quanfa. Design, test and operation of helium circulator for HTR-10[J]. Nuclear Power Engineering, 2004, 25(1): 54-58
    [7] 彭浩然, 孙俊. 高温气冷堆堆芯球床的流动与换热分析[J]. 工程热物理学报, 2016, 37(5):1076-1083

    Peng Haoran, Sun Jun. Investigation of flow and heat transfer in the pebble bed of the high temperature gas-cooled reactor[J]. Journal of Engineering Thermophysics, 2016, 37(5): 1076-1083
    [8] 张双宝, 李良星, 谢伟, 等. 球床式高温气冷堆堆芯三维建模及稳态热工水力分析[J]. 中国科学院大学学报, 2020, 37(2):186-191

    Zhang Shuangbao, Li Liangxing, Xie Wei, et al. Three-dimensional modeling of pebble bed type high temperature gas-cooled reactor core and steady-state thermal hydraulic analysis[J]. Journal of University of Chinese Academy of Sciences, 2020, 37(2): 186-191
    [9] 陈卓. HTR-PM主氦风机叶轮气动性能优化研究[D]. 衡阳: 南华大学, 2020: 9-22

    Chen Zhuo. Study on the aerodynamic performance optimization of the impeller of the helium circulator of HTR-PM[D]. Hengyang: University of South China, 2020: 9-22
    [10] 蔡兆麟, 刘华堂, 何国庚. 能源与动力装置基础[M]. 北京: 中国电力出版社, 2004: 58-90

    Cai Zhaolin, Liu Huatang, He Guogeng. Fundamentals of energy and power equipment[M]. Beijing: China Electric Power Press, 2004: 58-90
    [11] 王捷, 周惠忠, 汤全法. HTR-10主氦风机性能试验研究[J]. 高技术通讯, 2002, 12(11):96-100

    Wang Jie, Zhou Huizhong, Tang Quanfa. Performance test of HTR-10 helium circulator[J]. Chinese High Technology Letters, 2002, 12(11): 96-100
    [12] 王捷, 周惠忠. HTR-10一回路流道气动特性和主氦风机运行参数的研究[J]. 高技术通讯, 2003, 13(3):92-97

    Wang Jie, Zhou Huizhong. Study on pneumatic features of primary system and operation parameters of helium circulator for HTR-10[J]. Chinese High Technology Letters, 2003, 13(3): 92-97
