一种测量纳秒级高电压脉冲的D-dot探测器

潘子龙 程新兵 陈绒 陈侠 张瀚文 张仁杰 钱宝良

潘子龙, 程新兵, 陈绒, 等. 一种测量纳秒级高电压脉冲的D-dot探测器[J]. 强激光与粒子束. doi: 10.11884/HPLPB202537.240319
引用本文: 潘子龙, 程新兵, 陈绒, 等. 一种测量纳秒级高电压脉冲的D-dot探测器[J]. 强激光与粒子束. doi: 10.11884/HPLPB202537.240319
Pan Zilong, Cheng Xinbing, Chen Rong, et al. A D-dot monitor for measuring nanosecond high voltage pulses[J]. High Power Laser and Particle Beams. doi: 10.11884/HPLPB202537.240319
Citation: Pan Zilong, Cheng Xinbing, Chen Rong, et al. A D-dot monitor for measuring nanosecond high voltage pulses[J]. High Power Laser and Particle Beams. doi: 10.11884/HPLPB202537.240319

一种测量纳秒级高电压脉冲的D-dot探测器

doi: 10.11884/HPLPB202537.240319
基金项目: 湖南省研究生科研创新项目(CX20220064)
详细信息
    作者简介:

    潘子龙,sxbjtb@126.com

    通讯作者:

    程新兵,120chch@163.com

    陈 绒,chenrong0101@163.com

  • 中图分类号: TM835

A D-dot monitor for measuring nanosecond high voltage pulses

  • 摘要: 设计了一种测量纳秒级高电压脉冲的D-dot探测器,包括微分探头和无源积分器的设计、仿真和实验。该探测器的探头电极可以根据不同的测量器件进行更换,探头电极的轴向长度也可以根据测量需求进行调节。采用CST软件对该探头的电场分布开展了静电场模拟分析,并进行了结构优化,同时利用OrCAD/Pspice软件对D-dot探头、积分器和探测器的幅频响应特性进行了分析,确保探测器的工作频率满足设计要求。利用设计的D-dot探测器开展了纳秒级高电压脉冲测量实验,实验结果表明,设计的D-dot探测器满足前沿时间约37 ns、电压幅值约597 kV的高电压脉冲测量需求。
  • 图  1  电容分压器测量原理图

    Figure  1.  Schematic diagram of capacitive voltage divider measurement

    图  2  可调节式的D-dot探头结构示意图

    Figure  2.  Structure diagram of adjustable D-dot probe

    图  3  D-dot探头的电场分布图

    Figure  3.  Electric field distribution diagram of the D-dot probe

    图  4  D-dot探头的幅频特性曲线

    Figure  4.  Amplitude-frequency response of the D-dot probe

    图  5  积分器原理图

    Figure  5.  Schematic diagram of the integrator

    图  6  积分器等效电路图

    Figure  6.  Equivalent circuit diagram of the integrator

    图  7  分布参数对积分器输出波形的影响

    Figure  7.  Influence of distributed parameters on the output waveform of the integrator

    图  8  积分器的方波响应实验和模拟结果

    Figure  8.  Experimental and simulation results of square wave response

    图  9  积分器的幅频特性曲线

    Figure  9.  Amplitude-frequency response of the integrator

    图  10  D-dot探测器的幅频特性曲线

    Figure  10.  Amplitude-frequency response of the D-dot monitor

    图  11  D-dot探测器标定典型实验结果

    Figure  11.  Typical calibration experimental results of the D-dot monitor

    图  12  D-dot探头缩进接地外壳不同距离的归一化输出波形图

    Figure  12.  Normalized output waveforms of the D-dot monitor with different distance between the probe and the ground plate

    图  13  D-dot探测器高电压实验结果

    Figure  13.  High voltage experimental result of the D-dot monitor

    表  1  积分器等效电路参数表

    Table  1.   Parameters of the integrator equivalent circuit

    R/kΩ C1/pF L1/nH C/nF R2 L2/nH Rm Cm/pF Lm/nH
    3.0 0.1 20 0.75 0.05 1 50 2 20
    下载: 导出CSV

    表  2  不同探头电极位置的D-dot探测器灵敏度

    Table  2.   Sensitivities of the D-dot monitor with different location of the electrode

    distance between the electrode and the ground plate/mm sensitivity/(kV·V−1)
    0 55.15
    1.5 60.67
    3.0 69.00
    4.5 76.63
    下载: 导出CSV
  • [1] Edson W A, Oetzel G N. Capacitance voltage divider for high-voltage pulse measurement[J]. Review of Scientific Instruments, 1981, 52(4): 604-606. doi: 10.1063/1.1136644
    [2] 呼义翔, 郭宁, 韩娟娟. 磁绝缘传输线电压测量用自积分式电容分压器研制[J]. 强激光与粒子束, 2013, 25(7):1839-1844 doi: 10.3788/HPLPB20132507.1839

    Hu Yixiang, Guo Ning, Han Juanjuan. Self-integral capacitance divider used for voltage measurement along magnetically insulated transmission lines[J]. High Power Laser and Particle Beams, 2013, 25(7): 1839-1844 doi: 10.3788/HPLPB20132507.1839
    [3] 高景明, 刘永贵, 杨建华. 一种电容补偿型高压电容分压器的设计[J]. 高电压技术, 2007, 33(6):76-79

    Gao Jingming, Liu Yonggui, Yang Jianhua. Design of capacitance-compensated capacitive divider for high-voltage pulse measurement[J]. High Voltage Engineering, 2007, 33(6): 76-79
    [4] 卫兵, 龚伯仪, 王治, 等. 自积分式电容分压器的频率响应特性[J]. 强激光与粒子束, 2018, 30:045006 doi: 10.11884/HPLPB201830.170369

    Wei Bing, Gong Boyi, Wang Zhi, et al. Frequency response characteristics of self-integralting capacitive divider[J]. High Power Laser and Particle Beams, 2018, 30: 045006 doi: 10.11884/HPLPB201830.170369
    [5] 丁卫东, 李峰, 张乔根, 等. 特高压气体绝缘开关设备中特快速瞬态过电压测量用电容传感器的标定[J]. 中国电机工程学报, 2011, 31(31):56-65

    Ding Weidong, Li Feng, Zhang Qiaogen, et al. Calibration of the capacitive sensor used in the very fast transient overvoltage measurement of ultra high voltage gas insulated switchgear[J]. Proceedings of the CSEE, 2011, 31(31): 56-65
    [6] 欧阳佳, 刘金亮, 田亮, 等. 纳秒级不同脉宽的信号对电容分压器的影响[J]. 高电压技术, 2004, 30(12):42-44

    Ouyang Jia, Liu Jinliang, Tian Liang, et al. Influence of different input signals with nanosecond pulsewidth on capacitive voltage divider[J]. High Voltage Engineering, 2004, 30(12): 42-44
    [7] 王亮平, 郭宁, 李岩, 等. 测量强光一号负载电压的电容分压器[J]. 强激光与粒子束, 2010, 22(3):696-700 doi: 10.3788/HPLPB20102203.0696

    Wang Liangping, Guo Ning, Li Yan, et al. Capacitive divider for voltage measurement of diode load on Qiangguang - I accelerator[J]. High Power Laser and Particle Beams, 2010, 22(3): 696-700 doi: 10.3788/HPLPB20102203.0696
    [8] 卫兵, 方东凡, 卿燕玲, 等. 亚纳秒脉冲高电压测量探头[J]. 强激光与粒子束, 2012, 24(6):1497-1501 doi: 10.3788/HPLPB20122406.1497

    Wei Bing, Fang Dongfan, Qing Yanling, et al. D-dot monitor for sub-nanosecond high voltage pulse measurement[J]. High Power Laser and Particle Beams, 2012, 24(6): 1497-1501 doi: 10.3788/HPLPB20122406.1497
    [9] 卫兵, 顾元朝, 周荣国, 等. 阳加速器水传输线D-dot的设计、标定和实验[J]. 强激光与粒子束, 2007, 19(5):830-834

    Wei Bing, Gu Yuanchao, Zhou Rongguo, et al. Design, calibration and measurement of D-dot monitor for Yang accelerator water transmission line[J]. High Power Laser and Particle Beams, 2007, 19(5): 830-834
    [10] McKnight R H. Measuring fast-rise impulse by use of E - dot sensors[C]//Proceedings of the 5th International Symposium on High Voltage Engineering. 1987: 32-38.
    [11] Struve K W, Horry M L, Spielman R B. Design, calibration, and performance of water diagnostics on the PBFA Z[C]//Proceedings of the 11th IEEE International Pulsed Power Conference. 1997: 1303-1308.
    [12] 胡翔骏. 电路分析[M]. 2版. 北京: 高等教育出版社, 2007

    Hu Xiangjun. Electrical circuit analysis[M]. 2nd ed. Beijing: Higher Education Press, 2007
    [13] Stygar W A, Spielman R B, Ives H C, et al. D-DOT and B-DOT monitors for Z-vacuum section power-flow measurements[C]//Proceedings of the 11th IEEE International Pulsed Power Conference. 1997: 1258-1263.
    [14] Metwally I A. D-dot probe for fast-front high-voltage measurement[J]. IEEE Transactions on Instrumentation and Measurement, 2010, 59(8): 2211-2219. doi: 10.1109/TIM.2009.2030928
    [15] 卫兵, 傅贞, 王玉娟, 等. 无源RC积分器频率响应特性分析[J]. 高电压技术, 2008, 34(1):53-56,77

    Wei Bing, Fu Zhen, Wang Yujuan, et al. Frequency response analysis of passive RC integrator[J]. High Voltage Engineering, 2008, 34(1): 53-56,77
