高能同步辐射光源增强器隧道网测量及精度研究

闫皓月; 董岚; 王铜; 梁静; 马娜; 王小龙; 门玲鸰; 卢尚; 韩圆颖; 闫路平; 张露彦; 刘晓阳; 李波; 何振强; 柯志勇

doi:10.11884/HPLPB202537.250055

高能同步辐射光源增强器隧道网测量及精度研究

doi: 10.11884/HPLPB202537.250055

闫皓月^1,,
董岚^{1, 2, ,},
王铜^{1, 2},
梁静^{1, 2},
马娜^{1, 2},
王小龙^{1, 2},
门玲鸰^{1, 2},
卢尚¹,
韩圆颖¹,
闫路平¹,
张露彦¹,
刘晓阳¹,
李波^{1, 2},
何振强^{1, 2},
柯志勇^{1, 2}

1.
中国科学院高能物理研究所，北京 100040
2.
散裂中子源科学中心，广东东莞 523803

基金项目: 国家自然科学基金项目(12075264)

详细信息

作者简介:
闫皓月，yanhy@ihep.ac.cn

通讯作者:
董　岚，dongl@ihep.ac.cn。

中图分类号: TL505;P258
计量
- 文章访问数: 32
- HTML全文浏览量: 23
- PDF下载量: 3
- 被引次数: 0
出版历程
- 收稿日期: 2025-03-27
- 修回日期: 2025-08-13
- 录用日期: 2025-08-12
- 网络出版日期: 2025-08-16

Study on measurement and accuracy of tunnel network in booster of high energy photon source

Yan Haoyue^1
,,
Dong Lan^{1, 2
, ,},
Wang Tong^{1, 2},
Ma Na^{1, 2},
Liang Jing^{1, 2},
Wang Xiaolong^{1, 2},
Men Lngling^{1, 2},
Liu Xiaoyang¹,
Lu Shang¹,
Han Yuanying¹,
Yan Luping¹,
Zhang Luyan¹,
Li Bo^{1, 2},
Ke Zhiyong^{1, 2},
He Zhenqiang^{1, 2}

1.
Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100040, China
2.
Spallation Neutron Source Science Center, Dongguan 523803, China

摘要

摘要: 随着粒子加速器对束流的稳定性要求越来越高，对工程控制网的精度提出了更高的要求，本文以高能同步辐射光源（HEPS）周长454 m的增强器为例，针对隧道内空间狭长、无法大范围通视的不利条件，提出了基于激光跟踪仪精密测量的控制网布设方案及测量方法；同时，面对测量环节中测站多和测点密的数据有效性检测难题，提出了相邻单站拟合及多站拟合的观测过程质量控制方法，点位拟合误差RMS优于0.1 mm；最终，控制网的径向、切向及高程方向各坐标分量的绝对点位误差RMS达到0.2 mm，满足设备安装精度要求。同时，为了监测增强器土建完毕初期的稳定性，对增强器控制网在一年内进行了两期观测，测量结果表明：增强器隧道在一年内产生了10 mm左右变形，具体表现为隧道地基在正东偏南、正北偏西、正南偏西三区域向外膨胀。
- 高能同步辐射光源 /
- 控制网 /
- 激光跟踪仪 /
- 平差处理 /
- 精度分析
Abstract: Background
With the increasing requirement of beam stability in particle accelerators, the accuracy of engineering control network is required to be higher.
Purpose
This study aims to elaborate the specific observation scheme for large-scale tunnel control network, and introduce the control network layout, measurement mode and data processing.
Methods
In this paper, taking the booster of High Energy Photon Source (HEPS) with the circumference of 454 m as an example, aiming at the disadvantages of narrow space in the tunnel, the control network layout scheme and measurement method based on laser tracker precision measurement are proposed. At the same time, in the face of the problem of data validity detection of multiple stations and close points in the measurement process, the quality control method of adjacent single station fitting and multi-station fitting is proposed, and the point fitting error RMS is better than 0.1 mm.
Results
Finally, the absolute point error RMS of radial, tangential and elevation coordinate components of the control network reaches 0.2 mm, which meets the installation accuracy requirements of the equipment. At the same time, in order to monitor the stability of the enhancer after the initial construction, two phases of the enhancer control network were observed in one year. The measurement results show that the deformation of the booster tunnel is about 10 mm in one year. The specific manifestation is that the tunnel foundation expands outward in the three areas of southeast, northwest and southwest.
Conclusions
Overall, the point accuracy of the three directions of the control network is different. The correctness and reliability of the results of the control network can be ensured through multiple control network measurements and data processing and analysis, which provides a reference for other synchrotron radiation light source.
- High Energy Photon Source /
- control network /
- laser tracker /
- adjustment treatment /
- precision analysis

HTML全文

图 1 隧道截面控制点分布图

Figure 1. Distribution of control points in tunnel section

下载: 全尺寸图片幻灯片

图 2 HEPS装置坐标系定义

Figure 2. HEPS device coordinate system definition

下载: 全尺寸图片幻灯片

图 3 跟踪仪测量示意图

Figure 3. Tracker measurement diagram

下载: 全尺寸图片幻灯片

图 4 增强器首次测量拟合偏差统计

Figure 4. First measurement of the booster fitting deviation statistics

下载: 全尺寸图片幻灯片

图 5 增强器第二次测量拟合偏差统

Figure 5. Statistics of fitting deviation of the second measurement of the booster

下载: 全尺寸图片幻灯片

图 6 增强器首次测量绝对点位精度统计

Figure 6. Absolute point accuracy statistics for the first measurement of the booster

下载: 全尺寸图片幻灯片

图 7 增强器首次测量相对点位精度统计

Figure 7. Relative point accuracy statistics of the first measurement of the booster

下载: 全尺寸图片幻灯片

图 8 增强器第二次测量绝对点位精度统计

Figure 8. Absolute point accuracy statistics of the second measurement of the booster

下载: 全尺寸图片幻灯片

图 9 增强器第二次测量相对点位精度统计

Figure 9. Relative point accuracy statistics of the second measurement of the booster

下载: 全尺寸图片幻灯片

图 10 增强器变形示意图

Figure 10. Distortion diagram of the booster

下载: 全尺寸图片幻灯片

图 11 高能光源俯瞰图

Figure 11. High Energy Photon Source overhead view

下载: 全尺寸图片幻灯片

图 12 三次测量坐标差值

Figure 12. The differences in coordinates from three measurements

下载: 全尺寸图片幻灯片

表 1 测站间拟合精度统计表

Table 1. Statistical table of fitting accuracy between stations

	maximum value/mm	minimum value/mm	mean value/mm	RMS/mm
first adjacent stations fitting	0.121	0.015	0.055	0.058
first multi-station fitting	0.142	0.016	0.051	0.059
second adjacent stations fitting	0.166	0.043	0.094	0.096
second multi-station fitting	0.166	0.048	0.089	0.096

下载: 导出CSV

表 2 两次地面网成果及坐标对比

Table 2. Two ground network results and coordinate comparison

point	x/mm	y/mm	z/mm	x/mm	y/mm	z/mm	Δx/mm	Δy/mm	Δz/mm
point	first surface network results			second surface network results			difference value
P03B	−130232.554	75392.727	57803.56173	−130231.6037	75393.04397	57803.7595	0.950	0.317	0.198
P04B	−130233.832	−75376.151	57824.9754	−130233.4951	−75379.02807	57824.7247	0.337	−2.877	−0.251

下载: 导出CSV

表 3 增强器首次测量精度统计表

Table 3. First measurement accuracy statistics table of the booster

		M_r/mm	M_t/mm	M_z/mm
absolute point error	maximum value	0.087	0.068	0.069
	minimum value	0.000	0.000	0.000
	RMS	0.057	0.044	0.044
	mean value	0.054	0.038	0.044
relative point error	maximum value	0.013	0.010	0.041
	minimum value	0.008	0.008	0.026
	RMS	0.009	0.009	0.034
	mean value	0.009	0.009	0.034

下载: 导出CSV

表 4 增强器第二次测量精度统计表

Table 4. Statistical table of the second measurement accuracy of the booster

		M_r/mm	M_t/mm	M_z/mm
absolute point error	maximum value	0.296	0.230	0.093
	minimum value	0.000	0.000	0.000
	RMS	0.193	0.152	0.042
	mean value	0.185	0.137	0.041
relative point error	maximum value	0.065	0.047	0.036
	minimum value	0.037	0.027	0.024
	RMS	0.055	0.040	0.029
	mean value	0.055	0.040	0.028

下载: 导出CSV

表 5 两期数据永久点坐标差值

Table 5. The difference of permanent point coordinates between two periods of data

point	Δx/mm	Δy/mm	Δz/mm
P03B	0.950	0.317	0.198
P04B	0.337	−2.505	−0.250

下载: 导出CSV

表 6 第一次与第二次测量单站数据拟合结果

Table 6. The first and second measurements of the single station data fitting results (mm)

point	x	y	z	point	x	y	z	Δx	Δy	Δz	deviation
booster first measurement				booster second measurement				difference of fit
N01E	−2154.015	−3419.194	72.972	N01E	−2153.925	−3419.103	72.947	0.090	0.091	−0.025	0.130
P03B	455.753	−2936.756	−1584.657	P03B	452.113	−2939.324	−1584.397	−3.640	−2.568	0.260	4.462
N84C	1998.115	−8896.537	237.889	N84C	1998.504	−8896.623	237.922	0.389	−0.086	0.033	0.399
N84E	−1405.302	−9035.101	76.752	N84E	−1405.409	−9035.364	76.836	−0.107	−0.263	0.084	0.296
N83C	2190.508	−13907.794	−29.339	N83C	2190.790	−13908.252	−29.005	0.282	−0.458	0.334	0.633
N02E	−3292.440	1579.134	86.768	N02E	−3292.027	1579.542	86.653	0.413	0.408	−0.115	0.592
N03E	−4966.306	6568.881	95.168	N03E	−4965.908	6569.416	95.031	0.398	0.535	−0.137	0.681
N04E	−7071.915	11371.418	67.343	N04E	−7071.855	11371.823	67.282	0.060	0.405	−0.061	0.414
N05E	−9635.486	16029.972	84.583	N05E	−9636.133	16029.987	84.687	−0.647	0.015	0.104	0.656
N01E	−2154.015	−3419.194	72.972	N01E	−2153.925	−3419.103	72.947	0.090	0.091	−0.025	0.130
N46E	13005.902	−5004.357	99.298	N46E	13006.282	−5004.653	99.668	0.380	−0.296	0.370	0.607
N45E	7991.025	−2187.280	80.901	N45E	7991.297	−2187.541	81.225	0.272	−0.261	0.324	0.497
N44E	3703.471	852.225	105.812	N44E	3703.690	852.140	106.074	0.219	−0.085	0.262	0.352
N44C	1681.837	−1920.423	318.687	N44C	1681.675	−1920.891	318.968	−0.162	−0.468	0.281	0.569
N43E	−73.798	4043.163	86.369	N43E	−73.634	4043.361	86.393	0.164	0.198	0.024	0.258
P04B	−2002.493	2183.522	−1528.857	P04B	−2000.821	2186.391	−1527.491	1.672	2.869	1.366	3.591
N43C	−2636.862	1709.145	357.933	N43C	−2637.133	1708.907	357.936	−0.271	−0.238	0.003	0.361
N42C	−6406.183	5574.865	319.908	N42C	−6406.619	5574.626	319.494	−0.436	−0.239	−0.414	0.647
N42E	−3857.964	7857.320	93.410	N42E	−3858.009	7857.533	93.070	−0.045	0.213	−0.340	0.404

下载: 导出CSV

表 7 第二次与第三次测量单站数据拟合结果

Table 7. The second and third measurements of the single station data fitting results (mm)

point	x	y	z	point	x	y	z	Δx	Δy	Δz	deviation
booster first measurement				booster second measurement				difference of fit
N02E	−2430.261	2204.415	288.202	N02E	−2430.206	2204.456	288.287	0.055	0.041	0.085	0.109
N03A	627.550	6670.640	−1383.339	N03A	627.624	6670.683	−1383.229	0.074	0.043	0.111	0.140
N04A	1734.094	12537.945	−1382.390	N04A	1734.067	12538.040	−1382.346	−0.027	0.095	0.045	0.108
N83B	−6895.974	−13549.849	−1384.002	N83B	−6896.052	−13549.960	−1384.001	−0.078	−0.111	0.002	0.136
N84B	−4236.805	−9399.401	−1383.172	N84B	−4236.856	−9399.482	−1383.166	−0.051	−0.081	0.007	0.096
N84A	−5501.753	−8583.214	−1383.938	N84A	−5501.905	−8583.237	−1383.924	−0.152	−0.023	0.015	0.154
N01C	−1328.642	−4234.699	420.347	N01C	−1328.592	−4234.776	420.312	0.050	−0.077	−0.036	0.099
P03B	−1909.093	−3640.849	−1382.848	P03B	−1909.863	−3640.697	−1382.845	−0.770	0.152	0.004	0.784
N01A	−2051.384	−1546.725	−1382.119	N01A	−2051.394	−1546.708	−1382.021	−0.010	0.017	0.099	0.101
N44B	1277.827	2778.162	−1551.890	N44B	1277.852	2778.136	−1551.930	0.025	−0.026	−0.040	0.053
N44A	−120.801	3287.963	−1552.411	N44A	−120.736	3287.952	−1552.451	0.065	−0.011	−0.040	0.077
N43A	−1371.188	171.988	−1549.324	N43A	−1371.181	172.072	−1549.412	0.007	0.084	−0.088	0.121
P04B	−1367.688	−2001.620	−1530.638	P04B	−1368.130	−2001.602	−1530.622	−0.442	0.018	0.016	0.442
N43C	−724.774	−2470.177	354.789	N43C	−724.857	−2470.072	354.698	−0.083	0.105	−0.091	0.161
N42C	−3316.924	−7206.586	316.347	N42C	−3316.953	−7206.461	316.248	−0.029	0.125	−0.099	0.162
N42B	−3519.240	−7122.133	−1555.201	N42B	−3519.246	−7122.024	−1555.186	−0.006	0.109	0.015	0.110
N42A	−4759.557	−6322.921	−1556.183	N42A	−4759.506	−6322.845	−1556.206	0.051	0.076	−0.023	0.095
N41C	−6361.835	−11810.764	326.681	N41C	−6361.734	−11810.635	326.654	0.101	0.129	−0.027	0.166
N44B	1277.827	2778.162	−1551.890	N44B	1277.852	2778.136	−1551.930	0.025	−0.026	−0.040	0.053

下载: 导出CSV
