辉光放电触发重频伪火花开关研究

丁闻婧 冯进军 张明 杨鸿飞

丁闻婧, 冯进军, 张明, 等. 辉光放电触发重频伪火花开关研究[J]. 强激光与粒子束, 2024, 36: 055012. doi: 10.11884/HPLPB202436.240036
引用本文: 丁闻婧, 冯进军, 张明, 等. 辉光放电触发重频伪火花开关研究[J]. 强激光与粒子束, 2024, 36: 055012. doi: 10.11884/HPLPB202436.240036
Ding Wenjing, Feng Jinjun, Zhang Ming, et al. Study on glow discharge triggered repetitive frequency pseudospark switch[J]. High Power Laser and Particle Beams, 2024, 36: 055012. doi: 10.11884/HPLPB202436.240036
Citation: Ding Wenjing, Feng Jinjun, Zhang Ming, et al. Study on glow discharge triggered repetitive frequency pseudospark switch[J]. High Power Laser and Particle Beams, 2024, 36: 055012. doi: 10.11884/HPLPB202436.240036

辉光放电触发重频伪火花开关研究

doi: 10.11884/HPLPB202436.240036
详细信息
    作者简介:

    丁闻婧,2563582948@qq.com

    通讯作者:

    冯进军fengjinjun@tsinghua.org.cn

  • 中图分类号: TN134

Study on glow discharge triggered repetitive frequency pseudospark switch

  • 摘要: 伪火花开关是工作在帕邢曲线左支的低气压开关,具有纳秒级击穿时间、百千安级脉冲电流、工作寿命长等特点。具有高重频性能的伪火花开关民用领域以及军事领域均有广泛的应用需求。基于双脉冲辉光放电触发结构,设计出一种具有重频能力的伪火花开关;在10 kV阳极电压下进行了整管测试,观察不同气压,预、主触发电压对重频性能以及触发性能的影响;结合仿真软件计算不同气压与触发电压下,触发电流的变化,最终总结了两个脉冲对触发过程的影响。测试结果表明,最低仅100 V触发电压,开关重复频率即可从沿面放电触发的100 Hz提升至400 Hz。
  • 图  1  伪火花开关结构

    Figure  1.  Pseudospark switch structure

    1-hollow anode; 2-hollow cathode; 3-gate; 4-insulating ceramic; 5-trigger electrode; 6-hydrogen storage

    图  2  辉光放电-双脉冲触发的伪火花开关

    Figure  2.  Glow discharge - double pulse triggered pseudospark switch

    图  3  测试电路原理图

    Figure  3.  Schematics of test circuit

    Ea- high voltage DC power supply; Utcp1- main trigger voltage; Utcp2- pre-trigger voltage; UH-hydrogen storage voltage; G- pseudospark switch under test; Ra- charge resistor; Rb- equalizing resistor; RL- load resistor; PFN- pulse forming network

    图  4  测试现场

    Figure  4.  Test site

    图  5  阳极电压波形图

    Figure  5.  Anode voltage waveforms

    图  6  氢压UH对于重复频率的影响

    Figure  6.  Effect of hydrogen pressure UH on pulse repetition frequency

    图  7  仿真模拟下,不同气压(10~90 Pa)对阴极电流的影响

    Figure  7.  Influence of different air pressure (10~90 Pa) on cathode current under simulation

    图  8  不同预触发电压对重复频率的影响

    Figure  8.  Influence of different pre-trigger voltages on pulse repetition frequency

    图  9  仿真模拟下,主触发电压Utcp1=1.0 kV时,预触发电压Utcp2对触发电流的影响

    Figure  9.  When the main trigger voltage Utcp1= 1.0 kV, the influence of the pre-trigger voltage Utcp2 on the trigger current under simulation

    图  10  不同预触发电压Utcp2下,重复频率随主触发电压Utcp1变化

    Figure  10.  Under different pre-trigger voltages Utcp2, the pulse repetition frequency changes with the main trigger voltage Utcp1

    表  1  国内外重频伪火花开关参数对比

    Table  1.   Comparison of repetitive frequency pseudospark switches

    model anode
    voltage/kV
    cathode pulsating
    current/kA
    average anode
    current/A
    pulse repetition
    frequency/kHz
    size/mm life
    span/C
    trigger
    mode
    TD-150k/25 25 150 1.5 0.1 ϕ150 mm×110 mm 5×105 surface discharge
    TPI-10k/25 25 10 1.5 20 ϕ100 mm×160 mm 1×106 glow discharging
    TPI-10k/50 50 10 0.35 3 ϕ100 mm×190 mm 1×106 glow discharging
    VE4172 40 30 0.5 0.1 ϕ150 mm×167 mm 1×105 surface discharge
    下载: 导出CSV
  • [1] Akimov A V, Logachev P V, Bochkov V D, et al. Application of TPI-thyratrons in a double-pulse mode power modulator with inductive-resistive load[J]. IEEE Transactions on Dielectrics and Electrical Insulation, 2010, 17(3): 716-720. doi: 10.1109/TDEI.2010.5492243
    [2] Bochkov V D, Bochkov D V, Gnedin I N, et al. High voltage pulse generator based on TPI-thyratron for pulsed electric field milk processing[C]//2012 IEEE International Power Modulator and High Voltage Conference (IPMHVC). 2012: 98-101.
    [3] 张明, 周亮, 栾小燕, 等. 面向脉冲功率技术需求的伪火花开关技术[J]. 真空电子技术, 2021(1):1-9

    Zhang Ming, Zhou Liang, Luan Xiaoyan, et al. Pseudo-spark switch technologies for pulsed power sources[J]. Vacuum Electronics, 2021(1): 1-9
    [4] Bloess D, Kamber I, Riege H, et al. The triggered pseudo-spark chamber as a fast switch and as a high-intensity beam source[J]. Nuclear Instruments and Methods in Physics Research, 1983, 205(1/2): 173-184.
    [5] Bochkov V D, Bochkov D V, Dyagilev V M, et al. Development of high-power gas discharge and electronic vacuum devices for pulsed electrophysic. Current status and prospects[J]. AIP Conference Proceedings, 2016, 1771: 070005.
    [6] 栾小燕, 张明, 周亮. 一种新型大电流脉冲调制器件——伪火花开关[J]. 真空电子技术, 2012(5):38-41,58

    Luan Xiaoyan, Zhang Ming, Zhou Liang. A new pulse modulator device for large current—pseudospark switch[J]. Vacuum Electronics, 2012(5): 38-41,58
    [7] Beouf J P, Pitchford L C. Pseudospark discharges via computer simulation[J]. IEEE Transactions on Plasma Science, 1991, 19(2): 286-296. doi: 10.1109/27.106826
    [8] 徐远灿, 刘庆想, 王庆峰, 等. 冷阴极闸流管的同步特性[J]. 强激光与粒子束, 2010, 22(4):717-720 doi: 10.3788/HPLPB20102204.0717

    Xu Yuancan, Liu Qingxiang, Wang Qingfeng, et al. Synchronization characteristics of cold cathode thyratron[J]. High Power Laser and Particle Beams, 2010, 22(4): 717-720 doi: 10.3788/HPLPB20102204.0717
    [9] Bochkov V D, Dyagilev V M, Ushich V G, et al. Sealed-off pseudospark switches for pulsed power applications (current status and prospects)[J]. IEEE Transactions on Plasma Science, 2001, 29(5): 802-808. doi: 10.1109/27.964478
    [10] Bochkov V D, Botchkov D V, Dyagilev V M, et al. Triggering of pseudospark switches[C]//20th International Symposium on Discharges and Electrical Insulation in Vacuum. 2002: 592-594.
    [11] 赵征, 周亮, 栾小燕, 等. 新型小体积伪火花开关研制[J]. 强激光与粒子束, 2023, 35:035002 doi: 10.11884/HPLPB202335.220290

    Zhao Zheng, Zhou Liang, Luan Xiaoyan, et al. Development of miniature pseudo-spark switch[J]. High Power Laser and Particle Beams, 2023, 35: 035002 doi: 10.11884/HPLPB202335.220290
