Narrow line width quasi-continuous-wave yellow laser by optical parametric oscillator
-
摘要: 利用输出532 nm波长的全固态准连续Nd:YAG激光器作为泵浦源，对以KTP晶体为非线性晶体的窄线宽光学参量振荡器输出特性进行研究。在谐振腔内插入石英标准具压缩输出激光线宽。通过理论分析,估算了脉冲光学参量振荡器谐振腔内标准具对闲频光的透射光谱线宽，根据计算结果设计了实验用的标准具参数。在光学参量振荡器谐振腔内插入另一KTP晶体对闲频光进行腔内倍频，实现了波长调谐范围574.5～577.2 nm的pm级窄线宽可调谐黄光输出。在重复频率为10 kHz，泵浦光平均功率为30 W时，倍频黄光的峰值波长为575.81 nm，对应的平均输出功率为155 mW，脉宽约为35 ns，线宽仅为0.8 pm，x和y方向光束质量因子则分别为1.286和1.807。Abstract: The output characteristics of a narrow line width optical parametric oscillator with KTP as the nonlinear crystal which pumped by a 532 nm wavelength all-solid-state quasi-continuous-wave Nd:YAG laser are studied. A quartz etalon is inserted into the resonant cavity to compress the output laser line width. Through theoretical analysis, the transmission spectra line width of the etalon for the idler wave within the pulsed optical parametric oscillator’s resonant cavity is estimated. Based on the calculation results, the parameters of the etalon for experimental use are designed.By inserting another KTP crystal into the optical parametric oscillator resonant cavity to perform intracavity frequency doubling on the idler, a tunable yellow laser output with a wavelength tuning range of 574.5-577.2 nm and a pm-level line width is achieved. At a repetition rate of 10 kHz and an average pump power of 30 W, the peak wavelength of the frequency doubled yellow light is at 575.81 nm, with a corresponding average output power of 155 mW and a pulse width of 35 ns. The line width at the peak wavelength is only 0.8 pm. Beam quality factor in the x and y direction is measured respectively as 1.286 and 1.807.
-
Key words:
- solid-state laser /
- optical parametric oscillator /
- quasi-continuous-wave /
- narrow line width /
- yellow laser /
- etalon
-
图 1 OPO泵浦激光波长和线宽的波形图
Figure 1. The wavelength waveform and the line width waveform of pump laser for OPO
图 4 OPO腔内闲频光在子午面和弧矢面的光斑半径分布
Figure 4. Beam radius of idler wave in the OPO cavity for meridional ray and sagittal ray
图 5 腔内标准具中心波长
1153 nm处的透射率曲线Figure 5. Transmittance curve of etalon in resonant cavity at center wavelength
1153 nm
图 6 闲频光波长与线宽的波形图
Figure 6. The wavelength waveform and the linewidth waveform of the idler wave
图 7 OPO倍频实验装置实物图与黄光输出参数
Figure 7. Photo of OPO frequency doubling experimental device and the yellow laser output
-
[1] Zhou H, Zhang J, Chen T, et al. Picosecond, narrow-band, widely tunable optical parametric oscillator using a temperature-tuned lithium borate crystal[J]. Applied Physics Letters, 1993, 62(13): 1457-1459. doi: 10.1063/1.108657 [2] Strößner U, Meyn J P, Wallenstein R, et al. Single-frequency continuous-wave optical parametric oscillator system with an ultrawide tuning range of 550 to 2830 nm[J]. Journal of the Optical Society of America B, 2002, 19(6): 1419-1424. doi: 10.1364/JOSAB.19.001419 [3] Bi Yong, Zhang Hongbo, Sun Zhipei, et al. High-power blue light generation by external frequency doubling of an optical parametric oscillator[J]. Chinese Physics Letters, 2003, 20(11): 1957-1959. doi: 10.1088/0256-307X/20/11/015 [4] 毕勇, 孙志培, 李惠清, 等. 高平均功率全固态OPO及倍频可调谐蓝光激光器[J]. 石河子大学学报(自科版), 2005, 23(4):397-400Bi Yong, Sun Zhipei, Li Huiqing, et al. High power tunable blue lasers from all-solid-state optical parametric oscillator with frequency doubling[J]. Journal of Shihezi University (Natural Science), 2005, 23(4): 397-400 [5] Strössner U, Peters A, Mlynek J, et al. Single-frequency continuous-wave radiation from 0.77 to 1.73 µm generated by a green-pumped optical parametric oscillator with periodically poled LiTaO3[J]. Optics Letters, 1999, 24(22): 1602-1604. doi: 10.1364/OL.24.001602 [6] Weise D R, Strößner U, Peters A, et al. Continuous-wave 532-nm-pumped singly resonant optical parametric oscillator with periodically poled KTiOPO4[J]. Optics Communications, 2000, 184(1/4): 329-333. [7] Lee D H, Kim S K, Park S N, et al. Continuous-wave 532 nm pumped MgO: PPLN optical parametric oscillator with external power regulation and spatial mode filtering[J]. Applied Optics, 2009, 48(1): 37-42. doi: 10.1364/AO.48.000037 [8] Wang Haobo, Ma Yan, Zhai Zehui, et al. Tunable continuous-wave doubly resonant optical parametric oscillator by use of a semimonolithic KTP crystal[J]. Applied Optics, 2002, 41(6): 1124-1127. doi: 10.1364/AO.41.001124 [9] 王海龙, 杨慧琦, 苏静, 等. 基于单共振光学参量振荡器实现近红外到中红外激光输出的实验研究[J]. 中国激光, 2022, 49:1801005 doi: 10.3788/CJL202249.1801005Wang Hailong, Yang Huiqi, Su Jing, et al. Experimental study of near-infrared to mid-infrared laser output based on single resonant optical parametric oscillator[J]. Chinese Journal of Lasers, 2022, 49: 1801005 doi: 10.3788/CJL202249.1801005 [10] 王月珠, 姚宝权, 鞠有伦, 等. 1.2 W中红外ZnGeP2光参量振荡器(英文)[J]. 强激光与粒子束, 2005, 17(s0):163-166Wang Yuezhu, Yao Baoquan, Ju Youlun, et al. 1.2 W ZnGeP2 optical parametric oscillator[J]. High Power Laser and Particle Beams, 2005, 17(s0): 163-166 [11] 彭跃峰, 王卫民, 刘东, 等. 62W高效率PPMgLN光参量振荡红外激光器[J]. 中国激光, 2010, 37(3):613-616Peng Yuefeng, Wang Weimin, Liu Dong, et al. High efficiency PPMgLN optical parametric oscillator infrared laser with 62W output power[J]. Chinese Journal of Lasers, 2010, 37(3): 613-616 [12] 凤正荣, 朱海永, 段延敏, 等. 新型非临界相位匹配KTA-OPO 2 μm激光器[J]. 强激光与粒子束, 2013, 25(4):805-806 doi: 10.3788/HPLPB20132504.0805Feng Zhengrong, Zhu Haiyong, Duan Yanmin, et al. New type of 2 μm laser source based on non-critical phase matching KTA-OPO[J]. High Power Laser and Particle Beams, 2013, 25(4): 805-806 doi: 10.3788/HPLPB20132504.0805 [13] 李牧野, 杨学宗, 孙玉祥, 等. 单频连续波金刚石拉曼激光器研究进展(特邀)[J]. 红外与激光工程, 2022, 51:20210970 doi: 10.3788/IRLA20210970Li Muye, Yang Xuezong, Sun Yuxiang, et al. Single-frequency continuous-wave diamond Raman laser (Invited)[J]. Infrared and Laser Engineering, 2022, 51: 20210970 doi: 10.3788/IRLA20210970 -
