CSNS-II加速器控制网络管理系统设计与实现

薛康佳; 张玉亮; 朱鹏; 吴煊; 王林; 李明涛; 何泳成; 程司农; 彭娜

doi:10.11884/HPLPB202537.250082

CSNS-II加速器控制网络管理系统设计与实现

doi: 10.11884/HPLPB202537.250082

薛康佳^{1, 2,},
张玉亮^{1, 2, 3},
朱鹏^{1, 2, 3},
吴煊^{1, 2, 3},
王林^{1, 2, 3},
李明涛^{1, 2},
何泳成^{1, 2, 3},
程司农^{1, 2},
彭娜^{1, 2}

1.
中国科学院高能物理研究所，北京 100049
2.
散裂中子源科学中心，广东东莞 523803
3.
中国科学院大学，北京 100049

基金项目: 中国科学院青年创新促进会项目(Y9291420K2)

详细信息

作者简介:
薛康佳，xuekj@ihep.ac.cn

中图分类号: TL503.6
计量
- 文章访问数: 11
- HTML全文浏览量: 9
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2025-04-17
- 修回日期: 2025-05-20
- 录用日期: 2025-06-27
- 网络出版日期: 2025-07-16

Design and implementation of CSNS-II accelerator control network management system

Xue Kangjia^{1, 2
,},
Zhang Yuliang^{1, 2, 3},
Zhu Peng^{1, 2, 3},
Wu Xuan^{1, 2, 3},
Wang Lin^{1, 2, 3},
Li Mingtao^{1, 2},
He Yongcheng^{1, 2, 3},
Cheng Sinong^{1, 2},
Peng Na^{1, 2}

1.
Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
2.
Spallation Neutron Source Science Center, Dongguan Guangdong 523808, China
3.
University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要: 随着基于粒子加速器的大科学装置的规模和复杂度不断提升，其控制网络面临着设备数量激增、安全管控困难、维护效率低下等挑战。针对这些问题，设计并开发了一套面向大型加速器的控制网络管理系统。该系统实现了控制网络IP地址统一管理、网络动态信息自动采集以及网络接入控制的三个主要功能。通过集中申请与审批机制避免IP冲突问题；基于交换机运行数据实现设备在线状态实时监控和物理位置精确定位功能；采用IP与端口绑定方案确保控制网络的安全接入。该系统采用Web架构进行设计和实现，前端基于Vue.js框架开发，后端采用Node.js与Python混合技术栈，数据存储选用MongoDB数据库。该系统已在CSNS加速器控制网络中成功部署并稳定运行，有效解决了网络管理中的安全隐患和维护难题，为CSNS-II网络管理奠定了基础。
- 控制网络 /
- 控制系统 /
- 加速器 /
- 网络管理 /
- 中国散裂中子源
Abstract: As accelerators increase in scale and complexity, their control networks face challenges such as device proliferation, security management difficulties, and low maintenance efficiency. To address these issues, a control network management system for large-scale accelerators was designed and developed. This system implements three functionalities: centralized management of control network IP addresses, automated collection of dynamic network information, and network access control. The system prevents IP conflicts through a centralized application and approval mechanism; enables real-time monitoring of device status and precise physical location identification based on switch operational data; and enhances control network access security through IP and port binding. The system is built on a Web architecture, with a front-end developed using the Vue.js framework and a back-end utilizing a hybrid technology stack of Node.js and Python, while MongoDB is employed for data storage. This system has been successfully deployed and is operating stably in the CSNS accelerator control network, effectively addressing security vulnerabilities and maintenance challenges in network management. It has also established a foundation for network management in CSNS-II.
- control network /
- control system /
- accelerator /
- network management /
- CSNS
