速调管放大器输出腔的匹配理论

何琥 雷禄容 李士锋

何琥, 雷禄容, 李士锋. 速调管放大器输出腔的匹配理论[J]. 强激光与粒子束, 2025, 37: 023005. doi: 10.11884/HPLPB202537.240338
引用本文: 何琥, 雷禄容, 李士锋. 速调管放大器输出腔的匹配理论[J]. 强激光与粒子束, 2025, 37: 023005. doi: 10.11884/HPLPB202537.240338
He Hu, Lei Lurong, Li Shifeng. Matching theory and PIC simulation for klystron output cavity with beam[J]. High Power Laser and Particle Beams, 2025, 37: 023005. doi: 10.11884/HPLPB202537.240338
Citation: He Hu, Lei Lurong, Li Shifeng. Matching theory and PIC simulation for klystron output cavity with beam[J]. High Power Laser and Particle Beams, 2025, 37: 023005. doi: 10.11884/HPLPB202537.240338

速调管放大器输出腔的匹配理论

doi: 10.11884/HPLPB202537.240338
基金项目: 国家自然科学基金项目(62301519);高功率微波技术重点实验室项目(JCKYS2021212013、61426050105)
详细信息
    作者简介:

    何 琥,783803749@qq.com

  • 中图分类号: TN62

Matching theory and PIC simulation for klystron output cavity with beam

  • 摘要: 基于输出波导与腔体耦合的等效电路模型,对于任意的输出波导与腔体的耦合和任意的腔体和电子束参数,建立了速调管放大器输出腔的匹配理论即最大输出功率理论。建立了带有互感和感应电流等参数的输出腔等效电路模型,研究了输出微波功率和反射功率,其中在研究反射功率时讨论了复耦合系数不等于1和等于1这两种情况下反射功率的表达式,推导了输出波导与带有电子束的输出腔任意的耦合和完全匹配这两种情形时输出微波功率和间隙电压关系的公式。推导了完全匹配时输出腔谐振频率与输出腔有载品质因数的表达式。匹配情形时从含有互感的等效电路模型推出的输出功率的计算结果与经典理论的计算结果近似相等。
  • 图  1  输出腔等效电路图

    Figure  1.  Equivalent circuit model of a klystron output cavity

    图  2  带有输出波导和电子束的速调管输出腔示意图

    Figure  2.  Schematic of a klystron output cavity with output waveguide and beam

    图  3  输出微波功率与工作频率关系图

    Figure  3.  Output power versus frequency

  • [1] 吴洋. 强流高增益相对论速调管放大器理论和实验研究[D]. 北京: 清华大学, 2013

    Wu Yang. Theoretical and experiment study on intense beam high gain relativistic klystron amplifier[D]. Beijing: Tsinghua University, 2013
    [2] Wu Yang, Xu Zhou, Jin Xiao, et al. A long pulse relativistic klystron amplifier driven by low RF power[J]. IEEE Transactions on Plasma Science, 2012, 40(10): 2762-2766. doi: 10.1109/TPS.2012.2210250
    [3] Wu Yankai, Xie H Q, Li Z H, et al. Gigawatt peak power generation in a relativistic klystron amplifier driven by 1 kW seed-power[J]. Physics of Plasmas, 2013, 20: 113102. doi: 10.1063/1.4828975
    [4] 丁耀根. 大功率速调管的理论与计算模拟[M]. 北京: 国防工业出版社, 2008: 73-75

    Ding Yaogen. Theory and computer simulation of high power klystron[M]. Beijing: National Defence Industry Press, 2008: 73-75
    [5] 何琥, 李士锋, 刘振帮. 速调管放大器输入腔的匹配理论和模拟研究[J]. 强激光与粒子束, 2024, 36:103004 doi: 10.11884/HPLPB202436.240226

    He Hu, Li Shifeng, Liu Zhenbang. Matching theory and PIC simulation for klystron input cavity with microwave beam[J]. High Power Laser and Particle Beams, 2024, 36: 103004 doi: 10.11884/HPLPB202436.240226
    [6] Carlsten B E, Ferguson P. Numerical determination of the matching conditions and drive characteristics for a klystron input cavity with beam[J]. IEEE Transactions on Electron Devices, 1997, 44(5): 894-900. doi: 10.1109/16.568055
    [7] Carlsten B E, Faehl R J, Fazio M V, et al. Beam-cavity interaction physics for mildly relativistic, intense-beam klystron amplifiers[J]. IEEE Transactions on Plasma Science, 1994, 22(5): 730-739. doi: 10.1109/27.338289
    [8] Wilsen C B, Luginsland J W, Lau Y Y, et al. A simulation study of beam loading on a cavity[J]. IEEE Transactions on Plasma Science, 2002, 30(3): 1160-1168. doi: 10.1109/TPS.2002.801623
    [9] Carlsten B E, Ferguson P, Sprehn D. Accuracy of the equivalent circuit model using a fixed beam impedance for klystron gain cavities[J]. IEEE Transactions on Plasma Science, 1998, 26(6): 1745-1749. doi: 10.1109/27.747895
  • 加载中
图(3)
计量
  • 文章访问数:  43
  • HTML全文浏览量:  40
  • PDF下载量:  5
  • 被引次数: 0
出版历程
  • 收稿日期:  2024-07-11
  • 修回日期:  2025-01-02
  • 录用日期:  2025-01-02
  • 网络出版日期:  2025-01-17
  • 刊出日期:  2025-02-15
