Study of field distribution characteristics of large split EMP simulator with distributed terminator
-
摘要: 基于并行时域有限差分（FDTD）方法，以大型分裂型分布式负载垂直极化EMP模拟器有效工作空间的选择为目的，先对固定尺寸的该类型模拟器不同平面上的电场垂直分量峰值（简称为“场峰值”）分布特性进行了研究，进而给出了该类型模拟器有效工作空间的选择方法示例；并据此选择了影响该类型模拟器有效工作空间尺寸的两个典型平面为监测面，研究分析了模拟器的最大宽度、模拟器的架高、及模拟器上极板空隙最大尺寸对所选择的监测面上（归一化）场峰值分布的影响，进而给出模拟器的设计建议。模拟结果表明：模拟器的最大宽度越宽、模拟器的架高越低、及模拟器上极板空隙最大尺寸越小，会使得所选择的监测面上场峰值有增加的趋势；模拟器最大宽度的增加会使得场峰值在模拟器宽度方向上的均匀性变好；模拟器架高的增加会使得场峰值在模拟器高度方向上的均匀性变好，但会使得在宽度方向上的均匀性变得略差；模拟器上极板空隙最大尺寸的增加会使得模拟器内场峰值在宽度方向上的均匀性变好，但会使得其在高度方向的均匀性变差。Abstract:
Background There is currently little research on the choice of the effective work-space of large split vertically polarized electromagnetic pulse (EMP) simulator with distributed terminator.Purpose In order to get the distribution characteristics of the peak-value of electric field’s vertical component (called “field peak-value”) inside large simulators,Methods two typical planes were chosen as testing-planes found on an example of selecting the effective working-space of this type of simulator firstly, then the influences of the maximum width, the maximum height, and the maximum width of the upper plate’s void on (normalized) field peak-value distribution characteristics on the two testing-planes, are studied and analyzed based on parallel finite-difference time-domain (FDTD) method.Results The results show that, field peak-values increase on the two testing-planes, as the simulator’s maximum width is wider, maximum height is lower, and maximum width of the upper plate’s void is smaller. The field peak-value uniform along the simulator’s width direction becomes better as the simulator’s maximum width increases; The field peak-value uniform along the simulator’s height direction becomes better, but becomes slightly wrong along the simulator’s width direction, as the simulator’s maximum height increases; The field peak-value uniform along the simulator’s width direction becomes better, but becomes wrong along the simulator’s height direction, as the maximum width of the upper plate’s void increases.Conclusions When selecting an effective workspace in practical experiments, it is necessary to select the appropriate size-parameters of the simulator according to the field peak-values required by the effect experiment and the actual size of the effector, combined with the engineering practice.-
Key words:
- split /
- field peak-value distribution /
- effective working-space /
- vertically polarized /
- simulator
-
图 1 分裂型分布式负载有界波EMP模拟器简化结构示意图
Figure 1. Model of split bounded-wave EMP simulator with distributed load
图 2 在y=0 m平面及与其平行的几个平面上场峰值的分布
Figure 2. Distribution of Ezp on y=0 m plane and other planes parallel to y=0 m plane
图 3 与yOz平面平行的几个平面上场峰值的分布
Figure 3. Distribution of Ezp on planes parallel to yOz plane
图 4 模拟器最大宽度不同时y=0 m平面上场峰值分布的对比
Figure 4. Comparison of Ezp on y=0 m plane as w different
图 5 模拟器最大宽度不同时x=−9 m平面上场峰值分布的对比
Figure 5. Comparison of Ezp on x=−9 m plane as w different
图 6 模拟器最大宽度不同时y=0 m平面上及x=−9 m平面上归一化场峰值分布的对比
Figure 6. Comparison of Epr on y=0 m plane and x=−9 m plane as w different
图 7 模拟器架高不同时y=0 m平面上场峰值分布的对比
Figure 7. Comparison of Ezp on y=0 m plane as H different
图 8 模拟器架高不同时x=−9 m平面上场峰值分布的对比
Figure 8. Comparison of Ezp on x=−9 m plane as H different
图 9 模拟器架高不同时平面上y=0 m及x=−9 m平面上归一化场峰值分布的对比
Figure 9. Comparison of Epr on y=0 m plane and x=−9 m plane as H different
图 10 上极板空隙最大尺寸不同时y=0 m平面上场峰值分布的对比
Figure 10. Comparison of Ezp on y=0 m plane as d different
图 11 上极板空隙最大尺寸不同时x=−9 m平面上场峰值分布的对比
Figure 11. Comparison of Ezp on x=−9 m plane as d different
-
[1] Baum C E. EMP simulators for various types of nuclear EMP environments: an interim categorization[J]. IEEE Transactions on Electromagnetic Compatibility, 1978, EMC-20(1): 35-53. [2] 潘晓东, 魏光辉, 张希军, 等. 有界波模拟器频率特性研究[J]. 军械工程学院学报, 2005, 17(6): 25-28Pan Xiaodong, Wei Guanghui, Zhang Xijun, et al. Research on frequency characteristic of bounded-wave simulator[J]. Journal of Ordnance Engineering College, 2005, 17(6): 25-28 [3] 刘顺坤, 郑振兴, 焦杰. 电磁脉冲模拟器空间场分布的数值模拟[J]. 强激光与粒子束, 1998, 10(3): 399-402Liu Shunkun, Zheng Zhenxing, Jiao Jie. A numerical simulation of the spatial electromagnetic field in EMP simulator[J]. High Power Laser and Particle Beams, 1998, 10(3): 399-402 [4] 谢彦召, 孙蓓云, 聂鑫, 等. 有界波电磁脉冲模拟器下短线缆效应的理论和实验研究[J]. 强激光与粒子束, 2005, 17(11): 1717-1720Xie Yanzhao, Sun Beiyun, Nie Xin, et al. Response of a short single-wire line illuminated by an EMP simulator[J]. High Power Laser and Particle Beams, 2005, 17(11): 1717-1720 [5] 肖冬萍, 袁军, 何为, 等. 高空核爆电磁脉冲对便携式监护仪的辐射效应[J]. 高电压技术, 2011, 37(7): 1734-1739Xiao Dongping, Yuan Jun, He Wei, et al. Radiation effect of high-altitude electromagnetic pulse on portable monitor[J]. High Voltage Engineering, 2011, 37(7): 1734-1739 [6] 杜立航, 高成, 陈海林, 等. 金属挡板对平行线栅有界波模拟器的影响仿真研究[J]. 强激光与粒子束, 2018, 30: 073204Du Lihang, Gao Cheng, Chen Hailin, et al. Simulation study on influence of metal plate on parallel wire-grid bounded-wave simulator[J]. High Power Laser and Particle Beams, 2018, 30: 073204 [7] 谢彦召, 相辉, 聂鑫, 等. 不对称结构的分布式负载有界波电磁脉冲模拟器[J]. 强激光与粒子束, 2006, 18(10): 1669-1672Xie Yanzhao, Xiang Hui, Nie Xin, et al. Design and construction of an asymmetrical bounded wave EMP simulator with distributed terminators[J]. High Power Laser and Particle Beams, 2006, 18(10): 1669-1672 [8] 翟爱斌, 谢彦召, 韩军, 等. 两种高空核爆电磁脉冲下电话机的效应异同性及概率分布[J]. 强激光与粒子束, 2009, 21(10): 1529-1533Zhai Aibin, Xie Yanzhao, Han Jun, et al. Effect of high altitude nuclear electromagnetic pulse upon phone call[J]. High Power Laser and Particle Beams, 2009, 21(10): 1529-1533 [9] 孙凤杰, 罗学金, 李小伟, 等. 基于时域有限差分法的亚纳秒有界波模拟器数值模拟及分析[J]. 电子工程师, 2008, 34(7): 34-37Sun Fengjie, Luo Xuejin, Li Xiaowei, et al. Numerical analysis and design for subnanosecond EMP simulator based on finite difference-time domain method[J]. Electronic Engineer, 2008, 34(7): 34-37 [10] 孙凤杰, 罗学金, 李小伟, 等. 亚纳秒前沿有界波模拟器传输线设计的理论分析与实验[J]. 强激光与粒子束, 2008, 20(5): 811-814Sun Fengjie, Luo Xuejin, Li Xiaowei, et al. Theoretical analysis and experimental varification on design of transmission line for subnanosecond risetime EMP simulator[J]. High Power Laser and Particle Beams, 2008, 20(5): 811-814 [11] 国海广, 魏光辉, 范丽思, 等. 快沿电磁脉冲模拟器内部垂直极化场分布仿真研究[J]. 强激光与粒子束, 2009, 21(3): 403-406Guo Haiguang, Wei Guanghui, Fan Lisi, et al. Simulation study on vertical field distribution of EMP simulator with fast risetime[J]. High Power Laser and Particle Beams, 2009, 21(3): 403-406 [12] 朱湘琴, 王建国, 陈维青, 等. 分布式负载平行板有界波电磁脉冲模拟器的模拟分析[J]. 强激光与粒子束, 2014, 26: 035001 doi: 10.3788/HPLPB20142603.35001Zhu Xiangqin, Wang Jianguo, Chen Weiqing, et al. Simulation for flat-plate bounded wave electromagnetic pulse simulator with distributed terminator[J]. High Power Laser and Particle Beams, 2014, 26: 035001 doi: 10.3788/HPLPB20142603.35001 [13] Yao Lijun, Shen Tao, Kang Ning, et al. Time-domain simulation and measurement of a guided-wave EMP simulator's field uniformity[J]. IEEE Transactions on Electromagnetic Compatibility, 2013, 55(6): 1187-1194. doi: 10.1109/TEMC.2013.2257795 [14] 谢霖燊, 石跃武, 张国伟, 等. "春雷"号模拟装置新传输线的传输特性[J]. 现代应用物理, 2016, 7: 040501Xie Linshen, Shi Yuewu, Zhang Guowei, et al. Study of the new transmission line used in "spring-thunder" bounded-wave EMP simulator[J]. Modern Applied Physics, 2016, 7: 040501 [15] 张国伟, 王海洋, 陈维青, 等. 60m×20m×10m大尺寸TEM天线传输特性[J]. 强激光与粒子束, 2015, 27: 063202 doi: 10.3788/HPLPB20152706.63202Zhang Guowei, Wang Haiyang, Chen Weiqing, et al. Experimental study on propagation properties of 60m×20m×10m TEM antennas[J]. High Power Laser and Particle Beams, 2015, 27: 063202 doi: 10.3788/HPLPB20152706.63202 [16] 段泽民, 郝凤柱, 张松, 等. 有界波模拟器波形仿真与实验研究[J]. 传感器与微系统, 2018, 37(2): 76-79,85Duan Zemin, Hao Fengzhu, Zhang Song, et al. Waveform simulation and experimental study of bounded-wave simulator[J]. Transducer and Microsystem Technologies, 2018, 37(2): 76-79,85 [17] Nuclear Effects Directorate. Test Operations Procedure (TOP) 1-2-622 Vertical electromagnetic pulse (VEMP) testing[R]. TOP, 2009. [18] Mazuc A. Technical challenges for E3 test facilities meeting new MIL-STD requirements[C]//Proceedings of the 2017 IEEE International Symposium on Electromagnetic Compatibility & Signal/Power Integrity (EMCSI). 2017: 1-23. [19] 朱湘琴, 吴伟, 谢霖燊. 大尺寸Split型垂直极化有界波EMP模拟器场的特性分析[J]. 现代应用物理, 2023, 14: 010503Zhu Xiangqin, Wu Wei, Xie Linshen. Field characteristics analysis of large split-type vertically polarized bounded-wave EMP simulator[J]. Modern Applied Physics, 2023, 14: 010503 [20] IEC TR 61000-4-32, Testing and measurement techniques - high-altitude electromagnetic pulse (HEMP) simulator compendium[S]. [21] Pacheco P S. Parallel programming with MPI[M]. San Francisco: Morgan Kaufman, 1997. [22] 葛德彪, 闫玉波. 电磁波时域有限差分方法[M]. 3版. 西安: 西安电子科技大学出版社, 2011: 239-244Ge Debiao, Yan Yubo. Finite-difference time-domain method for electromagnetic waves[M]. 3rd ed. Xi'an: Xidian University Press, 2011: 239-244 [23] Gedney S D. An anisotropic PML absorbing media for the FDTD simulation of fields in Lossy and dispersive media[J]. Electromagnetics, 1996, 16(4): 399-415. doi: 10.1080/02726349608908487 -
