北斗/GPS导航系统抗高功率微波防护设计

韩曹政 王武斌 赵伟 陈瑞涛 马兴旺 李艳玲 白嘉琪

韩曹政, 王武斌, 赵伟, 等. 北斗/GPS导航系统抗高功率微波防护设计[J]. 强激光与粒子束, 2024, 36: 123001. doi: 10.11884/HPLPB202436.240219
引用本文: 韩曹政, 王武斌, 赵伟, 等. 北斗/GPS导航系统抗高功率微波防护设计[J]. 强激光与粒子束, 2024, 36: 123001. doi: 10.11884/HPLPB202436.240219
Han Caozheng, Wang Wubin, Zhao Wei, et al. Protection design of BD/GPS navigation system to resist high power microwave[J]. High Power Laser and Particle Beams, 2024, 36: 123001. doi: 10.11884/HPLPB202436.240219
Citation: Han Caozheng, Wang Wubin, Zhao Wei, et al. Protection design of BD/GPS navigation system to resist high power microwave[J]. High Power Laser and Particle Beams, 2024, 36: 123001. doi: 10.11884/HPLPB202436.240219

北斗/GPS导航系统抗高功率微波防护设计

doi: 10.11884/HPLPB202436.240219
基金项目: 国家重点研发计划项目(2022YFE0204200);重点实验室基金项目(6142205230403)
详细信息
    作者简介:

    韩曹政,czheng991@163.com

  • 中图分类号: TN965.2

Protection design of BD/GPS navigation system to resist high power microwave

  • 摘要: 为提升北斗/GPS导航接收系统抗高功率微波的防护效能,采用场路协同仿真设计的方法,分析了北斗/GPS天线在高功率微波辐照下的响应特性,仿真得到天线端口的耦合电压量值。为实现对高功率微波的防护,设计两级防护电路,通过构建稳态电路和瞬态电路模型,对插入损耗和泄漏电压进行仿真分析,并对防护电路进行了加工。测试结果表明:防护电路在2 kW的窄带高功率微波注入下,泄漏功率小于0.5 W;在1411 V的超宽谱高功率微波注入下,泄漏电压小于12 V,可实现对高功率微波的有效抑制。同时将防护电路装配到北斗/GPS导航天线内,导航系统可正常工作。
  • 图  1  天线仿真模型

    Figure  1.  Simulation model of antenna

    图  2  驻波比

    Figure  2.  Curve of VSWR

    图  3  轴比曲线

    Figure  3.  Curve of axial ratio

    图  4  辐射方向图

    Figure  4.  Radiation pattern

    图  5  窄带高功率微波辐照波形

    Figure  5.  Irradiation waveform of HPM-NS

    图  6  天线端口电压

    Figure  6.  Voltage of antenna port

    图  7  超宽谱高功率微波辐照波形

    Figure  7.  Irradiation waveform of HPM-UWS

    图  8  天线端口电压

    Figure  8.  Voltage of antenna port

    图  9  天线防护总体设计框图

    Figure  9.  Overall design block diagram of antenna protection

    图  10  小信号等效电路

    Figure  10.  Equivalent circuit of small signal

    图  11  瞬态电路

    Figure  11.  Transient circuit

    图  12  输出电压

    Figure  12.  Output voltage

    图  13  插入损耗测试曲线

    Figure  13.  Test curve of insertion loss

    图  14  注入测试系统

    Figure  14.  Injection test system

    图  15  北斗/GPS高功率微波防护天线

    Figure  15.  BD/GPS antenna against HPM

    表  1  窄带高功率微波注入试验数据

    Table  1.   HPM-NS injection test data

    injection power/kW leakage power/W leakage voltage/V
    1 0.23 3.4
    2 0.40 4.5
    下载: 导出CSV

    表  2  超宽谱高功率微波注入试验数据

    Table  2.   HPM-UWS injection test data

    injection peak voltage/V leakage peak voltage/V
    947 8.9
    1 411 11.5
    下载: 导出CSV
  • [1] 李巍, 李明典, 刘斌, 等. 高功率微波对引信射频前端的干扰与防护研究[J]. 航空兵器, 2022, 29(5):100-106 doi: 10.12132/ISSN.1673-5048.2022.0062

    Li Wei, Li Mingdian, Liu Bin, et al. Research on the interference and protection of high power microwave to RF front-end of fuze[J]. Aero Weaponry, 2022, 29(5): 100-106 doi: 10.12132/ISSN.1673-5048.2022.0062
    [2] 范宇清, 程二威, 魏明, 等. 北斗接收机强电磁脉冲前门耦合仿真研究[J]. 重庆邮电大学学报(自然科学版), 2020, 32(3):426-433

    Fan Yuqing, Cheng Erwei, Wei Ming, et al. Simulation research on front door coupling of strong electromagnetic pulse for Beidou receiver[J]. Journal of Chongqing University of Posts and Telecommunications (Natural Science Edition), 2020, 32(3): 426-433
    [3] 王建争, 彭少磊. 高功率微波对北斗系统接收机影响分析[J]. 舰船电子工程, 2019, 39(10):27-29 doi: 10.3969/j.issn.1672-9730.2019.10.006

    Wang Jianzheng, Peng Shaolei. Effect of high power microwave on Beidou system receiver[J]. Ship Electronic Engineering, 2019, 39(10): 27-29 doi: 10.3969/j.issn.1672-9730.2019.10.006
    [4] 胡源, 江峰, 沈楠. 高功率微波武器对抗GPS研究[J]. 全球定位系统, 2008, 33(3):55-59 doi: 10.3969/j.issn.1008-9268.2008.03.014

    Hu Yuan, Jiang Feng, Shen Nan. Study on countermining GPS with high power microwave weapon[J]. GNSS World of China, 2008, 33(3): 55-59 doi: 10.3969/j.issn.1008-9268.2008.03.014
    [5] 许志永, 张厚, 吴瑞, 等. 高功率微波对弹载GPS天线的耦合特性分析[J]. 战术导弹技术, 2014(5):34-38

    Xu Zhiyong, Zhang Hou, Wu Rui, et al. Analysis of the coupling characteristics of high power microwave and missile-borne GPS antenna[J]. Tactical Missile Technology, 2014(5): 34-38
    [6] 胡锐. 卫星导航接收机强电磁脉冲耦合机理研究[D]. 北京: 北京交通大学, 2018

    Hu Rui. Research on the coupling mechanism of strong electromagnetic pulse for satellite navigation receiver[D]. Beijing: Beijing Jiaotong University, 2018
    [7] 胡明, 陈圣贤, 李永龙, 等. 重频超宽带电磁脉冲对GPS导航接收机的效应研究[J]. 强激光与粒子束, 2024, 36:033011 doi: 10.11884/HPLPB202436.230324

    Hu Ming, Chen Shengxian, Li Yonglong, et al. Influence of repeated frequency UWB electromagnetic pulse on GPS navigation receiver[J]. High Power Laser and Particle Beams, 2024, 36: 033011 doi: 10.11884/HPLPB202436.230324
    [8] 易波, 李丽英, 陈紫琪. 加载能量选择表面的导航天线强电磁辐照响应研究[J]. 舰船电子对抗, 2022, 45(6):95-99

    Yi Bo, Li Liying, Chen Ziqi. Research into strong electromagnetic radiation response of navigation antenna with loaded energy selective surface[J]. Shipboard Electronic Countermeasure, 2022, 45(6): 95-99
    [9] Yang Guohui, Yang Xin, Zhang Kuang, et al. An L-band narrowband energy selective surface design[C]//Proceedings of 2019 Cross Strait Quad-Regional Radio Science and Wireless Technology Conference. 2019: 1-3.
    [10] 王子亮. 北斗导航接收机抗强电磁场损毁限幅电路研究[D]. 北京: 北京交通大学, 2018

    Wang Ziliang. Study on the limiter of Beidou navigation receiver under strong electromagnetic field[D]. Beijing: Beijing Jiaotong University, 2018
    [11] 苏保文. 导航接收机强电磁场耦合特性及抗损毁的技术研究[D]. 北京: 北京交通大学, 2020

    Su Baowen. Study on coupling characteristics and anti-damage technology of navigation receiver in strong electromagnetic field[D]. Beijing: Beijing Jiaotong University, 2020
    [12] 陈自东, 秦风, 赵景涛, 等. 高功率微波作用下限幅器尖峰泄漏特性[J]. 强激光与粒子束, 2020, 32:103014 doi: 10.11884/HPLPB202032.200097

    Chen Zidong, Qin Feng, Zhao Jingtao, et al. Spike leakage characteristic of limiter irradiated by high power microwave[J]. High Power Laser and Particle Beams, 2020, 32: 103014 doi: 10.11884/HPLPB202032.200097
    [13] Ratna P, Jain S, Chattopadhyay J. Mitigation technique for high altitude electro magnetic pulse (HEMP) for GPS receiver[C]//Proceedings of 2014 Asia-Pacific Microwave Conference. 2014: 1175-1177.
    [14] Shukal M, Koledintseva M Y, Geiler M, et al. Adaptive interference mitigation using frequency-selective limiters over GPS band for automotive applications[C]//Proceedings of 2020 IEEE International Symposium on Electromagnetic Compatibility & Signal/Power Integrity. 2020: 614-618.
    [15] Lin H, Shi Xiaoling, Dubs C, et al. Compact and passive thin-film frequency-selective limiters[J]. IEEE Microwave and Wireless Technology Letters, 2023, 33(8): 1155-1158. doi: 10.1109/LMWT.2023.3268501
    [16] 易波, 陆奇敏, 杨莉. 一种强电磁防护型导航天线研究与设计[J]. 指挥控制与仿真, 2022, 44(6):115-118 doi: 10.3969/j.issn.1673-3819.2022.06.019

    Yi Bo, Lu Qimin, Yang Li. Research and design of antenna with ability of strong electromagnetic protection[J]. Command Control & Simulation, 2022, 44(6): 115-118 doi: 10.3969/j.issn.1673-3819.2022.06.019
    [17] 张江南. 宽带高功率电磁脉冲对典型无人机毁伤评估研究[D]. 南京: 南京理工大学, 2019

    Zhang Jiangnan. Damage assessment research of UAV against mesoband high-power electromagnetic pulse[D]. Nanjing: Nanjing University of Science & Technology, 2019
