High throughput of cell irradiation with microfluidics in single ion microbeam system
-
摘要: 辐照通量是指单位时间里离子辐照的细胞数量，是单离子束细胞辐照系统的重要性能指标。为提高单离子定位辐照通量，将微流控技术应用于单离子束细胞辐照系统，实现了单离子-单细胞精确定位自动辐照技术。微流控芯片上建立细胞储液池、O2和CO2注入通道、恒温加热、pH检测、细胞检测等功能机构。细胞微流受驱动在通道中保持运动，离子经微流控芯片辐照点射入微通道，对动态细胞进行辐照。基于CAS-LIBB装置，建立离子定位微流细胞的计算模型，研究离子精确瞄准微流细胞的基本方法和规律，获得微流细胞速度、最大辐照通量、辐照剂量、细胞间距等多个参量之间的相互约束关系，成为系统运行的理论指导。提出“即测即打”运行模式，以加快辐照速度，提高离子定位准确性。结果表明，细胞速度和辐照通量均存在上限值，提高微流细胞数密度和离子发射密度，是提高辐照通量的可选方法。采用微流控技术后，辐照通量达到
10000 细胞/h，相比之前提高10倍以上。计算数据和实验结果基本吻合。Abstract: The irradiation throughout means the amount of the cells irradiated per unit time, which is the important performance indicator of a single ion microbeam system. To improve the single ion localization irradiation throughout, microfluidic chip technology is applied to the single ion beam cell irradiation system with single ion to single cell auto-irradiation. A cell storage pool, O2 and CO2 injection channels, constant temperature control, pH detection and cell inspection are built on the chip. Ions irradiate the moving cells through the irradiation point on the microfluidic chip. Based CAS-LIBB system, this article establishes a computational model for ion targeting microfluidic cells. The basic methods and laws of ion targeting microfluidic cells are studied, therefore it has obtained the multi-relationships among cell velocity, irradiation throughout, irradiation dose, and cell separation, which are the theoretical guidance for system operation. A mode of “Promptly Irradiate with Inspected” is proposed to improve the irradiating effectivity and accuracy. The results show that there is an upper limit for cell speed as well as for irradiation throughout, and increasing cell number density and ion emission density are the most feasible ways to raise the irradiation throughout. With the microfluidic technology, the irradiation throughout now reaches10000 cells/h, more than 10 times higher than before. The calculated data is basically consistent with the experimental results. -
图 4 两个离子相继辐照一个运动细胞，准直器固定不动，细胞上两击中点的间距须小于a，a为细胞尺度， b为束斑直径
Figure 4. Two ions irradiate a cell successively, separation of the two hit points on cell is a, collimator is fixed, b is the beam spot diameter
图 5 微流通道中单列细胞数密度
Figure 5. Number density of the single-row cells in the microfluidic channel
表 1 设计实例数据
Table 1. Data of a design example
k d/mm n/s−1 m/μL−1 vm/(mm·s−1) Qmax /h−1 Q/h−1 relative error/% 2 1.0 1000 2500 8.5 30600 − − 2 1.0 2000 2500 17.0 61200 invalid − 5 1.0 1000 2500 3.4 12240 11861 −3.1 5 1.0 2000 2500 6.8 24480 23427 −4.3 10 1.0 1000 2500 1.7 6120 5954 −2.7 10 1.0 2000 2500 3.4 12240 11775 −3.8
下载: 导出CSV
-
[1] Hu Zhiwen, Chen Lianyun, Li Jun, et al. High-localized cell irradiation at the CAS-LIBB single-particle microbeam[J]. Nuclear Instruments and Methods in Physics Research Section B: Beam Interactions with Materials and Atoms, 2006, 244(2): 462-466. [2] 詹福如, 许明亮, 许永建, 等. 单离子束技术概述[J]. 强激光与粒子束, 2007, 19(11):1913-1917Zhan Furu, Xu Mingliang, Xu Yongjian, et al. Review of single ion microbeam technology[J]. High Power Laser and Particle Beams, 2007, 19(11): 1913-1917 [3] Randers-Pehrson G, Geard C R, Johnson G, et al. The Columbia University single-ion microbeam[J]. Radiation Research, 2001, 156(2): 210-214. doi: 10.1667/0033-7587(2001)156[0210:TCUSIM]2.0.CO;2 [4] Shafirkin A V, Grigoriev Y G, Ushakov I B. More precise determination of the relative biological effectiveness of fast neutrons and accelerated multi-charged ions at low doses for estimation of the risk of injury of brain and lens neurons[J]. Human Physiology, 2020, 46(7): 722-730. doi: 10.1134/S0362119720070130 [5] Almahwasi A. Low dose hyper-radiosensitivity in normal human cells[J]. Radiation Physics and Chemistry, 2023, 202: 110523. doi: 10.1016/j.radphyschem.2022.110523 [6] Joshi G S, Joiner M C, Tucker J D. Cytogenetic characterization of low-dose hyper-radiosensitivity in Cobalt-60 irradiated human lymphoblastoid cells[J]. Mutation Research/Fundamental and Molecular Mechanisms of Mutagenesis, 2014, 770: 69-78. doi: 10.1016/j.mrfmmm.2014.09.006 [7] Brenner D J, Elliston C D. The potential impact of bystander effects on radiation risks in a mars mission[J]. Radiation Research, 2001, 156(5): 612-617. doi: 10.1667/0033-7587(2001)156[0612:TPIOBE]2.0.CO;2 [8] Abdelhakm L O, Kandil E I, Mansour S Z, et al. Chrysin encapsulated copper nanoparticles with low dose of gamma radiation elicit tumor cell death through p38 MAPK/NF-κB pathways[J]. Biological Trace Element Research, 2023, 201(11): 5278-5297. doi: 10.1007/s12011-023-03596-1 [9] Okada M, Okabe A, Uchihori Y, et al. Single extreme low dose/low dose rate irradiation causes alteration in lifespan and genome instability in primary human cells[J]. British Journal of Cancer, 2007, 96(11): 1707-1710. doi: 10.1038/sj.bjc.6603775 [10] Zhou Hongning, Randers-Pehrson G, Geard C R, et al. Interaction between radiation-induced adaptive response and bystander mutagenesis in mammalian cells[J]. Radiation Research, 2003, 160(5): 512-516. doi: 10.1667/RR3083 [11] Guo Xiaoying, Sun Jie, Bian Po, et al. Radiation-induced bystander signaling from somatic cells to germ cells in Caenorhabditis elegans[J]. Radiation Research, 2013, 180(3): 268-275. doi: 10.1667/RR3218.1 [12] Yang Gen, Wu Lijun, Chen Lianyun, et al. Targeted irradiation of shoot apical meristem of Arabidopsis embryos induces long-distance bystander/abscopal effects[J]. Radiation Research, 2007, 167(3): 298-305. doi: 10.1667/RR0710.1 [13] Li Lu, Wang Lu, Prise K M, et al. Akt/mTOR mediated induction of bystander effect signaling in a nucleus independent manner in irradiated human lung adenocarcinoma epithelial cells[J]. Oncotarget, 2017, 8(11): 18010-18020. doi: 10.18632/oncotarget.14931 [14] Hu Beiyu, Xu Bingxue, Yun Juanli, et al. High-throughput single-cell cultivation reveals the underexplored rare biosphere in deep-sea sediments along the Southwest Indian Ridge[J]. Lab on a Chip, 2020, 20(2): 363-372. doi: 10.1039/C9LC00761J [15] 姚波, 何巧红, 杜文斌, 等. 微流控高通量试样引入技术的研究进展[J]. 色谱, 2009, 27(5):662-666 doi: 10.3321/j.issn:1000-8713.2009.05.018Yao Bo, He Qiaohong, Du Wenbin, et al. Developments of high-throughput microfluidic sample introduction techniques[J]. Chinese Journal of Chromatography, 2009, 27(5): 662-666 doi: 10.3321/j.issn:1000-8713.2009.05.018 [16] Simchi M, Riordon J, Wang Yihe, et al. High-throughput sperm DNA analysis at the single-cell and population levels[J]. Analyst, 2023, 148(16): 3748-3757. doi: 10.1039/D3AN00564J [17] Buonanno M, Garty G, Grad M, et al. Microbeam irradiation of C. elegans nematode in microfluidic channels[J]. Radiation and Environmental Biophysics, 2013, 52(4): 531-537. doi: 10.1007/s00411-013-0485-6 [18] Chen Dongwei, Nie Mengyue, Tang Wei, et al. Whole lifecycle observation of single-spore germinated Streptomyces using a nanogap-stabilized microfluidic chip[J]. mLife, 2022, 1(3): 341-349. doi: 10.1002/mlf2.12039 [19] Zhou Yang, Yu Zhibin, Wu Man, et al. Single-cell sorting using integrated pneumatic valve droplet microfluidic chip[J]. Talanta, 2023, 253: 124044. doi: 10.1016/j.talanta.2022.124044 [20] Gebreyesus S T, Muneer G, Huang C C, et al. Recent advances in microfluidics for single-cell functional proteomics[J]. Lab on a Chip, 2023, 23(7): 1726-1751. doi: 10.1039/D2LC01096H [21] Roper M G. Cellular analysis using microfluidics[J]. Analytical Chemistry, 2016, 88(1): 381-394. doi: 10.1021/acs.analchem.5b04532 [22] Tkaczyk A H, Tkaczyk E R, Norris T B, et al. Microfluidic droplet consistency monitoring and encapsulated cell detection via laser excitation[J]. Journal of Mechanics in Medicine and Biology, 2011, 11(1): 1-14. doi: 10.1142/S0219519410003617 [23] Larson A P, Ahlberg H, Folestad S. Semiconductor laser-induced fluorescence detection in picoliter volume flow cells[J]. Applied Optics, 1993, 32(6): 794-805. doi: 10.1364/AO.32.000794 [24] Zhan Furu, Qi Xuehong, Xu Mingliang, et al. Improvement of the energy stability of the single ion microbeam[J]. Plasma Science and Technology, 2008, 10(2): 250-253. doi: 10.1088/1009-0630/10/2/23 [25] Xu Mingliang, Xu Yongjian, Zhan Furu, et al. Analysis and optimization of stability of CAS-LIBB single ion microbeam[J]. Plasma Science and Technology, 2008, 10(5): 651-654. doi: 10.1088/1009-0630/10/5/24 -
