一种兆伏级电触发开关的触发脉冲引入方法

尹佳辉; 魏浩; 孙凤举; 姜晓峰; 梁天学; 罗维熙; 张信军; 张天洋; 呼义翔; 邱爱慈

doi:10.11884/HPLPB202537.250093

一种兆伏级电触发开关的触发脉冲引入方法

doi: 10.11884/HPLPB202537.250093

强脉冲辐射环境模拟与效应全国重点实验室，西北核技术研究所，西安 710024

详细信息

作者简介:
尹佳辉，男，河北廊坊人，副研究员，博士，主要从事脉冲功率技术研究；E-mail：Yinjiahui@nint.ac.cn

中图分类号: TM85
计量
- 文章访问数: 36
- HTML全文浏览量: 13
- PDF下载量: 3
- 被引次数: 0
出版历程
- 收稿日期: 2025-04-22
- 修回日期: 2025-05-12
- 录用日期: 2025-04-24
- 网络出版日期: 2025-05-27

Trigger pulse feed and cable protection for MV electrical-triggered gas switch

National Key Laboratory of Intense Pulsed Radiation Simulation and Effect, Northwest Institute of Nuclear Technology, Xi’an 710024, China

摘要

摘要: 采用电脉冲触发兆伏（MV）级开关，触发器与被触发开关之间既需要良好的电气连接以保证触发脉冲的有效施加，还需要隔离保护措施以避免开关导通后形成的MV级主脉冲反馈回触发器导致其损坏。介绍了一种用于MV级电触发开关的触发脉冲引入方法，该方法将保护电阻放置在脉冲传输线的内外筒之间。当开关导通后，形成的MV级主脉冲经保护元件后再反馈回触发电缆。由于保护电阻与触发电缆之间近似按阻值（阻抗）分压，因此耦合进入触发电缆的脉冲的幅值远低于主脉冲的幅值，而保护电感能够有效抑制开关在导通过程中形成的快前沿、高幅值的电脉冲。结合提出的触发脉冲引入方法，讨论了开关导通过程对触发保护元件的影响，结合等效电路分析了保护电阻、保护电感所起的作用，实验研究了保护元件参数对开关触发特性的影响，最终将这两个保护元件的参数分别设定为500 Ω和2 μH，在此配置下开关在2.6 MV工作电压下实现稳定运行。
- 脉冲功率 /
- 感应电压叠加器 /
- 兆伏级开关 /
- 脉冲触发开关 /
- 触发脉冲引入
Abstract: When a MV triggered gas switch (TGS) is triggered by an electric pulse, a good electrical connection between the trigger generator and the TGS is required to ensure the trigger effect. Besides, a protective method is also necessary to avoid the damage to the trigger generator which feeds back from the MV main pulse after the TGS is closed. In this paper, a novel trigger pulse feed and protection method is introduced. The trigger pulse is introduced via a protective resistor, which is mounted between the inner and outer cylindrical electrodes of the pulse transmission line. The MV pulse is attenuated because the voltage is resistively divided by the resistor and trigger cable arrangement. Both the complex breakdown processes of the switch and its insulation issues are experimentally studied. The function and the beneficial effects of the protective resistor, installed together with an additional inductor, are discussed. Finally, the structure and parameters of these two protective components are set to 500 Ω and 2 μH, in which conditions the switch is demonstrated to successfully work at 2.6 MV.
- pulsed power /
- induction voltage adder /
- MV gas switch /
- triggered gas switch /
- trigger pulse feed

HTML全文

图 1 经电感引入触发脉冲的示意图

Figure 1. Diagram of feeding trigger pulse via hollow inductor

下载: 全尺寸图片幻灯片

图 2 电触发开关及其触发引入的示意图

Figure 2. Diagram of TGS and its trigger pulse feed method

下载: 全尺寸图片幻灯片

图 3 开关实验平台结构示意图

Figure 3. The sectional view of TGS test bed

下载: 全尺寸图片幻灯片

图 4 开关实验平台及触发系统的等效电路图

Figure 4. The equivalent circuit model of TGS test bed and trigger generator

下载: 全尺寸图片幻灯片

图 5 微分型电容分压器结构示意图

Figure 5. The diagram of differential capacitive voltage monitor

下载: 全尺寸图片幻灯片

图 6 两种状态下保护电阻以及触发引入区域的电场分布

Figure 6. The electric field strength simulations of protective resistor under two states

下载: 全尺寸图片幻灯片

图 7 不同保护元件参数下B、C两点的反馈电压波形

Figure 7. The voltage waveforms at the point B and C versus protective parameters

下载: 全尺寸图片幻灯片

图 8 触发电缆末端电压波形

Figure 8. The voltage waveforms at the end of trigger cable

下载: 全尺寸图片幻灯片

图 9 典型的开关触发实验波形及t_g、t_d定义

Figure 9. Typical voltage waveforms of TGS and the definition of t_g and t_d

下载: 全尺寸图片幻灯片

图 10 不同保护参数下的开关实验波形

Figure 10. The voltage waveforms of TGS under different protective parameters

下载: 全尺寸图片幻灯片

图 11 不同保护电阻阻值时的开关触发时刻与触发时延（未串联保护电感）

Figure 11. t_d versus t_g with different protective resistance and without protective inductor

下载: 全尺寸图片幻灯片

图 12 定型开关触发时刻与触发时延对应关系

Figure 12. t_d versus t_g of finalized TGS

下载: 全尺寸图片幻灯片

表 1 开关实验绝缘损坏情况统计

Table 1. Insulation failures events during the TGS test

working voltage/ MV	number of shots	resistance/ Ω	inductance/ nH*	insulation status		conditions of test and TGS
working voltage/ MV	number of shots	resistance/ Ω	inductance/ nH*	trigger cable	resistor insulator	conditions of test and TGS
1.95	18	340	150	damaged	damaged	The original TGS, and the duration of high voltage is about 370 ns.
1.95	86	1050	150	safe	damaged
1.95	12	812	150	safe	safe	The optimized TGS，the main gap spacing is increased from 100 mm to 105 mm and the spacing of disc-ground gap is reduced from 41 mm to 33 mm.
2.27	23	812	150	safe	damaged
2.27	35	780	2000	safe	safe
1.80	140	500	2000	safe	safe	The optimized TGS, and the duration of high voltage is about 310 ns.
2.17	60	500	2000	safe	safe
2.53	86	500	2000	safe	safe
* Note: Without additional protective inductor, the inductance of electoral connection between TGS and protective resistor is about 150 nH.

下载: 导出CSV

参考文献(12)

[1]	Wei Hao, Yin Jiahui, Zhang Pengfei, et al. Simulation, experiment, and performance of a 4 MV induction voltage adder machine for flash X-ray radiography[J]. Physical Review Accelerators and Beams, 2021, 24: 020402. doi: 10.1103/PhysRevAccelBeams.24.020402
[2]	魏浩, 尹佳辉, 张鹏飞, 等. 4 MV/80 kA IVA型脉冲X射线照相装置研制进展[J]. 强激光与粒子束, 2020, 32:025013 doi: 10.11884/HPLPB202032.190331 Wei Hao, Yin Jiahui, Zhang Pengfei, et al. Status of radiographic X-ray source driven by 4 MV, 80 kA induction voltage adder[J]. High Power Laser and Particle Beams, 2020, 32: 025013 doi: 10.11884/HPLPB202032.190331
[3]	邱孟通, 呼义翔, 吴伟, 等. 西北核技术研究所强脉冲辐射模拟装置近年发展综述[J]. 现代应用物理, 2024, 15:030101 doi: 10.12061/j.issn.2905-6223.2024.030101 Qiu Mengtong, Hu Yixiang, Wu Wei, et al. Review of the development of intense pulsed radiation simulator and its technology in northwest institute of nuclear technology in the past decade[J]. Modern Applied Physics, 2024, 15: 030101 doi: 10.12061/j.issn.2905-6223.2024.030101
[4]	魏浩, 孙凤举, 邱爱慈, 等. 国际高能脉冲X射线闪光照相加速器的发展综述[J]. 强激光与粒子束, 2022, 34:094001 doi: 10.11884/HPLPB202234.210444 Wei Hao, Sun Fengju, Qiu Aici, et al. Review of development of high energy pulsed X-ray accelerators for flash radiography[J]. High Power Laser and Particle Beams, 2022, 34: 094001 doi: 10.11884/HPLPB202234.210444
[5]	Yin Jiahui, Sun Fengju, Qiu Aici, et al. 2.8-MV low-inductance low-jitter electrical-triggered gas switch[J]. IEEE Transactions on Plasma Science, 2016, 44(10): 2045-2052. doi: 10.1109/TPS.2016.2600479
[6]	Sincerny P, Childers K, Kortbawi D, et al. Decade Quad design and testing status [pulsed power generator][C]//Proceedings of the Digest of Technical Papers. 11th IEEE International Pulsed Power Conference (Cat. No. 97CH36127). 1997: 698-708.
[7]	张永民, 陈维青, 来定国, 等. 加速器中内置式预脉冲抑制电感的研制[J]. 强激光与粒子束, 2008, 20(9):1533-1536 Zhang Yongmin, Chen Weiqing, Lai Dingguo, et al. Development of inner prepulse restraining inductance of accelerator[J]. High Power Laser and Particle Beams, 2008, 20(9): 1533-1536
[8]	Barrett D M. Trigger system for the eagle pulsed power research facility[C]//Proceedings of the IEEE 3rd Int. Pulsed Power Conf. 1981: 206-209.
[9]	刘轩东, 李登云, 孙凤举, 等. 用于纳秒脉冲高压测量的同轴型电容分压器[J]. 高压电器, 2008, 44(1):32-36 Liu Xuandong, Li Dengyun, Sun Fengju, et al. A coaxial capacitive voltage divider for nanosecond pulse measurement[J]. High Voltage Apparatus, 2008, 44(1): 32-36
[10]	姚伟博, 张永民, 徐启福, 等. 快脉冲测量探头的标定技术研究[J]. 高电压技术, 2019, 45(3):814-819 Yao Weibo, Zhang Yongmin, Xu Qifu, et al. Study on calibration technology for fast pulsed electrical sensors[J]. High Voltage Engineering, 2019, 45(3): 814-819
[11]	刘锡三. 高功率脉冲技术[M]. 北京: 国防工业出版社, 2005 Liu Xisan. High pulsed power technology[M]. Beijing: National Defense Industry Press, 2005
[12]	尹佳辉. MV级气体开关电脉冲同步触发技术研究[D]. 西安: 西北核技术研究所, 2007 Yin Jiahui. Study on electrical synchronized trigger for MV gas switch[D]. Xi’an: Northwest Institute of Nuclear Technology, 2007
