大功率高能脉冲激光电源设计

李贺龙 徐健 杨之青 宋家豪 吴周宇 汤义辉 赵爽 丁立健

李贺龙, 徐健, 杨之青, 等. 大功率高能脉冲激光电源设计[J]. 强激光与粒子束, 2024, 36: 055008. doi: 10.11884/HPLPB202436.240045
引用本文: 李贺龙, 徐健, 杨之青, 等. 大功率高能脉冲激光电源设计[J]. 强激光与粒子束, 2024, 36: 055008. doi: 10.11884/HPLPB202436.240045
Li Helong, Xu Jian, Yang Zhiqing, et al. Design of high-power repetitive pulse laser power supply[J]. High Power Laser and Particle Beams, 2024, 36: 055008. doi: 10.11884/HPLPB202436.240045
Citation: Li Helong, Xu Jian, Yang Zhiqing, et al. Design of high-power repetitive pulse laser power supply[J]. High Power Laser and Particle Beams, 2024, 36: 055008. doi: 10.11884/HPLPB202436.240045

大功率高能脉冲激光电源设计

doi: 10.11884/HPLPB202436.240045
基金项目: 合肥综合性国家科学中心能源研究院科研项目(24JYDL01)
详细信息
    作者简介:

    李贺龙,helong.li@hfut.edu.cn

    通讯作者:

    杨之青,zhiqing.yang@hfut.edu.cn

  • 中图分类号: TM51

Design of high-power repetitive pulse laser power supply

  • 摘要: 根据YAG激光器对大功率高能量脉冲电源的应用需求,设计了一种大功率脉冲激光电源,可实现高脉冲能量重复频率输出及充电电压灵活调控。前级充电网络采用串联LC谐振变换器,后级脉冲形成网络选择晶闸管触发LC放电电路。最终,研制了1台7 kW实验样机,最大重复频率10 Hz,最高充电电压2.2 kV,可实现单脉冲最高700 J电能输出,满足大功率高能脉冲输出的应用需求,实验测试结果验证了设计的可行性。
  • 图  1  电源组成图

    Figure  1.  Composition diagram of the developed power supply

    图  2  串联LC谐振变换器四种工作模态图

    Figure  2.  Four working states of the convertor series LC resonant

    图  3  所测试氙灯在不同条件下的等效电阻

    Figure  3.  Equivalent resistance of the xenon lamp under various conditions

    图  4  设计的脉冲激光电源测试平台

    Figure  4.  Developed laser pulse power supply test bench

    图  5  实验波形图

    Figure  5.  Experimental waveforms

    图  6  激光器输出能量

    Figure  6.  Laser output energy

    表  1  样机参数

    Table  1.   Prototype parameters

    Uin/V C1/μF Cr/μF Lr/μH n C2/μF L/μH fr/kHz f/skHz f/Hz Pmax/kW
    220 (50 Hz) 420 0.44 28 1∶5.2 300 80 45 22 10 7.26
    下载: 导出CSV

    表  2  输出能量实验结果

    Table  2.   Output energy experimental results

    voltage/kV single output
    energy/J
    max output
    fluctuation/%
    1.6 6.63 0.60
    1.8 8.19 0.49
    2.0 9.47 0.42
    2.2 10.16 0.39
    下载: 导出CSV
  • [1] Ahn J B, Song S H, Ryoo H J. Design and implementation of 3-kW simmer and 30-kV DC trigger power supply system for driving xenon flash lamps in large-area processes[J]. IEEE Transactions on Industrial Electronics, 2022, 69(12): 11999-12008. doi: 10.1109/TIE.2021.3128898
    [2] Tandon S, Rathore A K. Current-fed full-bridge series LC resonance impulse ZCS commutated DC-DC converter[C]//2020 IEEE International Conference on Power Electronics, Smart Grid and Renewable Energy (PESGRE2020). 2020: 1-6.
    [3] Lu Jingjie, Liu Yikun, Ji Junpeng. Research on circuit topology of high voltage DC pulse power supply for removing wide-diameter dust[C]//2018 Chinese Automation Congress (CAC). 2018: 3133-3136.
    [4] Cho C G, Song S H, Park S M, et al. A novel series-connected xenon lamp power supply system using a pulse trigger with simmer circuits for pulsed light sintering application[J]. IEEE Transactions on Industrial Electronics, 2019, 66(1): 233-244. doi: 10.1109/TIE.2018.2818654
    [5] Mishra R K, Joshi D, Agrawal P K. Effect on timing drift due to temperature variation in high voltage pulse power supply[C]//2020 International Conference on Power, Energy, Control and Transmission Systems (ICPECTS). 2020: 1-5.
    [6] 彭享, 叶兵, 朱旗, 等. 一种高压脉冲电源设计[J]. 合肥工业大学学报(自然科学版), 2017, 40(11):1511-1514

    Peng Xiang, Ye Bing, Zhu Qi, et al. Design of a high voltage pulse power supply[J]. Journal of Hefei University of Technology (Natural Science), 2017, 40(11): 1511-1514
    [7] 陈洪海, 胡宝共, 聂凤明, 等. YAG脉冲激光电源硬件电路的设计[J]. 电子设计工程, 2011, 19(4):85-87

    Chen Honghai, Hu Baogong, Nie Fengming, et al. Design of hardware circuit of YAG pulsed laser power supply[J]. Electronic Design Engineering, 2011, 19(4): 85-87
    [8] 李波, 李博婷, 黄斌, 等. 高可靠性脉冲氙灯电源设计[J]. 强激光与粒子束, 2017, 29:065004 doi: 10.11884/HPLPB201729.160468

    Li Bo, Li Boting, Huang Bin, et al. Design of high reliability pulse xenon lamp power supply[J]. High Power Laser and Particle Beams, 2017, 29: 065004 doi: 10.11884/HPLPB201729.160468
    [9] Ma Yufei, Li Xudong, Ge Lin, et al. Comparison between tape casting YAG/Nd: YAG/YAG and Nd: YAG ceramic lasers[C]//2017 Conference on Lasers and Electro-Optics Pacific Rim (CLEO-PR). 2017: 1-3.
    [10] 魏哲. 1064 nm双频Nd: YAG激光器及其放大特性研究[D]. 西安: 西北大学, 2022

    Wei Zhe. Research on 1064 nm dual frequency Nd: YAG laser and amplification characteristics[D]. Xi’an: Northwest University, 2022
    [11] 庄书琴. 大功率脉冲激光电源充电变换器的研究[D]. 武汉: 华中科技大学, 2008

    Zhuang Shuqin. Researches on the charging converter of high power pulsation laser power supply[D]. Wuhan: Huazhong University of Science and Technology, 2008
    [12] Wang Hui, An Kaiqiang, Wang Zeyu, et al. Interleaved boost-integrated LC series resonant converter with pulse frequency modulation for wide voltage range applications[C]//2022 4th International Conference on Smart Power & Internet Energy Systems (SPIES). 2022: 809-813.
    [13] 梁勖, 赵读亮, 林颖, 等. 基于可控LC串联谐振的高重频高精度脉冲充电电源[J]. 高电压技术, 2018, 44(9):3022-3027

    Liang Xu, Zhao Duliang, Lin Ying, et al. High repetition rate and high accuracy capacitor charging pulse power supply based on controllable LC series resonance[J]. High Voltage Engineering, 2018, 44(9): 3022-3027
    [14] 王晓东. 强脉冲光治疗机的控制技术研究[D]. 天津: 天津大学, 2009

    Wang Xiaodong. Study on the control technology of the intense pulsed light system[D]. Tianjin: Tianjin University, 2009
    [15] 薛志洋. 触发预燃一体化脉冲固体激光器电源的研究[D]. 哈尔滨: 哈尔滨工业大学, 2016

    Xue Zhiyang. Study on the integration of trigger and simmer about pulsed solid-state laser power supply[D]. Harbin: Harbin Institute of Technology, 2016
