Output of 100 W 1-mJ narrow linewidth nanosecond-pulsed fiber amplifier based on home-made Yb-doped tapered fiber
-
摘要: 窄线宽大能量纳秒脉冲单模光纤放大器具有高效率、高光束质量和小体积等优点，在激光探测、工业加工等应用领域中具有明显的竞争优势。近期中国工程物理研究院激光聚变研究中心基于国产锥形掺镱光纤和主振荡功率放大器（MOPA），实现了平均功率100 W、脉冲宽度100 ns、单脉冲能量1 mJ、峰值功率10 kW的窄线宽（Δλ3dB=0.49 nm）、线偏振（PER：12.3 dB）、近单模（M2=1.49）全光纤结构1 064 nm激光输出。通过优化增益光纤和放大器设计，可进一步提升放大器的输出能量、功率和光束质量。Abstract: Thanks to the advantages of compact, high beam quality and high conversion efficiency, narrow linewidth high pulse energy single mode nanosecond-pulsed fiber amplifier is highly desired in laser detection and industry applications. Recently, an all-fiber amplifier with a home-made Yb-doped tapered fiber produces linearly polarized (12.3 dB PER) 100 ns, 1 mJ pulses with 0.49 nm linewidth, M2=1.49, 100 W of average output power and 10 kW peak power at 1 064 nm. It is believed that the pulse energy, output power and beam quality can be further improved by optimizing the Yb-doped fiber and design of amplifier.
-
Key words:
- Yb-doped tapered fiber /
- narrow linewidth /
- fiber amplifier /
- nanosecond-pulse
-
图 1 基于国产锥形光纤的窄线宽掺镱纳秒脉冲光纤放大器的实验结构
Figure 1. Experimental setup of narrow linewidth Yb-doped nanosecond-pulsed fiber amplifier based on home-made tapered fiber
-
[1] Jauregui C, Limpert J, Tünnermann A. High-power fibre lasers[J]. Nature Photonics, 2013, 7(11): 861-867. doi: 10.1038/nphoton.2013.273 [2] Brooks C D, Di Teodoro F. 1-mJ energy, 1-MW peak-power, 10-W average-power, spectrally narrow, diffraction-limited pulses from a photonic-crystal fiber amplifier[J]. Optics Express, 2005, 13(22): 8999-9002. doi: 10.1364/OPEX.13.008999 [3] Anderson B M, Flores A, Dajani I. Filtered pseudo random modulated fiber amplifier with enhanced coherence and nonlinear suppression[J]. Optics Express, 2017, 25(15): 17671-17682. doi: 10.1364/OE.25.017671 [4] Liu Wei, Ma Pengfei, Shi Chen, et al. Theoretical analysis of the SRS-induced mode distortion in large-mode area fiber amplifiers[J]. Optics Express, 2018, 26(12): 15793-15803. doi: 10.1364/OE.26.015793 [5] Su Rongtao, Zhou Pu, Ma Pengfei, et al. High-peak-power, single-frequency, single-mode, linearly-polarized, nanosecond all-fiber laser based on SPM compensation[J]. Applied Optics, 2013, 52(30): 7331-7335. doi: 10.1364/AO.52.007331 [6] Kalichevsky-Dong M T, Ge Wenping, Hawkins T W, et al. 4.8 mJ pulse energy directly from single-mode Q-switched ytterbium fiber lasers[J]. Optics Express, 2021, 29(19): 30384-30391. doi: 10.1364/OE.438634 [7] Fedotov A, Noronen T, Gumenyuk R, et al. Ultra-large core birefringent Yb-doped tapered double clad fiber for high power amplifiers[J]. Optics Express, 2018, 26(6): 6581-6592. doi: 10.1364/OE.26.006581 [8] Petrov A, Mikhailovsky G, Gorbatchev A, et al. High-power and pulse energy picosecond narrow linewidth laser system based on tapered fiber amplifier for second harmonic generation[C]//Proceedings of SPIE 11665, Fiber Lasers XVIII: Technology and Systems. 2021: 116651D. [9] Huang Long, Ma Pengfei, Su Rongtao, et al. Comprehensive investigation on the power scaling of a tapered Yb-doped fiber-based monolithic linearly polarized high-peak-power near-transform-limited nanosecond fiber laser[J]. Optics Express, 2021, 29(2): 761-782. doi: 10.1364/OE.414788 -
