磁控管双能固态调制器研制

杜辉 周英怀 唐维斌 邓长春 李刚

杜辉, 周英怀, 唐维斌, 等. 磁控管双能固态调制器研制[J]. 强激光与粒子束, 2025, 37: 025003. doi: 10.11884/HPLPB202537.240282
引用本文: 杜辉, 周英怀, 唐维斌, 等. 磁控管双能固态调制器研制[J]. 强激光与粒子束, 2025, 37: 025003. doi: 10.11884/HPLPB202537.240282
Du Hui, Zhou Yinghuai, Tang Weibin, et al. Development of the magnetron double energy solid-state modulator[J]. High Power Laser and Particle Beams, 2025, 37: 025003. doi: 10.11884/HPLPB202537.240282
Citation: Du Hui, Zhou Yinghuai, Tang Weibin, et al. Development of the magnetron double energy solid-state modulator[J]. High Power Laser and Particle Beams, 2025, 37: 025003. doi: 10.11884/HPLPB202537.240282

磁控管双能固态调制器研制

doi: 10.11884/HPLPB202537.240282
详细信息
    作者简介:

    杜 辉,304262192@qq.com

    通讯作者:

    周英怀,zyh@injet.cn

  • 中图分类号: TN787

Development of the magnetron double energy solid-state modulator

  • 摘要: 海关安检双能加速器是由磁控管驱动的,在双能运行时,由于磁控管的静态工作阻抗及脉冲电流波形幅值一般相差比较大,造成脉冲电流顶部波形畸变,不能满足海关安检需要。为此采用“双回路并联电路拓扑+并联IGBT固态开关技术+高变比脉冲变压器技术+波形校正技术”研制了用于双能加速器的固态调制器,实现高低能交替输出脉冲。结果显示,在工作电流在70~120 A范围内时,高低能交替工作的磁控管脉冲电流波形都为比较理想的梯形波,其电流波形的平顶相对变化小于5%。
  • 图  1  双能加速器磁控管的工作状态图

    Figure  1.  Timing sequence of dual-energy accelerator of the magnetron

    图  2  双能固态调制器电路原理图

    Figure  2.  Schematic of dual-energy solid-state modulator circuit

    图  3  控制信号和输出电压时序图

    Figure  3.  Timing sequence of signals and output voltage

    图  4  磁控管双能脉冲电压及电流波形

    Figure  4.  Dual-energy pulse voltage and current waveforms of the magnetron

    图  5  磁控管单能脉冲电压电流波形

    Figure  5.  Single-energy pulse voltage and current waveforms of the magnetron

    图  6  固态调制器仿真原理图

    Figure  6.  Circuit simulation model of the solid-state modulator

    图  7  双能工作情况下的磁控管两端电压和电流仿真波形

    Figure  7.  Simulated dual-energy output pulse voltage and current waveforms of the magnetron

    图  8  栅极电压信号与磁控管脉冲电流仿真

    Figure  8.  Simulated of gate voltage signal and magnetron pulse current

    图  9  栅极电压信号与脉冲电流

    Figure  9.  Gate voltage and pulse current waveforms

    图  10  采用波形校正后的双能脉冲电压电流波形

    Figure  10.  Dual-energy pulse output voltage and current waveforms of waveform correction

  • [1] 陈志强, 赵眺, 李亮. 高能双能X射线DR成像及物质识别技术综述[J]. CT理论与应用研究, 2014, 23(5):731-742

    Chen Zhiqiang, Zhao Tiao, Li Liang. The review of high energy dual-energy X-ray DR imaging and material recognition technology[J]. CT Theory and Applications, 2014, 23(5): 731-742
    [2] 赵眺. 双能X射线集装箱CT重建及材料分解技术研究[D]. 北京: 清华大学, 2018: 2-8

    Zhao Tiao. Research on reconstruction and material decomposition techniques for dual energy X-ray container CT[D]. Beijing: Tsinghua University, 2018: 2-8
    [3] 邬小平, 陈志强, 王学武. 双能X射线材料识别技术在大型集装箱检测系统中的应用[J]. 核电子学与探测技术, 2005, 25(6):782-784 doi: 10.3969/j.issn.0258-0934.2005.06.055

    Wu Xiaoping, Chen Zhiqiang, Wang Xuewu. Application of LCIS for material discrimination with dual energy method[J]. Nuclear Electronics & Detection Technology, 2005, 25(6): 782-784 doi: 10.3969/j.issn.0258-0934.2005.06.055
    [4] 吴志芳, 董涛. 大型客体辐射成像检测技术的发展与趋势[J]. 原子能科学技术, 2019, 53(10):2062-2071 doi: 10.7538/yzk.2019.53.10.2062

    Wu Zhifang, Dong Tao. Development and trend of radiation imaging technology for large object[J]. Atomic Energy Science and Technology, 2019, 53(10): 2062-2071 doi: 10.7538/yzk.2019.53.10.2062
    [5] 魏智. 发射机高压脉冲调制器的设计与实践[M]. 北京: 电子工业出版社, 2009

    Wei Zhi. Design and practice of transmitter high voltage pulse modulator[M]. Beijing: Publishing House of Electronics Industry, 2009
    [6] 蔡政平, 曹湘军, 王勇. 大功率固态调制器的仿真研究[J]. 强激光与粒子束, 2007, 19(2):330-334

    Cai Zhengping, Cao Xiangjun, Wang Yong. Simulation study on high power solid-state modulator[J]. High Power Laser and Particle Beams, 2007, 19(2): 330-334
    [7] 尚雷, 李为民, 丛晓艳, 等. 大功率固态脉冲调制器技术分析[J]. 高电压技术, 2005, 31(11):28-30 doi: 10.3969/j.issn.1003-6520.2005.11.011

    Shang Lei, Li Weimin, Cong Xiaoyan, et al. Study on the technology of high power, solid-state modulators[J]. High Voltage Engineering, 2005, 31(11): 28-30 doi: 10.3969/j.issn.1003-6520.2005.11.011
    [8] Gaudreau M P J, Casey J, Mulvaney J M, et al. Solid state modulator for klystron/gyrotron conditioning, testing, and operation[C]//Conference Record of 2000 Twenty-Fourth International Power Modulator Symposium. 2000: 125-128.
    [9] 刘克富. 固态Marx发生器研究进展[J]. 高电压技术, 2015, 41(6):1781-1787

    Liu Kefu. Research progress in solid-state Marx generators[J]. High Voltage Engineering, 2015, 41(6): 1781-1787
    [10] 饶俊峰. 基于固态开关的重复频率脉冲功率源的脉冲调制技术及其应用[D]. 上海: 复旦大学, 2013

    Rao Junfeng. Pulse modulation technology of repetitive frequency pulse power source based on solid state switch and its application[D]. Shanghai: Fudan University, 2013
    [11] 黄军, 戴广明, 田为. 几种全固态刚管调制器的对比[J]. 现代雷达, 2010, 32(3):80-83 doi: 10.3969/j.issn.1004-7859.2010.03.020

    Huang Jun, Dai Guangming, Tian Wei. Comparision of several all-solid-state hard tube modulators[J]. Modern Radar, 2010, 32(3): 80-83 doi: 10.3969/j.issn.1004-7859.2010.03.020
    [12] 饶俊峰, 李成建, 李孜, 等. 全固态高重频高压脉冲电源[J]. 强激光与粒子束, 2019, 31:035001 doi: 10.11884/HPLPB201931.190005

    Rao Junfeng, Li Chengjian, Li Zi, et al. All solid state high-frequency and high voltage pulsed power supply[J]. High Power Laser and Particle Beams, 2019, 31: 035001 doi: 10.11884/HPLPB201931.190005
    [13] Zarghani M, Mohsenzade S, Kaboli S. A high-voltage pulsed power supply with online rise time adjusting capability for vacuum tubes[J]. IEEE Journal of Emerging and Selected Topics in Power Electronics, 2021, 9(3): 3019-3029. doi: 10.1109/JESTPE.2020.3006013
    [14] 姜松, 邱力文, 饶俊峰, 等. 新型全固态高压多电平波形发生器的研制[J]. 强激光与粒子束, 2019, 31:115003 doi: 10.11884/HPLPB201931.190124

    Jiang Song, Qiu Liwen, Rao Junfeng, et al. Development of a new all-solid-state high voltage multilevel waveform generator[J]. High Power Laser and Particle Beams, 2019, 31: 115003 doi: 10.11884/HPLPB201931.190124
    [15] 冯文荃. 磁控管V-I特性的近似分析及其应用[J]. 南京大学学报, 1990, 26(4):596-602

    Feng Wenquan. The approximate analysis of magnetron V-I characteristics and its applications[J]. Journal of Nanjing University Natural Science, 1990, 26(4): 596-602
