基于InP折射率变化的辐射图像探测技术原理验证

涂艳云; 马继明; 宋岩; 张健; 徐青; 孙铁平; 彭博栋; 韩长材; 李阳; 郭泉; 张骞; 高可庆; 李郎郎; 刘振

doi:10.11884/HPLPB202537.250230

基于InP折射率变化的辐射图像探测技术原理验证

doi: 10.11884/HPLPB202537.250230

涂艳云^1,,
马继明^1, ,,
宋岩¹,
张健²,
徐青¹,
孙铁平¹,
彭博栋¹,
韩长材¹,
李阳¹,
郭泉¹,
张骞¹,
高可庆¹,
李郎郎¹,
刘振¹

1.
强脉冲辐射环境模拟与效应全国重点实验室，西北核技术研究所，西安 710024
2.
国防科技大学，长沙 410073

基金项目: 国防科技卓越青年科学基金项目（JQZQ021902）

详细信息

作者简介:
涂艳云，tuyanyun@nint.ac.cn

通讯作者:
马继明，majiming@nint.ac.cn。

中图分类号: TL81
计量
- 文章访问数: 55
- HTML全文浏览量: 11
- PDF下载量: 6
- 被引次数: 0
出版历程
- 收稿日期: 2025-07-20
- 修回日期: 2025-09-21
- 录用日期: 2025-09-21
- 网络出版日期: 2025-09-25
- 刊出日期: 2025-10-15

Proof-of-principle of radiation detecting technology based on InP refractive index changes

1.
National Key Laboratory of Intense Pulsed Radiation Simulation and Effect, Northwest Institute of Nuclear Technology, Xi’an 710024, China
2.
National University of Defense Technology, Changsha 410073, China

摘要

摘要: 为了验证基于磷化铟（InP）晶体折射率变化的辐射图像探测技术对脉冲射线探测的有效性，开展了原理验证实验。搭建了基于迈克尔逊干涉仪的辐射图像探测系统，采用350 μm厚的掺铁InP晶体作为辐射转换晶体。利用该系统成功获取了该晶体在532 nm激光脉冲激发下的干涉条纹变化图像。基于泵浦-探测技术测得掺铁InP晶体在532 nm泵浦激光下的时间响应为1.5 ns。通过在泵浦激光光路中放置分辨率板测量空间分辨率，重构结果表明，系统的空间分辨率可达1 lp/mm。实验结果表明，基于InP折射率变化的超快图像探测技术初步验证可行，该系统有望用于发展具有高时间与高空间分辨能力的脉冲射线探测技术。
- 掺铁InP晶体 /
- 迈克尔逊干涉 /
- 辐射探测技术 /
- 泵浦-探测
Abstract: Background
With the continuous development of national strategic needs, multiple large-scale radiation simulation facilities have been constructed, imposing increasingly stringent requirements on the temporal and spatial resolution of radiation detection. Researchers have been actively developing novel techniques to achieve higher resolution. Against this background, the technique utilizing the transient refractive index response of semiconductor crystals for radiation detection has gained significant attention.
Purpose
This study presents a novel approach based on refractive index changes in indium phosphide (InP) crystals to enhance the temporal and spatial resolution of radiation detection. A proof-of-principle experiment was conducted to validate the effectiveness of the proposed technique for pulsed radiation detection.
Methods
A radiation imaging system was constructed based on a Michelson interferometer configuration. This system used a 350 μm thick iron-doped InP crystal as the radiation sensor.
Results
Using this setup, images of refractive index changes within the crystal induced by laser pulse excitation with a wavelength of 532 nm were successfully captured. Pump-probe measurements revealed that the iron-doped InP crystal exhibited a time response of 1.5 ns under pump laser irradiation. Spatial resolution was characterized by placing a resolution target in the pump beam path; image reconstruction achieved a system spatial resolution of 1 lp/mm.
Conclusions
These experimental results demonstrate the feasibility of the ultrafast image detection technology based on InP refractive index changes. This system has the potential to significantly advance pulsed radiation beam detection technology, offering high temporal and spatial resolution capabilities.
- iron-doped InP crystal /
- Michelson interferometer /
- radiation detecting technology /
- pump-probe

HTML全文

图 1 激光脉冲波形和实验系统示意图

Figure 1. Waveform of laser pulse and schematic of the experimental system

下载: 全尺寸图片幻灯片

图 2 无泵浦激光激发和有泵浦激光激发的干涉条纹图

Figure 2. Comparison of interferograms without and with pump laser excitation

下载: 全尺寸图片幻灯片

图 3 无泵浦激发和有泵浦激发下的干涉条纹图、分辨率卡和重建图

Figure 3. Comparison of interferograms without and with pump excitation, resolution target, and reconstructed image

下载: 全尺寸图片幻灯片

图 4 不同泵浦探测延时时间下的干涉条纹图

Figure 4. Interferograms at different pump-probe delay times

下载: 全尺寸图片幻灯片

参考文献(17)

[1]	邱孟通, 呼义翔, 吴伟, 等. 西北核技术研究所强脉冲辐射模拟装置近年发展综述[J]. 现代应用物理, 2024, 15: 030101 Qiu Mengtong, Hu Yixiang, Wu Wei, et al. Review of the development of intense pulsed radiation simulator and its technology in northwest institute of nuclear technology in the past decade[J]. Modern Applied Physics, 2024, 15: 030101
[2]	马戈, 黑东炜, 罗剑辉, 等. 抛物线型柱面弯晶谱仪在Z箍缩软X射线辐射能谱测量中的应用[J]. 现代应用物理, 2023, 14: 010203 Ma Ge, Hei Dongwei, Luo Jianhui, et al. Parabolic cylindrical curved crystal spectrometer and its application in Z-pinch soft X-ray spectra measurement[J]. Modern Applied Physics, 2023, 14: 010203
[3]	严维鹏, 李斌康, 姚志明, 等. MCP像增强器开关门时间对图像强度分布的影响[J]. 现代应用物理, 2023, 14: 020201 Yan Weipeng, Li Binkang, Yao Zhiming, et al. Influence of MCP image intensifier opening and closing times on image intensity distribution[J]. Modern Applied Physics, 2023, 14: 020201
[4]	Lowry M E, Bennett C V, Vernon S P, et al. X-ray detection by direct modulation of an optical probe beam—Radsensor: progress on development for imaging applications[J]. Review of Scientific Instruments, 2004, 75(10): 3995-3997. doi: 10.1063/1.1790055
[5]	Sarantos C H, Heebner J E. Solid-state ultrafast all-optical streak camera enabling high-dynamic-range picosecond recording[J]. Optics Letters, 2010, 35(9): 1389-1391. doi: 10.1364/OL.35.001389
[6]	Stewart R E, Vernon S P, Steele P T, et al. Ultrafast transient grating radiation to optical image converter: US20120250133A1[P]. 2012-10-04.
[7]	Baker K L, Stewart R E, Steele P T, et al. Solid-state framing camera with multiple time frames[J]. Applied Physics Letters, 2013, 103: 151111. doi: 10.1063/1.4824192
[8]	Brown K, Steele P, Curtis A. Radoptic effect in InP and GaN for ultrafast scintillator applications[C]//Proceedings of SPIE 9215, Radiation Detectors: Systems and Applications XV. 2014: 92150H.
[9]	彭博栋. 基于折射率调制测量MeV级伽马射线脉冲时间行为研究[D]. 西安: 西北核技术研究所, 2016: 16-24 Peng Bodong. Research on detecting time dependent intensity variation of~MeV gamma pulses by refeactive index modulation principle[D]. Xi’an: Northwest Institute of Nuclear Technology, 2016: 16-24
[10]	彭博栋, 宋岩, 盛亮, 等. 折射率调制脉冲射线探测技术原理验证[J]. 强激光与粒子束, 2014, 26: 114005 doi: 10.3788/HPLPB20142611.114005 Peng Bodong, Song Yan, Sheng Liang, et al. Validation of radiation detecting technology based on refractive index modulation[J]. High Power Laser and Particle Beams, 2014, 26: 114005 doi: 10.3788/HPLPB20142611.114005
[11]	Song Yan, Cao Liang, Peng Bodong, et al. Investigation of an InP-based image converter with optical excitation[J]. Review of Scientific Instruments, 2017, 88: 033109. doi: 10.1063/1.4975993
[12]	Song Yan, Peng Bodong, Song Guzhou, et al. Investigating non-equilibrium carrier lifetimes in nitrogen-doped and boron-doped single crystal HPHT diamonds with an optical method[J]. Applied Physics Letters, 2018, 112: 022103. doi: 10.1063/1.5019587
[13]	Song Yan, Peng Bodong, Wang Hongxing, et al. Development of an all-optical framing camera and its application on the Z-pinch[J]. Optics Express, 2017, 25(25): 32074-32079. doi: 10.1364/OE.25.032074
[14]	宋岩, 曹亮, 彭博栋, 等. 基于InP的全光高速相机的理论和实验研究[J]. 强激光与粒子束, 2016, 28: 084005 doi: 10.11884/HPLPB201628.151015 Song Yan, Cao Liang, Peng Bodong, et al. Theoretical and experimental research on the all optical high-speed camera based on InP[J]. High Power Laser and Particle Beams, 2016, 28: 084005 doi: 10.11884/HPLPB201628.151015
[15]	王峰, 魏惠月, 韦欣, 等. 全光扫描装置设计及实验研究[J]. 强激光与粒子束, 2013, 25(9): 2213-2218 doi: 10.3788/HPLPB20132509.2213 Wang Feng, Wei Huiyue, Wei Xin, et al. Design and experimental research of all-optical scanning device[J]. High Power Laser and Particle Beams, 2013, 25(9): 2213-2218 doi: 10.3788/HPLPB20132509.2213
[16]	王博, 白永林, 曹伟伟, 等. 基于探针光调制的皮秒分辨X-ray探测方法与实验[J]. 物理学报, 2015, 64: 200701 doi: 10.7498/aps.64.200701 Wang Bo, Bai Yonglin, Cao Weiwei, et al. Picosecond resolving detection method and experiment for ultrafast X-ray by modulation of an optical probe[J]. Acta Physica Sinica, 2015, 64: 200701 doi: 10.7498/aps.64.200701
[17]	韩长材, 宋顾周, 马继明, 等. 科学级CCD相机噪声标定及特性分析[J]. 现代应用物理, 2014, 5(3): 233-238 Han Changcai, Song Guzhou, Ma Jiming, et al. Measurement and analysis of noise characteristics for scientific-grade CCD cameras[J]. Modern Applied Physics, 2014, 5(3): 233-238
