安徽大学强光磁试验装置水冷系统研制及其水温高精度控制实现

陈帆 邓天白 徐忠祥 陶骏 丁石川 潘天红 刘东洋 吴俊峰 陈思跃

陈帆, 邓天白, 徐忠祥, 等. 安徽大学强光磁试验装置水冷系统研制及其水温高精度控制实现[J]. 强激光与粒子束, 2025, 37: 021005. doi: 10.11884/HPLPB202537.240347
引用本文: 陈帆, 邓天白, 徐忠祥, 等. 安徽大学强光磁试验装置水冷系统研制及其水温高精度控制实现[J]. 强激光与粒子束, 2025, 37: 021005. doi: 10.11884/HPLPB202537.240347
Chen Fan, Deng Tianbai, Xu Zhongxiang, et al. Water-cooling system development and its high precision water temperature control for Anhui University Free Electron Laser & High Magnetic Field device[J]. High Power Laser and Particle Beams, 2025, 37: 021005. doi: 10.11884/HPLPB202537.240347
Citation: Chen Fan, Deng Tianbai, Xu Zhongxiang, et al. Water-cooling system development and its high precision water temperature control for Anhui University Free Electron Laser & High Magnetic Field device[J]. High Power Laser and Particle Beams, 2025, 37: 021005. doi: 10.11884/HPLPB202537.240347

安徽大学强光磁试验装置水冷系统研制及其水温高精度控制实现

doi: 10.11884/HPLPB202537.240347
基金项目: 强光磁试验装置建设项目(Z010111095)
详细信息
    作者简介:

    陈 帆,chenfan@ahu.edu.cn

    通讯作者:

    陈思跃,22302@ahu.edu.cn

  • 中图分类号: TL508

Water-cooling system development and its high precision water temperature control for Anhui University Free Electron Laser & High Magnetic Field device

  • 摘要: 介绍了安徽大学正在建设的强光磁试验装置的整体布局,详细分析了装置的稳定运行对水冷系统的设计要求及难点,根据需求完成了整个装置的水冷系统设计研制,装置的水冷系统一共包含了两路独立的水冷机组系统,设计温度分别为(42±0.1)℃与(25±0.5)℃,并且可在一定范围内调节。装置水冷控制系统基于EPICS 框架开发,温度调节及控制功能通过PLC程序实现,PID参数配置通过PID调节器实现。控制系统的软件开发主要是在EPICS环境下实现对设备参数的设定和状态数据的回读,并将历史数据存入Archiver Appliances数据库中。试运行期间水冷控制系统的温度控制精度达到了(42±0.03)℃和(25±0.08)℃,符合设计要求,运行期间该系统稳定可靠,可以很好地保障装置安全稳定运行。
  • 图  1  安徽大学强光磁试验装置布局简图

    Figure  1.  Schematic layout of Free Electron Laser & High Magnetic Field device at Anhui University

    图  2  安徽大学强光磁试验装置的恒温水冷系统三维图

    Figure  2.  3-D diagram of the constant temperature water cooling system of the Free Electron Laser & High Magnetic Field device at Anhui University

    图  3  安徽大学强光磁试验装置的恒温水冷系统管道仪表流程图

    Figure  3.  Piping and instrument diagram of the thermostatic water-cooling system of the Free Electron Laser & High Magnetic Field device at Anhui University

    图  4  基于传感器的PID系统控制原理

    Figure  4.  Sensor-based control principles for PID systems

    图  5  25 ℃恒温冷却水系统的恒温和精度控制方案图

    Figure  5.  Constant temperature and precision control scheme diagram of 25 ℃ constant-temperature water-cooling system

    图  6  基于EPICS的水冷系统控制硬件架构图

    Figure  6.  Hardware architecture diagram of EPICS-based water cooling system control

    图  7  冷却水控制系统OPI界面

    Figure  7.  Cooling water control system OPI interface

    图  8  水冷系统温度控制精度测试结果图

    Figure  8.  Water-cooling system temperature control accuracy test results

    表  1  各厅流量分配

    Table  1.   Flow distribution by halls

    position 42 ℃ water cooling capacity/kW 42 ℃ water flow/(t/h) 25 ℃ water cooling capacity/kW 25 ℃ water flow/(t/h)
    FEL hall 18 36 50 30
    auxiliary hall 2 4 50 30
    total 20 40 100 60
    下载: 导出CSV

    表  2  恒温水冷系统主管路设计计算

    Table  2.   Design and calculation of main pipelines for constant temperature water-cooling system

    system
    name
    water temperature
    and control
    accuracy/℃
    dissipation
    of heat/
    kW
    water volume
    for given
    branch/(m3/h)
    temperature
    rise of given
    water/℃
    designed
    flow
    rate/(m/s)
    designed
    pipe
    diameter/mm
    pipe
    diameter
    rounding/mm
    tube flow
    rate/
    (m/s)
    FEL hall25±0.550301.43272.84801.67
    auxiliary hall25±0.550301.43259.47651.67
    FEL hall42±0.118360.43279.791001.27
    auxiliary hall42±0.1240.43226.60321.38
    下载: 导出CSV
  • [1] Zhao Z T, Wang Dangliang, Chen Jianhui, et al. First lasing of an echo-enabled harmonic generation free-electron laser[J]. Nature Photonics, 2012, 6(6): 360-363. doi: 10.1038/nphoton.2012.105
    [2] Allaria E, Castronovo D, Cinquegrana P, et al. Two-stage seeded soft-X-ray free-electron laser[J]. Nature Photonics, 2013, 7(11): 913-918. doi: 10.1038/nphoton.2013.277
    [3] 秦伟伦. X射线自由电子激光的电子束操控方法研究[D]. 北京: 北京大学, 2018: 1-10

    Qin Weilun. Research on electron beam manipulation methods in X-ray free-electron lasers[D]. Beijing: Peking University, 2018: 1-10
    [4] 赵晟. 连续波FEL的注入器束流动力学与束流调制研究[D]. 北京: 北京大学, 2022: 98-108

    Zhao Sheng. Research on the beam dynamics of photoinjector and beam modulation in continuous-wave FEL[D]. Beijing: Peking University, 2022: 98-108
    [5] 曾凌. 高功率谐波型自种子自由电子激光的物理研究[D]. 北京: 北京大学, 2018: 1-10

    Zeng Ling. Study of high power self-seeded harmonic FEL[D]. Beijing: Peking University, 2018: 1-10
    [6] Fang Z, Li J, Qian X X, et al. Design of a 42 T resistive magnet at the CHMFL[J]. IEEE Transactions on Applied Superconductivity, 2024, 34: 4300504.
    [7] 徐远方. 振荡器自由电子激光输出性能研究[D]. 合肥: 中国科学技术大学, 2020: 30-40

    Xu Yuanfang. The study of laser performance in oscillator free electron laser[D]. Hefei: University of Science and Technology of China, 2020: 30-40
    [8] Zen Huishun, Suphakul S, Kii T, et al. Present status and perspectives of long wavelength free electron lasers at Kyoto University[J]. Physics Procedia, 2016, 84: 47-53. doi: 10.1016/j.phpro.2016.11.009
    [9] Ortega J M, Rieul B, Berthet J P, et al. Electron beam adaptation measurement of an infrared FEL[J]. Nuclear Instruments and Methods in Physics Research Section A: Accelerators, Spectrometers, Detectors and Associated Equipment, 2013, 707: 69-72.
    [10] Li Heting, Jia Qika, Zhang Shancai, et al. Design of FELiChEM, the first infrared free-electron laser user facility in China[J]. Chinese Physics C, 2017, 41: 018102. doi: 10.1088/1674-1137/41/1/018102
    [11] 刘金琨. 先进PID控制MATLAB仿真[M]. 北京: 电子工业出版社, 2016

    Liu Jinkun. Advanced PID control MATLAB simulation[M]. Beijing: Publishing House of Electronics Industry, 2016
    [12] EPICS Introduction[EB/OL]. https://epics.anl.gov/index.php.
    [13] EPICS Users[EB/OL]. https://en.wikipedia.org/wiki/EPICS.
    [14] EPICS. IOC software components[EB/OL]. https://docs.epics-controls.org/en/latest/guides/EPICS_Intro.html.
    [15] SNS Controls CS-Studio[EB/OL]. https://controlssoftware.sns.ornl.gov/css_phoebus/.
