短脉冲高产额中子发生器驱动电源研制

董攀 王韬 李杰 刘平 何佳龙 叶龙建

董攀, 王韬, 李杰, 等. 短脉冲高产额中子发生器驱动电源研制[J]. 强激光与粒子束, 2025, 37: 035002. doi: 10.11884/HPLPB202537.240409
引用本文: 董攀, 王韬, 李杰, 等. 短脉冲高产额中子发生器驱动电源研制[J]. 强激光与粒子束, 2025, 37: 035002. doi: 10.11884/HPLPB202537.240409
Dong Pan, Wang Tao, Li Jie, et al. Development of driving power supply for short pulse high yield neutron generator[J]. High Power Laser and Particle Beams, 2025, 37: 035002. doi: 10.11884/HPLPB202537.240409
Citation: Dong Pan, Wang Tao, Li Jie, et al. Development of driving power supply for short pulse high yield neutron generator[J]. High Power Laser and Particle Beams, 2025, 37: 035002. doi: 10.11884/HPLPB202537.240409

短脉冲高产额中子发生器驱动电源研制

doi: 10.11884/HPLPB202537.240409
基金项目: 国家自然科学基金项目(11975217)
详细信息
    作者简介:

    董 攀,panner95@163.com

    通讯作者:

    李 杰,nlijie@sina.com

  • 中图分类号: TM51

Development of driving power supply for short pulse high yield neutron generator

  • 摘要: 真空弧中子发生器是一种短脉冲高产额的中子源,被广泛应用在石油测井、元素活化分析等领域。真空弧中子发生器的典型特点是放电弧流大、脉宽短,为此研制了一套大电流的真空弧放电及其引出电源,包含触发模块、主弧模块和引出模块等。触发模块为LRC放电,输出电压峰值大于5 kV。主弧模块采用LRCD半周期放电方式产生主弧电流,电流峰值大于600 A,半高宽大于0.5 μs。引出模块使用多倍压整流电路,将交流高压整流成所需的高压直流,输出电压峰值大于120 kV,负载电流大于2 A。根据设计方案建立了仿真模型,仿真结果表明该电源能很好地输出设定的电参数。最后制备了一套大电流真空弧放电及引出电源,测试结果表明该电源输出参数和设计值一致,可用来作为真空弧中子发生器驱动电源。
  • 图  1  触发和主弧模块仿真电路

    Figure  1.  Trigger and arc module simulation circuit

    图  2  触发模块导通波形

    Figure  2.  Trigger module conduction waveform

    图  3  主弧模块通道波形

    Figure  3.  Arc module conduction waveform

    图  4  倍压整流电路

    Figure  4.  Voltage doubling rectifier circuit

    图  5  2级倍压电压

    Figure  5.  Two stage doubling voltage

    图  6  触发模块输出波形

    Figure  6.  Trigger module output waveform

    图  7  主弧电流波形

    Figure  7.  Arc current waveform

    图  8  引出电流和高压波形

    Figure  8.  Extraction current and voltage waveform

  • [1] Anders A. Cathodic arcs[M]. New York: Springer, 2008.
    [2] Beilis I I. Vacuum arc cathode spot theory: history and evolution of the mechanisms[J]. IEEE Transactions on Plasma Science, 2019, 47(8): 3412-3433. doi: 10.1109/TPS.2019.2904324
    [3] 米夏兹Γ A. 真空放电物理和高功率脉冲技术[M]. 李国政, 译. 北京: 国防工业出版社, 2007

    Месяц Γ A. Зктоныв вакуумном разряде: пробой, искра, дуга[M]. LI Guozheng, trans. Beijing: National Defense Industry Press, 2007
    [4] 董攀, 刘尔祥, 李杰, 等. 氘化物阴极真空弧放电光斑分布[J]. 强激光与粒子束, 2021, 33:034006

    Dong Pan, Liu Erxiang, Li Jie, et al. Luminous spot distribution of vacuum arc discharge with deuteride cathode[J]. High power Laser and Particle Beams, 2021, 33: 034006
    [5] 唐建, 邓春凤, 伍春雷, 等. 脉冲金属氢化物真空弧放电等离子体发射光谱特性[J]. 强激光与粒子束, 2015, 27:114004 doi: 10.11884/HPLPB201527.114004

    Tang Jian, Deng Chunfeng, Wu Chunlei, et al. Spectral property investigation of pulsed metallic hydride vacuum arc discharge plasmas[J]. High Power Laser and Particle Beams, 2015, 27: 114004 doi: 10.11884/HPLPB201527.114004
    [6] Jia Shaolei, Cao Yingying, Li Guanghao, et al. Electric field design of cold cathode Penning ion source for miniaturization neutron tube[J]. Nuclear Instruments and Methods in Physics Research Section A: Accelerators, Spectrometers, Detectors and Associated Equipment, 2024, 1060: 169071. doi: 10.1016/j.nima.2023.169071
    [7] Zhang Ailin, Li Dong, Xu Lechen, et al. Simulation and optimization of a miniaturized ion source for a neutron tube[J]. Physical Review Accelerators and Beams, 2022, 25: 103501. doi: 10.1103/PhysRevAccelBeams.25.103501
    [8] Jia Shaolei, Lu Zhaohu, Li Guanghao, et al. The magnetic field design of a solenoid for the cold-cathode Penning ion source of a miniature neutron tube[J]. Plasma Science and Technology, 2023, 25: 095503. doi: 10.1088/2058-6272/accbab
    [9] Chernikova D, Romodanov V L, Belevitin A G, et al. Experimental and numerical investigations of radiation characteristics of Russian portable/compact pulsed neutron generators: ING-031, ING-07, ING-06 and ING-10-20-120[J]. Nuclear Instruments and Methods in Physics Research Section A: Accelerators, Spectrometers, Detectors and Associated Equipment, 2014, 746: 74-86.
    [10] Lang R F, Pienaar J, Hogenbirk E, et al. Characterization of a deuterium–deuterium plasma fusion neutron generator[J]. Nuclear Instruments and Methods in Physics Research Section A: Accelerators, Spectrometers, Detectors and Associated Equipment, 2018, 879: 31-38.
    [11] 杨晓光, 史冉冉, 高思佳, 等. 一种高压电源谐振升压倍压电路[J]. 强激光与粒子束, 2018, 30:095007 doi: 10.11884/HPLPB201830.180105

    Yang Xiaoguang, Shi Ranran, Gao Sijia, et al. A resonance boosting and voltage double circuit for high voltage power supply[J]. High Power Laser and Particle Beams, 2018, 30: 095007 doi: 10.11884/HPLPB201830.180105
    [12] 张远绎, 凌志斌, 李旭光. 便携式谐振倍压电容充电电源的设计[J]. 强激光与粒子束, 2020, 32:035006 doi: 10.11884/HPLPB202032.190400

    Zhang Yuanyi, Ling Zhibin, Li Xuguang. Design of portable resonant voltage doubling capacitor charging power supply[J]. High Power Laser and Particle Beams, 2020, 32: 035006 doi: 10.11884/HPLPB202032.190400
    [13] 闫良, 闫英敏, 杨凤彪. 倍压整流电路的分析和仿真[J]. 电子设计工程, 2017, 25(8):119-123

    Yan Liang, Yan Yingmin, Yang Fengbiao. Analysis and simulation of voltage doubling rectifier circuit[J]. Electronic Design Engineering, 2017, 25(8): 119-123
    [14] Wang Rixin, Liang Lizhen, Gong Congguo, et al. Analysis and design of voltage doubling rectifier circuit for power supply of neutron source device towards BNCT[J]. Nuclear Engineering and Technology, 2024, 56(6): 2395-2403. doi: 10.1016/j.net.2024.01.051
    [15] Zhao Guangyi, Liu Xiangyang, Wu Cong, et al. 300 kV/6 mA integrated Cockcroft-Walton high voltage power supply for a compact neutron generator[J]. Review of Scientific Instruments, 2020, 91: 074704. doi: 10.1063/5.0016287
