Test methods of radiation damage effects on semiconductor laser devices
-
摘要: 半导体激光器（LD）作为光源器件被广泛应用于光通信、测量、成像、显示、照明、工业加工、医疗诊断等领域，随着LD在空间光通信、大型强子对撞机、核工业等辐射环境中的大量应用，工作在空间辐射或核辐射环境中的LD会受到辐射损伤的问题日益突出，以LD为核心器件的光通信系统在辐射环境中的可靠性问题备受关注。鉴于国内外关于LD辐照损伤效应试验方法相关的研究报道较少，主要针对LD在辐射环境中应用时遭受的辐照损伤效应，参考与电子元器件辐射效应相关的国内外标准、规范、指南，结合LD辐照损伤效应试验、辐射粒子输运模拟计算、辐照效应仿真模拟、辐照损伤机理分析，从辐照试验源选取、试验流程、辐照偏置条件等方面开展LD辐照损伤效应试验方法研究，分别建立LD位移效应、电离总剂量效应、瞬时剂量率效应辐照试验流程，从而形成辐照损伤效应试验方法，为开展LD辐照损伤评估和抗辐射加固性能考核提供试验技术支撑。Abstract:
Background Semiconductor laser devices (LDs) are a kind of laser with semiconductor material as its working material. LDs are the general name of optical oscillator and optical amplifier produced by photon excited emission caused by electron-optical transition in semiconductor material. LDs have the advantages of small volume, light weight, low power consumption, long life, simple structure, direct modulation and fast response. Thus, LDs are widely used as light source devices in the fields of optics communication, measurement, imaging, display, illumination, industrial processing, medical diagnosis, and so on.Purpose With the application of LD in space optics communication, large hadron collider, nuclear industry, and other radiation environments, LDs operated in space radiation or nuclear radiation environment will suffer radiation damage. The reliability of LD-based optics communication system in radiation environment has attracted much attention. In view of the few reports on LD irradiation damage test methods at home and abroad, this paper mainly focuses on the radiation damage effects on the LDs used in radiation environment.Methods Referring to domestic and foreign standards, specifications and guidelines related to the radiation effects on the electronic components, combining LD irradiation damage test, radiation particle transport simulation and radiation effect simulation, and radiation damage mechanism analysis, the test methods of LD irradiation damage effect are studied from the aspects of irradiation source selection, test flow, irradiation bias conditions, etc.Result The radiation test procedures for the LD displacement effect, ionization total dose effect, and transient dose rate effect are established respectively to form the test method of radiation damage effects on LDs.Conclusions The research provides the experimental technical supports for the evaluation of LD radiation damage and the test of LD radiation hardening. -
图 1 LD的P-I特性曲线随反应堆中子辐照增大的变化关系曲线
Figure 1. P-I curves versus the reactor neutron fluence
图 3 不同偏置下辐照后的LD阈值电流与辐照前阈值电流之比随中子辐照注量的变化曲线
Figure 3. Ratio of the threshold current after radiation of LD to threshold current before radiation versus the reactor neutron fluence with different bias conditions
图 4 在能量为5 MeV，注量为3×1013 p/cm2质子的条件下，LD处于不同偏置状态下辐照后的P-I特性比较
Figure 4. Comparison of LD P-I curves at the 5 MeV proton fluence of 3×1013 p/cm2 with different bias conditions
图 5 半导体激光器电离辐射总剂量效应辐照试验流程
Figure 5. Test procedure of total ionizing dose radiation effects on LD
-
[1] 王祖军, 宁浩, 薛院院, 等. 半导体激光器辐照损伤效应实验研究进展[J]. 半导体光电, 2020, 41(2): 151-158Wang Zujun, Ning Hao, Xue Yuanyuan, et al. Research progresses of radiation damage experiments in laser diodes[J]. Semiconductor Optoelectronics, 2020, 41(2): 151-158 [2] 宁浩. 辐照诱发半导体激光器性能退化实验研究与仿真模拟[D]. 湘潭: 湘潭大学, 2020Ning Hao. Experimental research and analogue simulation of the performance degradation of laser diode induced by radiation[D]. Xiangtan: Xiangtan University, 2020 [3] 常国龙. 半导体激光器辐射效应及影响研究[D]. 哈尔滨: 哈尔滨工业大学, 2010Chang Guolong. The study of the influence of radiation effect on laser diodes[D]. Harbin: Harbin Institute of Technology, 2010 [4] 王立军, 宁永强. 高功率半导体激光器[M]. 北京: 国防工业出版社, 2016Wang Lijun, Ning Yongqiang. High power semiconductor laser[M]. Beijing: National Defense Industry Press, 2016 [5] 姜会林, 佟首峰, 张立中, 等. 空间激光通信技术与系统[M]. 北京: 国防工业出版社, 2010Jiang Huilin, Tong Shoufeng, Zhang Lizhong, et al. The technologies and systems of space laser communication[M]. Beijing: National Defense Industry Press, 2010 [6] Fields R, Kozlowski D, Yura H, et al. 5.625 Gbps bidirectional laser communications measurements between the NFIRE satellite and an optical ground station[C]//Proceedings of 2011 International Conference on Space Optical Systems and Applications. 2011: 44-53. [7] Petree M C. Degradation of luminescence in neutron-irradiated GaAs diodes[J]. Applied Physics Letters, 1963, 3(4): 67. doi: 10.1063/1.1753871 [8] Barnes C E. Neutron damage in GaAs Laser Diodes: at and above Laser Threshold[J]. IEEE Transactions on Nuclear Science, 1972, 19(6): 382-385. doi: 10.1109/TNS.1972.4326862 [9] Schroeder J O, Noel B W. Neutron irradiation effects on diffused GaAs laser diodes[J]. IEEE Transactions on Nuclear Science, 1973, 20(6): 261-265. doi: 10.1109/TNS.1973.4327405 [10] Minden H T. Effects of Proton bombardment on the properties of GaAs laser diodes[J]. Journal of Applied Physics, 1976, 47(3): 1090-1094. doi: 10.1063/1.322731 [11] Millea M F, Aukerman L W. The role of diffusion current in the electroluminescence of GaAs diodes[J]. Applied Physics Letters, 1964, 5(8): 168-169. doi: 10.1063/1.1754101 [12] Compton D M J, Cesena R A. Mechanisms of radiation effects on lasers[J]. IEEE Transactions on Nuclear Science, 1967, 14(6): 55-61. doi: 10.1109/TNS.1967.4324775 [13] Barnes C E. Effects of 60Co gamma irradiation on epitaxial GaAs Laser Diodes[J]. Physical Review B, 1970, 1(12): 4735-4747. doi: 10.1103/PhysRevB.1.4735 [14] 林理彬, 黄万霞, 孔梅影. 粒子束辐照在AlGaAs/GaAs量子阱材料中引入的深能级缺陷[J]. 人工晶体学报, 2000, 29(s1): 248Lin Libin, Huang Wanxia, Kong Meiying. Deep energy defects in AlGaAs/GaAs quantum well material introduced by particle beam irradiation[J]. Journal of Synthetic Crystals, 2000, 29(s1): 248 [15] 黄绍艳, 刘敏波, 王祖军, 等. InGaAsP多量子阱激光二极管及其组件的γ辐射效应[J]. 原子能科学技术, 2009, 43(11): 1024-1028Huang Shaoyan, Liu Minbo, Wang Zujun, et al. γ-ray radiation effect on InGaAsP multi-quantum well laser diodes and its component[J]. Atomic Energy Science and Technology, 2009, 43(11): 1024-1028 [16] 黄绍艳, 刘敏波, 唐本奇, 等. 多量子阱激光二极管质子辐射效应及其退火特性[J]. 强激光与粒子束., 2009, 21(9): 1405-1410Huang Shaoyan, Liu Minbo, Tang Benqi, et al. Proton irradiation effects on multi-quantum-well laser diodes and their annealing characteristics[J]. High Power Laser and Particle Beams, 2009, 21(9): 1405-1410 [17] 杨瑞. 量子点激光器空间电离辐射损伤效应研究[D]. 哈尔滨: 哈尔滨工业大学, 2013Yang Rui. Research on ionizing radiation effect of quantum dot laser[D]. Harbin: Harbin Institute of Technology, 2013 [18] 王俊, 高欣, 冯展祖, 等. 空间光通信用量子点激光器辐射损伤效应研究[J]. 真空与低温, 2019, 25(1): 41-45Wang Jun, Gao Xin, Feng Zhanzu, et al. Radiation damage effect of quantum dot laser with space optical communication[J]. Vacuum and Cryogenics, 2019, 25(1): 41-45 [19] MIL-STD-883H, Ionizing radiation (total dose) test procedure[S]. [20] GJB 9397-2018, 军用电子元器件中子辐射效应试验方法[S]GJB 9397-2018, Test method for neutron radiation effects of military electronic components[S] [21] GJB 5422-2005, 军用电子元器件γ射线累积剂量效应测量方法[S]GJB 5422-2005, Testing method of military electronic devices for γ-ray total dose radiation[S] [22] GJB 548C-2021, 微电子器件试验方法和程序[S]GJB 548C-2021, Test methods and procedures for microelectronic devices[S] [23] GJB 7350-2011, 军用电子器件脉冲γ射线效应试验方法[S]GJB 7350-2011, Testing method of pulse γ-ray radiation effects for military electronic devices [24] Petkov M P. New millennium program: space environments on electronic components guidelines[R]. NASA, 2003. [25] Space Component Coordination Group. Total dose steady-state irradiation test method[R]. ESA/SCC basic specification No. 22900, 1995. [26] 王祖军, 薛院院, 刘敏波, 等. CCD空间环境辐射效应地面模拟试验方法[J]. 现代应用物理, 2016, 7: 040601Wang Zujun, Xue Yuanyuan, Liu Minbo, et al. Ground simulation test methods for space environment radiation effects on charge coupled devices[J]. Modern Applied Physics, 2016, 7: 040601 [27] 王祖军. CMOS图像传感器辐照损伤效应试验方法[J]. 半导体光电, 2025, 46(1): 180-188Wang Zujun. Test methods for radiation damage effects on CMOS image sensors[J]. Semiconductor Optoelectronics, 2025, 46(1): 180-188 [28] 谭志新, 敬罕涛, 樊瑞睿, 等. 中国散裂中子源伴生质子辐照实验平台及其技术参数的确定[J]. 现代应用物理, 2024, 15: 020401Tan Zhixin, Jing Hantao, Fan Ruirui, et al. Associated protons experimental platform of China spallation neutron source and determination of its technical parameters[J]. Modern Applied Physics, 2024, 15: 020401 [29] 沈国红, 张珅毅, 王春琴, 等. HXMT轨道空间辐射环境分析[J]. 现代应用物理, 2023, 14: 010606Shen Guohong, Zhang Shenyi, Wang Chunqin, et al. Analysis of space radiation exploration on hard X-ray modulation telescope[J]. Modern Applied Physics, 2023, 14: 010606 [30] 于春青, 李同德, 王亮, 等. 一款商用MRAM电离总剂量效应研究[J]. 现代应用物理, 2023, 14: 010605Yu Chunqing, Li Tongde, Wang Liang, et al. Total ionizing dose effect of a commercial magnetoresistive random access memory[J]. Modern Applied Physics, 2023, 14: 010605 [31] 王建国, 牛胜利, 张殿辉, 等. 高空核爆炸效应参数手册[M]. 北京: 原子能出版社, 2010Wang Jianguo, Niu Shengli, Zhang Dianhui, et al. The parameter manual book of high-altitude nuclear explosion effects[M]. Beijing: Atomic Energy Press, 2010 [32] Wang Jianguo, Liu Li, Zuo Yinghong, et al. Research progress in numerical simulation of environmental parameters generated by the high-altitude nuclear explosions[J]. IEEE Transactions on Nuclear Science, 2025, 72(3): 884-900. doi: 10.1109/TNS.2025.3530013 [33] GJB 3756A-2015, 测量不确定度的表示及评定[S]GJB 3756A-2015, Expression and evaluation of uncertainty in measurement[S] [34] GB 18871-2002, 电离辐射防护与辐射源安全基本标准[S]GB 18871-2002, Basic standards for protection against ionizing radiation and for the safety of radiation sources[S] [35] 王祖军, 唐本奇, 肖志刚, 等. CCD辐射损伤效应及加固技术研究进展[J]. 半导体光电, 2009, 30(6): 797-802,814Wang Zujun, Tang Benqi, Xiao Zhigang, et al. Progress of radiation damage effects and hardening technology on CCD[J]. Semiconductor Optoelectronics, 2009, 30(6): 797-802,814 [36] 王祖军, 刘静, 薛院院, 等. CMOS图像传感器总剂量辐照效应及加固技术研究进展[J]. 半导体光电, 2017, 38(1): 1-7Wang Zujun, Liu Jing, Xue Yuanyuan, et al. Progress of total ionizing dose radiation effects and hardening technology of CMOS image sensors[J]. Semiconductor Optoelectronics, 2017, 38(1): 1-7 -
