K波段高功率微波变极化可变倾角连续横向枝节天线

孙云飞 马照坤 贺军涛 曹甄强 张强

孙云飞, 马照坤, 贺军涛, 等. K波段高功率微波变极化可变倾角连续横向枝节天线[J]. 强激光与粒子束, 2025, 37: 043003. doi: 10.11884/HPLPB202537.240295
引用本文: 孙云飞, 马照坤, 贺军涛, 等. K波段高功率微波变极化可变倾角连续横向枝节天线[J]. 强激光与粒子束, 2025, 37: 043003. doi: 10.11884/HPLPB202537.240295
Sun Yunfei, Ma Zhaokun, He Juntao, et al. K-band high-power microwave variable-polarization antenna with variable inclination continuous transverse stub antenna[J]. High Power Laser and Particle Beams, 2025, 37: 043003. doi: 10.11884/HPLPB202537.240295
Citation: Sun Yunfei, Ma Zhaokun, He Juntao, et al. K-band high-power microwave variable-polarization antenna with variable inclination continuous transverse stub antenna[J]. High Power Laser and Particle Beams, 2025, 37: 043003. doi: 10.11884/HPLPB202537.240295

K波段高功率微波变极化可变倾角连续横向枝节天线

doi: 10.11884/HPLPB202537.240295
详细信息
    作者简介:

    孙云飞,sunyunfei_gfkd@163.com

    通讯作者:

    曹甄强,zqcao666@163.com

    张 强,zqiang1984@163.com

  • 中图分类号: TN82

K-band high-power microwave variable-polarization antenna with variable inclination continuous transverse stub antenna

  • 摘要: 提出了一种基于可变倾角连续横向枝节(VICTS)天线和多层全金属十字开孔透镜的变极化波束扫描方案,通过调整极化层、辐射层以及天线整体的旋转角度,即可实现线极化和左(右)旋圆极化的自由切换,并可实现不同极化输出下的二维波束扫描。设计了一个K波段口径150 mm的天线模型,仿真得到天线圆极化辐射时的最大增益为27.61 dB,轴比为1.05 dB,口径效率为58.7%;波束扫描至26°时,增益为25.72 dB,轴比为2.58 dB。线极化辐射时的最大增益为27.63 dB,口径效率为58.7%;波束扫描至26°时,增益为25.82 dB。按真空中金属击穿阈值50 MV/m进行计算,VICTS天线的功率容量为9.6 GW/m2,极化层的功率容量超过10 GW/m2,该变极化波束扫描天线方案有应用于高功率微波领域的潜力。
  • 图  1  天线整体示意图

    Figure  1.  Overall schematic diagram of the antenna

    图  2  VICTS天线波束扫描原理图

    Figure  2.  Schematic of VICTS antenna beam scanning

    图  3  CTS天线基本单元示意图

    Figure  3.  Schematic diagram of basic units of CTS antenna

    图  4  CTS天线单元示意图

    Figure  4.  Schematic diagram of units of CTS antenna

    图  5  CTS天线单元组阵仿真

    Figure  5.  Simulation of CTS antenna unit array

    图  6  VICTS天线示意图

    Figure  6.  Schematic of VICTS antenna

    图  7  天线在不同γ下的3D方向图

    Figure  7.  Antenna 3-D pattern at different γ

    图  8  天线方向图随γ的变化

    Figure  8.  Variation of antenna pattern with γ

    图  9  天线在不同γ角度下主极化和交叉极化的2D方向图

    Figure  9.  Antenna 2-D pattern at different γ for co-polarization and cross-polarization

    图  10  天线回波损耗随γ的变化

    Figure  10.  Variation of antenna return loss with γ

    图  11  极化层整体示意图

    Figure  11.  Overall schematic diagram of polarization layer

    图  12  极化单元随入射角变化的仿真结果

    Figure  12.  Simulation results of polarization unit with different incident angles

    图  13  VICTS天线工作在不同极化模式的示意图

    Figure  13.  VICTS antenna working in different polarization modes

    图  14  VICTS天线在不同γ情况下的增益情况

    Figure  14.  VICTS antenna gain with different γ

    表  1  VICTS天线在不同γ情况下的波束指向和增益情况

    Table  1.   VICTS antenna gain and AR with different γ

    γ/(°) θ/(°) φ/(°) initial gain/dB LP gain/dB CP gain/dB AR/dB
    0 0 0 27.83 27.63 27.61 1.05
    5 5 2.5 27.74 27.60 27.56 1.28
    10 9 5.0 27.60 27.46 27.43 1.68
    15 15 5.0 26.71 26.27 26.23 1.81
    20 21 7.5 26.58 26.07 25.98 2.54
    25 26 9.0 26.64 25.82 25.72 2.58
    下载: 导出CSV
