量子低扰动电磁环境测试技术

张金颢; 赵冯婷; 冉瑞冰; 安强; 孙占山

doi:10.11884/HPLPB202537.250153

量子低扰动电磁环境测试技术

doi: 10.11884/HPLPB202537.250153

张金颢^{1, 2,},
赵冯婷¹,
冉瑞冰¹,
安强^1, ,,
孙占山¹

1.
国防科技大学电子科学学院，长沙 410073
2.
中国人民解放军 63660部队，河南洛阳 471000

基金项目: 国家自然科学基金联合基金项目（U24B2009）

详细信息

作者简介:
张金颢，fengxueljc@163.com

通讯作者:
安　强，anqiang18@nudt.edu.cn。

中图分类号: O441.4;TN247.9
计量
- 文章访问数: 26
- HTML全文浏览量: 19
- PDF下载量: 0
- 被引次数: 0
出版历程
- 收稿日期: 2025-05-26
- 修回日期: 2025-08-27
- 录用日期: 2025-08-19
- 网络出版日期: 2025-09-08

Quantum low-perturbation electromagnetic environment testing technology

1.
College of Electronic Science and Technology, National University of Defense Technology, Changsha, 410073
2.
63660 Unit of PLA, Luoyang, 471000

摘要

摘要: 基于里德堡原子的量子微波传感技术因其具有自校准、大带宽、高灵敏度以及低扰动等特点，具有颠覆传统电磁场测量方式的潜力。为探索量子微波传感技术在复杂电磁环境测试领域的应用方法，发掘其相较于传统方式的应用优势，利用有限元方法验证了量子微波传感技术的低扰动测量特性，建立了基于里德堡原子的设备内部电场测量方法，证明了其绘制设备内部高分辨率电磁场分布特征的能力。结果表明，量子微波传感技术对待测场的扰动极小，其电场测量分辨率可达毫米级别，可为复杂电磁环境效应分析与评估提供关键数据支撑。
- 复杂电磁环境测试 /
- 量子微波传感技术 /
- 里德堡原子 /
- 低扰动测量 /
- 高分辨率测量
Abstract: Background
In complex electromagnetic environments, electronic devices face risks of strong electromagnetic interference, performance degradation and even damage. Accurate acquisition of internal electromagnetic field distribution is a core prerequisite for analyzing field coupling mechanisms, revealing effect principles and evaluating system safety. Traditional metal electric field probes, due to large size and significant disturbance to the measured field, fail to meet fine measurement needs; electro-optic crystal technology, though with low-disturbance advantage, lacks sufficient sensitivity and frequency selectivity in the GHz band. Rydberg atom-based quantum microwave sensing technology, featuring self-calibration, SI unit traceability and high sensitivity, provides a new solution to the above problems.
Purpose
To address the defects of traditional measurement technologies, verify the low-disturbance property of quantum microwave sensing technology, establish an accurate method for measuring internal electric fields of devices, realize high-resolution electromagnetic field distribution mapping, and provide technical support for the analysis and evaluation of complex electromagnetic environment effects.
Methods
The FDTD algorithm was used to compare field disturbance differences between metal probes and Rydberg atomic vapor cells; an experimental system centered on a cesium atomic vapor cell was built, combining electromagnetically induced transparency (EIT) spectroscopy and atomic superheterodyne technology. 45 measurement points with 2cm intervals were set in a square metal shell-simulated device to complete electric field measurement and data processing.
Results
This technology caused minimal disturbance to the measured field, with measurement resolution reaching the millimeter level (<2 mm); in the simulated device, the maximum field intensity was 14.62 mV/m and the minimum was 1.66 mV/m. It had better frequency selectivity than electro-optic crystal technology, and low-field measurement could effectively reduce device damage risks.
Conclusions
Quantum microwave sensing technology can make up for the shortcomings of traditional technologies. Although high-field real-time monitoring requires combining with spectrum matching and its instantaneous bandwidth is narrow, its engineering application feasibility has been verified. Future research can focus on developing simplified measurement schemes for high-field scenarios.
- complex electromagnetic environment testing /
- quantum microwave sensing technology /
- Rydberg atoms /
- low-disturbance measurement /
- high-resolution measurement

HTML全文

图 1 量子微波传感技术原理示意图

Figure 1. Schematic diagram of the principle of quantum microwave sensing technology

下载: 全尺寸图片幻灯片

图 2 不同探头对设备内部电场扰动对比

Figure 2. Comparison of electric field disturbance caused by different probes inside the device

下载: 全尺寸图片幻灯片

图 3 电场分布的测量与绘制

Figure 3. Measurement and mapping of electric field distribution

下载: 全尺寸图片幻灯片
