第1.5代“三高一优”YDF特种激光光纤

俞娟 倪力 彭昆 向恒 冷晓晓 林傲祥

俞娟, 倪力, 彭昆, 等. 第1.5代“三高一优”YDF特种激光光纤[J]. 强激光与粒子束, 2024, 36: 101001. doi: 10.11884/HPLPB202436.240268
引用本文: 俞娟, 倪力, 彭昆, 等. 第1.5代“三高一优”YDF特种激光光纤[J]. 强激光与粒子束, 2024, 36: 101001. doi: 10.11884/HPLPB202436.240268
Yu Juan, Ni Li, Peng Kun, et al. The 1.5th-generation “three-high/one-excellent” YDF specialty laser fiber[J]. High Power Laser and Particle Beams, 2024, 36: 101001. doi: 10.11884/HPLPB202436.240268
Citation: Yu Juan, Ni Li, Peng Kun, et al. The 1.5th-generation “three-high/one-excellent” YDF specialty laser fiber[J]. High Power Laser and Particle Beams, 2024, 36: 101001. doi: 10.11884/HPLPB202436.240268

第1.5代“三高一优”YDF特种激光光纤

doi: 10.11884/HPLPB202436.240268
基金项目: 高功率光纤激光技术所级重大专项;高功率光纤激光技术所地联合创新中心项目
详细信息
    作者简介:

    俞 娟,54795150@qq.com

    通讯作者:

    林傲祥,10778713@qq.com

  • 中图分类号: TN244

The 1.5th-generation “three-high/one-excellent” YDF specialty laser fiber

  • 摘要:

    面向高端特种光纤激光器研制需求,突破限制光纤激光器系统功率输出和性能提升的技术瓶颈,中国工程物理研究院化工材料研究所高功率光纤激光技术所地联合创新中心团队采用模式裁剪制备工艺技术,率先推出了国内首创、特别适合976 nm-LD端面泵浦方式(976技术路线)的第1.5代YDF特种激光光纤,有效提升了光纤激光系统的模式不稳定阈值(TMI),显著优化了激光输出的光束质量。相对于目前普遍使用的第1.0代铝磷硅三元体系光纤(Yb-APS),第1.5代YDF特种激光光纤的激光功率提升约20%,光束质量M2优化约20%,集中展现了高功率、高效率、高TMI阈值、M2优化的“三高一优”的技术特点,可供工业市场高端客户选择和强激光技术领域应用。

  • 图  1  第1.5代LMA-14/250-YDF特种激光光纤包层吸收谱及折射率分布图

    Figure  1.  Clad absorption spectrum and refractive-index profile of 1.5G LMA-14/250-YDF specialty laser fiber

    图  2  第1.5代LMA-14/250-YDF特种激光光纤2 kW功率输出时的M2光束质量

    Figure  2.  Beam quality M2 of 1.5G LMA-14/250-YDF at 2 kW output power

    图  3  14/360-RCF环芯传能纤横截面图

    Figure  3.  Cross-section photograph of 14/360-RCF fiber

    表  1  第1.5代YDF特种激光光纤参数

    Table  1.   1.5G-YDF specialty laser fiber parameters

    1.5G-YDF laser fiber laser power/kW beam quality M2
    LMA-14/250-YDF 2~3 ~1.05
    LMA-20/400-YDF 3~4 ~1.10
    LMA-25/400-YDF 4~6 ~1.20
    PLMA-20/400-YDF 2~3 ~1.20
    PLMA-25/400-YDF 3~5 ~1.30
    下载: 导出CSV

    表  2  第1.5代LMA-14/250-YDF特种激光光纤参数

    Table  2.   1.5G LMA-14/250-YDF specialty laser fiber parameters

    parameter unit specification
    peak cladding absorption @915 nm dB/m 0.50±0.15
    peak cladding absorption @976 nm dB/m 1.50±0.25
    cladding attenuation@1 095 nm dB/km ≤10
    core attenuation@1 200 nm dB/km ≤10
    core attenuation@1 300 nm dB/km ≤15
    core NA 0.070±0.005
    cladding NA(5%) ≥0.46
    core/clad offset μm ≤1.0
    core diameter μm 14.3±0.5
    clad diameter (flat-to-flat) μm 250±5.0
    max. output power kW ≥2.0
    slope efficiency@976 nm % ≥78
    beam quality M2 ~1.05
    下载: 导出CSV
  • [1] Eidam T, Wirth C, Jauregui C, et al. Experimental observations of the threshold-like onset of mode instabilities in high power fiber amplifiers[J]. Optics Express, 2011, 19(14): 13218-13224. doi: 10.1364/OE.19.013218
    [2] Otto H J, Stutzki F, Jansen F, et al. Temporal dynamics of mode instabilities in high-power fiber lasers and amplifiers[J]. Optics Express, 2012, 20(14): 15710-15722. doi: 10.1364/OE.20.015710
    [3] Stutzki F, Otto H J, Jansen F, et al. High-speed modal decomposition of mode instabilities in high-power fiber lasers[J]. Optics Letters, 2011, 36(23): 4572-4574. doi: 10.1364/OL.36.004572
    [4] Tao Rumao, Ma Pengfei, Wang Xiaolin, et al. Study of mode instabilities in high power fiber amplifiers by detecting scattering light[C]//Proceedings of Fiber-Based Technologies and Applications. 2014: FTh2F. 2.
    [5] 陶汝茂, 周朴, 肖虎, 等. 高功率光纤激光中模式不稳定性现象研究进展[J]. 激光与光电子学进展, 2014, 51:020001

    Tao Rumao, Zhou Pu, Xiao Hu, et al. Progress of study on mode instability in high power fiber amplifiers[J]. Laser & Optoelectronics Progress, 2014, 51: 020001
    [6] 史尘, 陶汝茂, 王小林, 等. 光纤激光模式不稳定的新现象与新进展[J]. 中国激光, 2017, 44:0201004 doi: 10.3788/CJL201744.0201004

    Shi Chen, Tao Rumao, Wang Xiaolin, et al. New progress and phenomena of modal instability in fiber lasers[J]. Chinese Journal of Lasers, 2017, 44: 0201004 doi: 10.3788/CJL201744.0201004
    [7] Brar K, Savage-Leuchs M, Henrie J, et al. Threshold power and fiber degradation induced modal instabilities in high-power fiber amplifiers based on large mode area fibers[C]//Proceedings of SPIE 8961, Fiber Lasers XI: Technology, Systems, and Applications. 2014: 89611R.
    [8] Otto H J, Modsching N, Jauregui C, et al. Wavelength dependence of maximal diffraction-limited output power of fiber lasers[C]//Proceedings of Advanced Solid State Lasers 2014. 2014: AM5A. 44.
    [9] Hejaz K, Norouzey A, Poozesh R, et al. Controlling mode instability in a 500 W ytterbium-doped fiber laser[J]. Laser Physics, 2014, 24: 025102. doi: 10.1088/1054-660X/24/2/025102
    [10] 曾令筏, 文榆钧, 王小林, 等. 高功率光纤激光器反常模式不稳定效应实验研究[J]. 中国激光, 2024, 51:0601001 doi: 10.3788/CJL230782

    Zeng Lingfa, Wen Yujun, Wang Xiaolin, et al. Experimental research on abnormal transverse mode instability in high-power fiber lasers[J]. Chinese Journal of Lasers, 2024, 51: 0601001 doi: 10.3788/CJL230782
    [11] 陈益沙, 廖雷, 李进延. 光纤激光器模式不稳定机理及抑制方法研究进展[J]. 激光与光电子学进展, 2017, 54:080001

    Chen Yisha, Liao Lei, Li Jinyan. Research progress on mode instability mechanism and suppression methods for fiber lasers[J]. Laser & Optoelectronics Progress, 2017, 54: 080001
    [12] 林傲祥, 彭昆, 俞娟, 等. 高功率连续光纤激光系统热效应及其抑制措施[J]. 强激光与粒子束, 2022, 34:011005 doi: 10.11884/HPLPB202234.210336

    Lin Aoxiang, Peng Kun, Yu Juan, et al. Thermal effect and its suppression in high-power continuous-wave fiber laser system[J]. High Power Laser and Particle Beams, 2022, 34: 011005 doi: 10.11884/HPLPB202234.210336
    [13] 林傲祥, 肖起榕, 倪力, 等. 国产YDF有源光纤实现单纤20 kW激光输出[J]. 中国激光, 2021, 48:0916003

    Lin Aoxiang, Xiao Qirong, Ni Li, et al. Domestic YDF active fiber realizes single fiber 20 kW laser output[J]. Chinese Journal of Lasers, 2021, 48: 0916003
    [14] 林傲祥, 倪力, 彭昆, 等. 国产千瓦级LMA-14/250-YDF有源激光光纤[J]. 中国激光, 2020, 47:1216003 doi: 10.3788/CJL202047.1216003

    Lin Aoxiang, Ni Li, Peng Kun, et al. Domestic kilowatt level LMA-14/250-YDF active laser fiber[J]. Chinese Journal of Lasers, 2020, 47: 1216003 doi: 10.3788/CJL202047.1216003
    [15] 林傲祥, 倪力, 彭昆, 等. 国产20/400 μm规格有源光纤实现3 kW激光输出[J]. 中国激光, 2017, 44:0115001 doi: 10.3788/CJL201744.0115001

    Lin Aoxiang, Ni Li, Peng Kun, et al. Domestic 20/400 μm specification active fiber achieves 3 kW laser output[J]. Chinese Journal of Lasers, 2017, 44: 0115001 doi: 10.3788/CJL201744.0115001
