Transient analysis of pressure distribution in ultra-high vacuum interlock protection system
-
摘要: 深圳中能高重频自由电子激光装置（S3FEL）是一台规划中的软X射线自由电子激光（FEL）装置，基于TESLA（TeV Energy Superconducting Linear Accelerator）型超导射频腔的直线加速器用于获得高重频高梯度的加速场，超导射频腔所在的低温超导模组是S3FEL装置中最具挑战的核心设备。超高真空差分段位于低温超导模组束流管出口，用于实现电子束运行管道在低温模组段与常温段的过渡，同时差分段上要求具有真空联锁保护，用于在突发情况下对低温模组内超导射频腔的保护。传统的快速关闭阀保护计算中仅按照气体分子速率进行计算，本文通过根据流态判据，划分快阀传感器至模组出口区域并开展有限元法和蒙特卡罗法计算，实现快速保护过程的瞬态分析。快阀传感器—快阀段真空室内瞬态压强分布计算结果表明，快阀传感器设置在距离快阀8～10 m位置可提供足够的缓冲反应时间，使快阀有足够时间做出动作响应；差分段瞬态压强分布计算中，当发生等效泄漏尺寸为0.5 mm的突发泄漏时，当低温测门阀完全关闭时，此处的压强最高达到10−5 Pa，仍能维持较好的高真空环境并满足离子泵的工作要求。此工作为S3FEL的差分段设计提供重要理论依据。Abstract:
Background Shenzhen Superconducting Soft X-Ray Free Electron Laser (S3FEL) is newly proposed by Institute of Advanced Science Facilities, Shenzhen (IASF). The linear accelerator based on TESLA-type superconducting RF cavity is used to obtain high-repetition-frequency and high-gradient field. The cryomodule is the most challenging core part in S3FEL device and ultra-high vacuum differential system is located at the module beam pipe outlet, which is used to realize the transition from cryomodule to ambient temperature section. The vacuum interlock protection is required on differential system to protect the superconducting RF cavity in cryomodule from emergency.Purpose This study aims to analyze the transient process of quick protection.Method Traditional fast closing valve protection process is only calculated according to gas molecular rate, and the finite element method and the Monte Carlo method are used in this paper.Result The transient pressure distribution results of sensor-fast closing valve section show that setting the sensor 8-10 m away from the fast closing valve can provide sufficient buffer reaction time.Conclusions The differential system analyses show that the pressure here reaches 1E-5 Pa within 2 s when the gate valve is completely closed, corresponding to leakage sizes of 0.5 mm, which still maintains a high-vacuum environment and meets working requirement of ion pumps. This work provides important theory basis for the S3FEL. -
图 7 快阀传感器-快阀段管道内压强分布瞬态变化
Figure 7. Transient change of pressure distribution in vacuum pipeline
图 10 差分管道轴向压强分布瞬态变化
Figure 10. Transient change of pressure distribution in differential pipeline
-
[1] 赵振堂. 先进X射线光源加速器原理与关键技术[M]. 上海: 上海交通大学出版社, 2020Zhao Zhentang. Principles and key technologies of advanced X-ray light source accelerators[M]. Shanghai: Shanghai Jiao Tong University Press, 2020 [2] Huang Zhirong, Lindau I. SACLA hard-X-ray compact FEL[J]. Nature Photonics, 2012, 6(8): 505-506. doi: 10.1038/nphoton.2012.184 [3] Zapfe K, Böhnert M, Hensler O, et al. The vacuum system of the European X-ray free electron laser XFEL[J]. Journal of Physics: Conference Series, 2008, 100: 092001. doi: 10.1088/1742-6596/100/9/092001 [4] Zhao Zhentang, Wang Dong, Gu Qiang, et al. SXFEL: a soft X-ray free electron laser in China[J]. Synchrotron Radiation News, 2017, 30(6): 29-33. doi: 10.1080/08940886.2017.1386997 [5] Bharadwaj V. LCLS II design[R]. Menlo Park: SLAC National Accelerator Laboratory, 2018. [6] Huang Yawei, Yao Zhitao, Liu Yuefeng, et al. Design and test results of the vacuum barrier for SHINE linac[C]//Proceedings of the 28th International Cryogenic Engineering Conference and International Cryogenic Materials Conference. 2023: 256-264. [7] Wang Xiaofan, Zeng Li, Shao Jiahang, et al. Physical design for Shenzhen superconducting soft X-ray free-electron laser (S3FEL)[C]//14th International Particle Accelerator Conference. 2023: 1852-1855. [8] 张浩, 赵峰, 林涵文, 等. S3FEL束流测试平台注入段废束桶束窗设计[J]. 强激光与粒子束, 2025, 37: 054001Zhang Hao, Zhao Feng, Lin Hanwen, et al. Design of injector dump beam window for the electron beam test platform of S3FEL[J]. High Power Laser and Particle Beams, 2025, 37: 054001 [9] 张浩, 黄礼明, 林涵文, 等. S3FEL束流测试平台注入段废束桶束窗安全性分析[J]. 强激光与粒子束, 2025, 37: 106032Zhang Hao, Huang Liming, Lin Hanwen, et al. Safety analysis of injector dump beam window for the electron beam test platform of S3FEL[J]. High Power Laser and Particle Beams, 2025, 37: 106032 [10] Hu L B, Wang X L, Yang L, et al. Conceptual design of S3FEL cryogenic system[J]. IOP Conference Series: Materials Science and Engineering, 2022, 1240: 012092. doi: 10.1088/1757-899X/1240/1/012092 [11] Li Han, He Chaofeng, Yue Weiming, et al. Dedicate SRF cryomodule test facilities for S3FEL[C]//21st International Conference on RF Superconductivity. 2023: 298-301. [12] Passarelli D, Parise M, Nicol T H, et al. High-vacuum simulations and measurements on the SSR1 cryomodule beam-line[C]//17th International Conference on RF Superconductivity. 2015: 754-756. [13] Swierblewski J, Bednarski M, Dzieza B, et al. Improvements of the mechanical, vacuum and cryogenic procedures for European XFEL cryomodule testing[C]//17th International Conference on RF Superconductivity. 2015: 906-909. [14] Qin Yuanshuai, Zhang Peng, Cai Hanjie, et al. Transfer line including vacuum differential system for a high-power windowless target[J]. Physical Review Accelerators and Beams, 2020, 23: 113002. doi: 10.1103/PhysRevAccelBeams.23.113002 [15] Wang Wen, Zhang Qingkun, Wang Yongfeng, et al. Design and experimental validation of differential pumped vacuum system for HINEG windowless gas target[J]. Fusion Engineering and Design, 2023, 189: 113465. doi: 10.1016/j.fusengdes.2023.113465 [16] Zhang Jianchuan, Min Yue, Li Lili, et al. Design and realization of vacuum control and interlock system for SESRI project[J]. Radiation Detection Technology and Methods, 2022, 6(4): 502-507. doi: 10.1007/s41605-022-00357-x [17] Pigny G, Antoniotti F, Boivin J P, et al. Measurements, alarms and interlocks in the vacuum control system of the LHC[C]//15th International Conference on Accelerator and Large Experimental Physics Control Systems. 2015: 338-341. [18] 达道安. 真空设计手册[M]. 2版. 北京: 国防工业出版社, 1991Da Dao’an. Handbook of vacuum technology[M]. 2nd ed. Beijing: National Defense Industry Press, 1991 [19] Bi Hailin, Zhang Yicong, He Ziyang, et al. A coupled NS-DSMC method applied to supersonic molecular beam and experimental validation[J]. Vacuum, 2023, 214: 112228. doi: 10.1016/j.vacuum.2023.112228 [20] Dommach M, Di Felice M, Dickert B, et al. The photon beamline vacuum system of the European XFEL[J]. Journal of Synchrotron Radiation, 2021, 28(4): 1229-1236. doi: 10.1107/S1600577521005154 -
