高功率GaN基蓝光二极管激光器（LD）的性能退化实验研究

谢鹏飞; 张永刚; 王丞乾; 吕文强; 武德勇; 郭林辉; 雷军; 王昭; 高松信

doi:10.11884/HPLPB202537.250150

高功率GaN基蓝光二极管激光器（LD）的性能退化实验研究

doi: 10.11884/HPLPB202537.250150

谢鹏飞^{1, 2},
张永刚^{1, 2},
王丞乾^{1, 2},
吕文强^{1, 2},
武德勇^{1, 2},
郭林辉^{1, 2, ,},
雷军^{1, 2},
王昭^{1, 2},
高松信^{1, 2}

1.
中国工程物理研究院应用电子学研究所，四川绵阳 621900
2.
先进激光与高功率微波全国重点实验室，四川绵阳 621900

基金项目: 中国工程物理研究院发展基金（C-2023JMRH-LG）

详细信息

通讯作者:
郭林辉，E-mail：glh863@163.com。

中图分类号: TN248.4
计量
- 文章访问数: 58
- HTML全文浏览量: 14
- PDF下载量: 2
- 被引次数: 0
出版历程
- 收稿日期: 2025-05-23
- 修回日期: 2025-09-30
- 录用日期: 2025-10-05
- 网络出版日期: 2025-11-08

The research on influence factors of high power GaN blue diode laser (LD) performance degradation

Pengfei Xie^{1, 2},
Yonggang Zhang^{1, 2},
Chengqian Wang^{1, 2},
Wenqiang Lv^{1, 2},
Deyong Wu^{1, 2},
Linhui Guo^{1, 2
, ,},
Jun Lei^{1, 2},
Zhao Wang^{1, 2},
Songxin Gao^{1, 2}

1.
Institute of Applied Electronics, China Academy of Engineering Physics, Mianyang, Sichuan 621900
2.
National Key Laboratory of Science and Technology on Advanced Laser and High Power Microwave, China Academy of Engineering Physics, Mianyang, Sichuan 621900

摘要

摘要: 高功率GaN基蓝光二极管激光器在工业加工、铜材料焊接、3D打印、水下激光通信等技术领域有着广泛的应用前景。蓝光二极管激光芯片COS单元器件具有热阻低和尺寸小的优点，但是该器件存在可靠性较低的问题，导致其在工业化应用中受到一定限制，因此对其性能退化因素进行深入研究。基于光学显微技术、扫描电子显微表征和能谱分析手段对经过长时老化考核后器件的性能退化因素进行分析研究。实验研究和分析表明，GaN基体材料缺陷、腔面多余物沉积和光化学腐蚀是导致蓝光二极管激光芯片性能退化的主因，同时良好的气密性封装可提高二极管激光芯片的可靠性。
- GaN蓝光二极管激光器 /
- 性能退化 /
- 二极管激光器封装 /
- 气密封 /
- 高功率
Abstract: Background
High power GaN-based blue diode lasers have wide application prospects in industrial processing, copper material welding, 3D printing, underwater laser communication and other technical fields. The Chip On Submount (COS unit) packaged in the heat sink is a kind of single component that can be applied to the fabrication of high power GaN-based blue diode lasers. The device has the advantages of low thermal resistance and small size.
Purpose
However, due to the low reliability of this device, the industrial application of this COS single component in high power GaN-based blue diode lasers is still limited to a certain extent, and its performance degradation factors need to be studied.
Methods
In this paper, based on the optical microscopy、scanning electron microscopy (SEM) and energy dispersive spectroscopy (EDS) the degradation factors of high power blue light COS components were studied.
Results
Finally, the experimental study and analysis show that the performance degradation factors of blue light diode laser chip are mainly related to GaN matrix material defects, cavity surface surplus deposition and photochemical corrosion factors, and through experiments, it is compared that high power blue light COS single component can improve its reliability by hermetic packaging and provide a reference for the subsequent engineering application of high power blue COS units.
Conclusions
Finally, experimental research and analysis indicate that the performance degradation factors of high-power blue laser diodes (LDs) are primarily related to defects in the GaN substrate material, foreign matter deposition on the cavity surface, and photochemical corrosion factors. Comparative experiments further reveal that the threshold current growth rate of LDs with gas sealing (～0.14 mA/h) is lower than that of non-gas-sealed LDs (～0.27 mA/h). This demonstrates that gas-sealed packaging of high-power blue LD COS unit devices can enhance their reliability.
- GaN blue diode laser /
- performance degradation /
- diode laser packging /
- hermetic packaging /
- high power

HTML全文

图 1 LD老化考核试验装置

Figure 1. The aging assessment of LD

下载: 全尺寸图片幻灯片

图 2 不同状态下的LD输出功率

Figure 2. The optical power curve of the LD

下载: 全尺寸图片幻灯片

图 3 LD在长时老化考核前后的输出波长变化统计

Figure 3. The wavelength statistics of the hermetic packaged LD and non-hermetic packaged LD

下载: 全尺寸图片幻灯片

图 4 非气密封LD前腔面。（a）未老化，（b）老化100小时后，（c）老化1100小时后

Figure 4. The images of front cavity surface of the non-hermetic packaged COS

下载: 全尺寸图片幻灯片

图 5 气密封LD长时老化考核后的前腔面

Figure 5. The images of front cavity surface of the hermetic packaged COS after 1100h aging

下载: 全尺寸图片幻灯片

图 6 非气密封LD前腔面附着物SEM和EDS分析

Figure 6. SEM and EDS analysis of the front cavity surface of a non-hermetic LD

下载: 全尺寸图片幻灯片

图 7 非气密封LD老化考核后的SEM和EDS

Figure 7. SEM and EDS analysis of the front cavity surface of non-hermetic LD after 1100h aging

下载: 全尺寸图片幻灯片

图 8 COD失效后的LD SEM和EDS分析

Figure 8. The images of the COD LD

下载: 全尺寸图片幻灯片

表 1 EDS各元素占比

Table 1. The contents of the elements

Elt.	Atomic/%	Atomic Ratio	Conc./(wt.%)
N	0.000	0.0000	0.000
O	35.256	1.0000	16.862
Al	23.464	0.6655	18.925
Si	25.972	0.7367	21.805
Ga	12.422	0.3523	25.890
Sn	0.205	0.0058	0.727
Au	2.682	0.0761	15.792
Total	100.000	—	100.000

下载: 导出CSV
